LG A9 Series Bedienungsanleitung

DWG.

No.

TRIG.

DR COMPLETED

도면 DR 완료

완료일 :

LG 전자 (주)

LG Electronics Inc.

UNIT SCALE 11

REVIEWEDDESIGNED

RELATED DWG.

CHECKED APPROVED

P.T.VAN

21.05.27

N.T.ANH

21.05.27

T.Q.THANH

21.05.27

MODELING I

APPROVED

승인자

PREPARED

시방자

DATE

년/월/일

REF. NO.

시방 번호

REV. NO.

기호

REVISION DESCRIPTION

변경 사항

RELEASING THIS DRAWING

WITHOUT PERMISSION LG

Electronics SHOULD BE

ACCUSED ACCORDING TO THE

LAWS AND COMPANY RULES.

이 도면은 LG전자의 자산으로 불법

유출시 관계법과 회사규정에 의해 처벌됨.

PDF

ILLUSTRATOR

148

210

MFL69883680

MANUAL,OWNER’S

A9 MOP CIS향

1/1

MFL69883680

<< 주기 >>

1. 재질, 인쇄방법, 인쇄도수, 외곽치수등은 작업표에 준한다.

2. 인쇄내용, 문자크기 및 형상, 선의 굵기 등은 설계에서 제시된 도면에 준함.

3. 외곽치수는 절단후 치수임.

4. 양산전에 설계 한도를 득할 것.

5. 본 부품에 금지물질이 포함되지 않도록 하고, 상세내용은 LG(63)-A-5501- 34

를 만족할 것.

<< NOTES >>

1. Material, printing and exterier size are refer to work tables.

2. Printing, text size and line are based on LG design drawing.

3. Exterier size on the drawing is cutting line.

4. Before product controlled by criteria sample.

5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,

PBDE) and details should comply with LG standard of LG(63)-A-5501 -34

WORK

적용모델

재 질 인쇄방법

OFFSET 인쇄

132, A5

PAGE

REMARK

SEC.

A9********

CIS향, A9 물걸레

English+Russia+Kazakh

모조지 80g OFFSET 인쇄

T.Q.THANHP.T.VAN

EWJL600038

ECO to realization Specification 21.06.07

www.lg.com

OWNER’S MANUAL

VACUUM CLEANER

Make sure to read the “SAFETY INSTRUCTIONS” carefully before starting

to use this product. Please keep this Owner’s Manual within easy reach

of the user. As the product is only intended for domestic use such as

household cleaning, it must not be used for commercial, experimental or

industrial purposes. Make sure to fully charge the product’s battery before

first use of the product after purchasing it.

A9**********

ENGLISH

MFL69883680

Rev.00_052521

TABLE OF CONTENTS

This manual may contain images or content

different from the model you purchased.

This manual is subject to revision by the

manufacturer.

SAFETY INSTRUCTIONS ..............................................................3

Safety Messages...............................................................................................3

INSTALLATION............................................................................. 11

Parts and Specifications.................................................................................. 11

Installing the Charging Station .......................................................................15

Storing the Accessories...................................................................................19

OPERATION .................................................................................21

Getting Started................................................................................................21

Charging the Battery .......................................................................................23

Using the Mop Nozzle.....................................................................................24

Using the Nozzles ...........................................................................................28

Using the Tools................................................................................................29

MAINTENANCE............................................................................31

Cleaning the Appliance ..................................................................................31

TROUBLESHOOTING..................................................................37

Before Calling for Service ...............................................................................37

SAFETY INSTRUCTIONS

Safety Messages

Reading Safety Messages

The following safety guidelines are intended to prevent unforeseen risks

or damage from unsafe or incorrect operation of the appliance.

The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as

described below.

This symbol is displayed to indicate matters and operations

that can cause risk. Read the part with this symbol carefully

and follow the instructions in order to avoid risk.

WARNING

This indicates that the failure to follow the instructions can cause

serious injury or death.

CAUTION

This indicates that the failure to follow the instructions can cause the

minor injury or damage to the product.

WARNING

To reduce the risk of explosion, fire, death, electric shock,

injury or scalding to persons when using this product, follow

basic precautions, including the following:

Technical Safety

•This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety. Children should

be supervised to ensure that they do not play with the appliance.

•If the power supply cord is damaged, it must be replaced by an LG

Electronics service center or dealer in order to avoid a potential hazard.

•Do not allow children to play with or hang on the appliance.

•Do not use the appliance on a wet surface.

•Place the cords from other appliances out of the area to be cleaned.

Battery

•Never use the battery, adapter, and the charging station from other

appliances with this appliance. Use only the battery and the charging

station provided by LG Electronics.

•Never use the battery, adapter, and the charging station from this

appliance with other appliances.

•Do not use the battery if it is leaking or has changed shape. If skin or

eyes come into contact with battery fluid, thoroughly wash the affected

area immediately with clean water and seek medical attention.

•Replace the battery when it is no longer able to hold a charge.

•Refer to the Charging section instructions for the method of replacing the

battery.

•When disposing of the battery or the appliance, remove the battery from

the appliance and safely dispose of it.

•Follow all local ordinances and regulations when handling or disposing of

the battery.

•In the event that some kind of liquid come from the battery, make sure

that it does not get into contact with the skin or the eye. It may cause fire

or severely damage the eye. If the liquid from the battery got into contact

with a part of skin, immediately wash off with ample amount of water and

seek medical advice.

•Do not use modified or damaged batteries.

Battery Specifications

•One or two batteries are provided, the number of batteries varies

depending on the model purchased.

Model Name EAC63382204

Type Rechargeable Lithium-ion Battery

Rated Capacity 25.2 V , 2400 mAh

Installation

•To avoid an electrical shock or fire, do not install, charge or store the

appliance where it may be exposed to water, rainfall or high humidity.

•Install, charge and store the appliance in a well-ventilated place.

•Avoid operating the appliance in areas where there is a risk of leakage of

flammable gas, industrial oil or metallic dust.

•Do not store or install the appliance, power cord or plug near heating

devices or open flames.

•Install the charging station on a firm, level surface.

•To prevent tipping, floor standing mode installations should be anchored

to the wall using the provided stand anchoring screw, anchoring block

and double-sided tape.

•In wall-mounted mode installations, the charging station should be

secured tightly to the wall using the provided wall anchoring screws.

•Use the anchoring screws only when attaching to concrete or similar solid

surfaces.

•Never drill into a wall without first checking that the area behind it is free

from power conduits, plumbing, vents, or cables.

•Do not use or store the appliance at temperatures below 5 °C or above

38 °C.

•Do not store or install the appliance where it is exposed to temperatures

below freezing or exposed to outdoor weather conditions.

•When installing or moving the appliance, be careful not to pinch, crush, or

damage the power cord or plug.

Operation

•Read all instructions before using the appliance, and save these

instructions.

•Use only as described in this manual. Use only manufacturer’s

recommended attachment.

•This appliance is designed for normal indoor domestic use only. It is not

to be used for any non-residential, commercial, or industrial application.

•Do not use or store the appliance in any outdoor location, garage

environment or on wet surface.

•This product should only be used with a 100 V - 240 V~ 50/60 Hz. Make

sure to check the power specifications of the place where you intend to

use the appliance.

•Do not handle the power cord, plug, or appliance controls with wet hands.

•Wipe any moisture or dirt off the cord or plug with a dry cloth.

•Unplug the power cord using the plug, not the cord. Pulling on the cord

can damage it and result in electric shock or fire.

•Never attempt to operate this appliance if it is damaged, malfunctioning,

partially disassembled, or has missing or broken parts, including a

damaged cord or plug. Take it to an authorized LG Electronics service

center or dealer for assistance.

•Do not apply excessive force to the power cord to bend it, or place it

under a heavy object as this will damage it.

•Do not use multiple-outlet adapters with this appliance. Make sure to use

a power socket with a capacity of 10 A.

•Do not plug the appliance into a damaged or loose outlet.

•Make sure to unplug the power cord and remove the battery if the

appliance will not be used for an extended period of time.

•Do not damage, alter, excessively bend, twist, pull, pinch or heat the

power cord.

•Before using the appliance, remove any wire or string on the floor.

•Avoid touching the prongs of the power plug with your finger(s) when

unplugging the power cord.

•Do not cover the power cord with a rug or carpeting.

•Push the power plug firmly into the wall outlet so that it is not loose.

•If the product has been submerged, contact an LG Electronics service

center or dealer for instructions before resuming use.

•If the product makes a strange noise or emits an odor or smoke,

discontinue use and contact an LG Electronics customer information

center.

•Only qualified technicians or service personnel from LG Electronics may

disassemble, repair or modify the appliance.

•Never insert a sharp metallic object such as a pin, nail or knife in a hole

or gap in the appliance or the charging station.

•Do not vacuum liquids with this appliance. Make sure that no water,

beverage or detergent gets inside the appliance or the charging station.

•Do not allow the appliance to sweep up blades, thumb tacks, sawdust,

sharp objects, or hot or cold ashes.

•Do not allow children to use the appliance.

•Do not let children or pets get close to the appliance when using,

charging or storing.

•Do not insert the nozzle or tools in your mouth.

•Keep clothing and hair, fingers, or other parts of the body away from

openings and moving parts.

•Do not operate the appliance with the suction inlet or outlet blocked.

•Do not use in an enclosed space where vapors are present from paint

thinner, mothproofing substances, flammable dust or other explosive or

toxic materials.

•Make sure that the filter is installed before use.

•Do not use with the dust bin opened.

•Do not touch the charging terminals on the appliance or the charging

station, or insert an electrified object inside the appliance or the station.

•Always store the appliance on the floor standing or wall-mounted

charging station when it is not in use.

•Do not lean the appliance on walls, chairs or tables.

•If the earth leakage breaker is tripped when the product is put on the

charging station, immediately remove the appliance from the charging

station. Contact an LG Electronics customer service center.

•Use extra care when cleaning on stairs.

•Do not use or store a heating device or flammable substance (ether,

benzene, alcohol, chemicals, combustible sprays, insecticide, air

freshener or cosmetics) in close proximity to the appliance.

•Do not attempt to clean up a liquid substance (water, beverage), odorous

substances (candy, chocolate, pet excrement), metallic objects (blades,

pins), flammable substances, surfactants, or glass shards with this

appliance.

•In the event of a gas leak (natural gas, propane gas, etc.) do not operate

this or any other appliance. Open a window or door to ventilate the area

immediately.

•Do not hold the charging station upside down with the battery in the

charging station.

•Do not disassemble, remove or short-circuit the battery.

•Do not expose the appliance, and the battery in particular, to heat, a

heating device or direct sunlight.

•Do not keep the appliance or its battery inside a vehicle which is exposed

to direct sunlight.

•Never allow any water, beverage or detergent to get inside the battery

•Do not apply physical impacts to the battery.

Maintenance

•Make sure to unplug the power cord when cleaning or maintaining the

charging station.

•Do not wash the inlet port or the dust bin with water or detergent.

•Do not use detergents, polishes or air fresheners to clean the dust bin.

•Do not apply or spray a flammable substance (gasoline or thinner) or

surfactants (detergent or bath soap) on the appliance.

•Wash hands after handling nozzles. The nozzles contain carbon fiber,

and contact may cause minor skin irritation.

Disposal

•Keep packing materials out of the reach of children. Packaging materials

can pose a suffocation risk for children.

•Destroy the carton, plastic bag, and other packing materials after the

appliance is unpacked. Children might use them for play. Cartons

covered with rugs, bedspreads, or plastic sheets can become airtight

chambers.

•Dispose of this appliance according to local, state, and regional laws and

regulations.

•Contact your local city council or the related government authority before

disposing of this appliance.

Mop Nozzle

•Do not vacuum sharp objects (glass pieces, wire, blades, pins, etc.) with

the mop nozzle attached. When cleaning the mop pads after mopping,

you could be injured by a sharp object embedded in the mop.

CAUTION

To reduce the risk of injury to persons, malfunction, or damage

to the product or property when using the appliance, follow basic

safety precautions, including the following:

Operation

•This appliance has a built-in safety device to prevent damage from

overheating. If the appliance becomes overheated after extended use,

it may automatically turn off. If this occurs, leave the appliance in a cool,

well-ventilated area for about an hour before turning on the power again.

•Do not subject the product to shocks or drop it.

•Secure the appliance in the charging station when not in use, to avoid it

falling over.

•Do not install wet or damp filters.

•Make sure to wipe up any liquid such as water or oil or pet excrement

from the floor before using the appliance.

•Do not clean the product with a volatile or organic solvent (thinner or

acetone).

•Always use a soft cloth to clean the appliance.

•Remain aware of your surroundings while using the appliance to avoid

colliding with people or animals.

•Do not kick or apply force to the appliance.

•Do not put any object other than the appliance, especially a metallic or

magnetic object, on the charging station.

•Do not clean the same spot repeatedly for an extended period of time.

•Vibration from the inlet port or rotating brush may damage the floor or the

carpet.

•Keep fingers away from pinch points when assembling the appliance or

the charging station.

Andere Handbücher für A9 Series

Inhaltsverzeichnis

Sprachen:

Andere LG Staubsauger Handbücher

LG VK7918NNA Bedienungsanleitung

LG VC73189NHTB Bedienungsanleitung

LG V-CC162H Series Bedienungsanleitung

LG VK8320SCSNY Bedienungsanleitung

LG VK7322 H Series Bedienungsanleitung

LG VR648 Series Bedienungsanleitung

LG V-CD271NT Series Bedienungsanleitung

LG VK7210 R Series Bedienungsanleitung

LG CodeZero A9 Series Bedienungsanleitung

LG VC68 Series Bedienungsanleitung

LG V-KC701H Series Bedienungsanleitung

LG A927KGMS Bedienungsanleitung

LG VK89 series Bedienungsanleitung

LG VC2320NNTR Bedienungsanleitung

LG VK5320GHTMY Bedienungsanleitung

LG V-C40**S series Bedienungsanleitung

LG VK89304H Bedienungsanleitung

LG VS8606SWM Bedienungsanleitung

LG VC42 NH Series Bedienungsanleitung

LG VR657*LVMP Bedienungsanleitung

LG VN-19210C Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

LG VC2020NNTR Bedienungsanleitung

LG VC3319YM Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung

Nobles

Nobles 608669 Produkthandbuch
