Knightsbridge 24DCIP60 Bedienungsanleitung

INSTALLATION & MAINTENANCE MANUAL

IP67 LED DRIVERS

230V

50Hz

These instructions should be read carefully and retained after installation by the end user for

future reference and maintenance.

These instructions should be used to aid installation of the following products:

24DCIP60 / 24DCIP100

GENERAL INSTRUCTIONS

SAFETY

INSTALLATION

• Installation of this driver should only be carried out by a qualified electrician or competent

person to the latest Building and current IEE Wiring Regulations (BS7671)

• Please isolate mains prior to installation/maintenance

• Check the total load on the circuit (including when this driver and LED load is fitted) does not

exceed the rating of the circuit cable, fuse or circuit breaker

• Please note the IP (Ingress of Protection) rating of this product when deciding the location for

installation

• This unit is rated at IP67

• This product is Class I and must be earthed

• This product is non-dimmable

• Provide power to the required point of installation

• Connect the LED driver to the mains supply ensuring the correct polarity is observed (see Fig 1)

Live (brown), Neutral (blue) Earth (green/yellow)

• Connect a suitable LED load to the secondary side of the driver + (red) – (black)

• Switch on power supply and check for correct operation

LED Drivers

These instructions should be read carefully and retained after installation by the end user for future reference and

maintenance.

These instructions should be used to aid installation of the following products:

12DCIP60 / 24DCIP60

SAFETY

•Installation of this driver should only be carried out by a qualified electrician or competent person to the

latest Building and current IEE Wiring Regulations (BS7671)

•Please isolate mains prior to installation/maintenance

•Check the total load on the circuit (including when this driver and LED load is fitted) does not exceed the

rating of the circuit cable, fuse or circuit breaker

•Please note the IP (Ingress of Protection) rating of this product when deciding the location for installation

•This unit is rated at IP67

•This product is Class I and must be earthed

•This product is non-dimmable

INSTALLATION

•Provide power to the required point of installation

•Connect the LED driver to the mains supply ensuring the correct polarity is observed (see Fig 1). Live (brown),

Neutral (blue) Earth (green/yellow)

Fig 1

•Connect a suitable LED load to the secondary side of the driver + (red) –(black)

•Switch on power supply and check for correct operation

WARNING

This product must be disconnected from the circuit if it subjected to any high voltage or insulation resistance testing.

Irreparable damage will occur if this instruction is not followed.

GENERAL

The unit should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where

facilities exist.

Fig 1

WARNING

This product must be disconnected from the circuit if it subjected to any high voltage or insulation

resistance testing. Irreparable damage will occur if this instruction is not followed.

GENERAL

WARRANTY

The unit should be recycled in the correct manner when it reaches the end of its life. Check local

authorities for where facilities exist.

This product has a warranty of 2 years from date of purchase. Failure to install this product in

accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of

the batch codes will invalidate the warranty. If this product should fail within its warranty period it

should be returned to the place of purchase for a free of charge replacement. ML Accessories does

not accept responsibility for any installation costs associated with the replacement product. Your

statutory rights are not affected. ML Accessories reserve the right to alter product specification

without prior notice.

ML Accessories Limited

LU5 5TA

www.mlaccessories.co.uk SBDEC17_V1
