Hunter Products 5620 Montageanleitung
BMW i8 Children’s Electronic Car manufactured by Paragon Child Products Co., Ltd. The BMW
trademarks are used under license from BMW AG. BMW i8 name and associated logos are
trademarks of BMW AG.
Owner’sManualand AssemblyInstructions
Model 5620
Read and understand the entire manual before assembly and operation. The vehicle must be
assembled by an adult who has read and understands the instructions.
Made in China.
Styles and colors may vary.
Save this manual with your sales receipt.
6V BMW i8 Spyder
Introduction
Thank you for purchasing the BMW i8. We hope the rider enjoys it for miles
to come. Please read this instruction guide carefully before assembling and
operating the vehicle.
Please contact Customer Service with any questions.
Web: www.electricrideon.com.au
Phone: 1800224094
Specifications:
BATTERY
MOTOR
AGE
MAX WEIGHT
PRODUCT SIZE
SPEED
RECHARGE TIME
TYPICAL RUN TIME
CHARGER OUTPUT
6V 7AH
6V 20W
3 Years and Up
77 lbs.
25.2 in. x 15.75 in. x 50 in.
2.0MPH
8-12 Hours
1-2 Hours
DC 7.0V0.8A
IMPORTANT!
YOU MUST CHARGE THE BATTERY
FOR 24 HOURS BEFORE FIRST USE!
Charge the battery after each use.
Charge the battery at least once a month, even if the vehicle is not in use.
DO NOT RETURN THIS ITEM
TO THE STORE!
Contact Customer Service if you need assistance or replacement
parts.
www.electricrideon.com.au
1800224094
Read this entire manual to ensure
proper assembly and safe operation
of the vehicle.
5
Table of Contents
Safety..........................................................6
Parts ..........................................................8
Charging Instructions ...............................9
Assemble the Front Wheels....................10
Assemble the Left Rear Wheel...............11
Assemble the Right Rear Wheel ............12
Attach the Steering Wheel......................13
Attach the Mirrors ...................................14
Attach the Seat ........................................15
Battery Removal ......................................16
Operating Instructions ............................17
Maintenance ............................................18
General Care ............................................19
Troubleshooting Guide............................20
...............................22
Service and Repairs
...................................................23
Warranty
6Safety
WARNING: SAFETY RIDING RULES
PREVENT INJURIES AND DEATHS:
• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view
when child is in vehicle. Direct adult supervision is REQUIRED.
• NEVER use on roadways, near cars, on or near steep inclines or steps,
swimming pools or other bodies of water.
• ALWAYS wear shoes.
• ALWAYS sit on the seat.
• NEVER allow mor e than (1) rider in the vehicle.
• Risk of fire. Do not bybass.
The user must follow all safety rules and guidelines, or serious injury or
death may occur to the user.
Always use common sense and safe practices when using the vehicle. The
user must be at least 3 years old and weigh no more than 77 lbs.
This product contains small parts that are for adult assembly only.
Keep small children away when assembling. Remove and dispose of all
protective material and plastic bags before assembly.
Do not overload the vehicle. Do not remove the weight restriction decals.
Do not pull the vehicle with another vehicle or similar device.
Keep body parts such as hands, legs, hair and clothing away from moving
parts. Moving parts can cause serious injury.
etc.).
Always use the vehicle in a safe, secure environment with adult supervision.
Riding the vehicle without a helmet. Riders must always wear a
AS/NZS 2063:2008.
7
Safety
(Continued)
WARNING: BATTERY SAFETY
• Battery posts, terminals and related accessories contain lead and lead compound
(asic) chemicals known to the state of California to cause cancer, reproductive
harm, and are toxic and corrosive. DO NOT open the battery.
• Contact exposure to battery leakage (lead acid) may cause serious injury.
Immediately contact your doctor if exposure occurs. If the chemical is on the skin,
ush immediately with cool water for 15 minutes. If the chemical is swallowed,
immediately give the person water or milk. Do not give water or milk if the person
is vomiting or has decreased alertness. Do not induce vomiting.
• Tampering with or modifying the electric circuit system may cause shock, re or
explosion. It could permanently damage the system. Keep the charger housing
closed to prevent exposed wiring, which may cause electric shock.
IMPORTANT: Before using the vehicle for the rst time, the battery must be
charged for a full 24 hours (no more than 30 hours).
WARNING: ADULT SUPERVISION
REQUIRED
• Before using the vehicle, the rider must understand the vehicle controls and safety
issues.
• It is the responsibility of the adult to educate the child and to determine if the child
is capable of understanding the vehicle controls.
• An adult must ALWAYS directly supervise the use of this vehicle.
• NEVER leave a child unsupervised in the vehicle.
8Parts
1. Windshield
2. Mirrors (2)
3. Steering Wheel
Assembly
4. Seat
5. Spoiler
6.
Left Door7.
Right Door
8. Rear Caps (2)
9. Rear Wheels (2)
10. Front Wheels (2)
11. Inner Wheel Spacer
12. Rims (4)
13. Snap Pins (4)
14. Rear Thick Washer
15. Thin Washers (4)
16. Front Thick Washer (2)
17. Hubcaps (4)
18. Charger
19. Battery
20. Front Grill
21. Front Panels (2)
22. Dashboard
• Phillips screwdriver
• Pliers
Not Included:
1
2
3
4
5
6
7
8
9
10
12
15
16
14
11
17
13
18
19
20
21
22
9
Charging Instructions
ONLY AN ADULT SHOULD HANDLE THE BATTERY AND CHARGER.
To Charge the Battery:
1. Ensure the car is stopped and
turned off.
2. Unlock and remove the seat.
3. Unplug the red battery connector
(A) from the red engine connector
(B).
4. Connect the red battery connector
(A) to the red battery charger
connector (C) and plug (D) into a
120 V outlet.
To Unplug the Battery:
1. Unplug the battery charger (D)
from the outlet.
2. Unplug the red battery connector
(A).
3. Reconnect the red battery
connector (A) to the red engine
connector (B).
4. Replace the seat and tighten lock.
Note: It is not necessary to remove
the battery for charging. However, if
the battery does not reach the outlet,
it can be removed for charging. For
Battery Removal instructions, see
Page 16.
D
YOU MUST CHARGE THE BATTERY FOR 24
HOURS BEFORE THE FIRST USE!
AC
Battery
AB
10 Assemble the Front Wheels
1. Slide the front thick washer (16) onto the axle
2. Slide the front wheel (10) onto the front wheel axle
3. Slide the thin washer (15) onto the axle
4. Push the straight end of the snap pin (13) into the hole on the
front wheel axle to secure the parts into place
5. Snap the rim onto the wheel (12), and snap the hubcap (17) onto
the rim
6. Repeat steps 1-5 for the other front wheel
