USER INSTRUCTIONS

HEIGHT ADJUSTABLE TOILET FRAME

WITH SEAT

M11090 Height Adjustable Toilet Frame with Seat

General Safety Warning

Please make sure that you read and follow

these instructions carefully. Keep these

instructions in a safe place for future reference.

Maximum User Weight

30st

190kg

1. INTENDED USE

To assist users when lowering onto and rising from the toilet. Primarily for use over the toilet using the

splash guard provided but also for use as a commode with the addition of a potty. The seat lid adds discreet

style and helps to improve cleanliness and hygiene.

Figure 1:

2. SAFETY

WARNING: The maximum user weight must not be

more than 190 kg (30 st).

DO NOT attempt to stand or climb on the product.

MAKE SURE all legs are set at equal height to avoid

rocking.

3. UNPACKING

Remove the packaging and check all parts carefully.

Contact your supplier immediately if parts are

missing or damaged and do not try and assemble.

4. INSTALLATION INSTRUCTIONS

Product arrives fully assembled.

To adjust the height:

• Remove the ‘E-clip’ and slide the legs to the

desired position.

• Align the holes and re-insert the ‘E-clip’.

• Repeat for all four legs.

Ensure that all four legs are positioned at the same

height to prevent rocking and instability.

Place the frame over the toilet ensuring that the

internal splash guard is positioned centrally over the

toilet bowl.

To t M20303 - Commode Pan

Figure 2: M20303 Commode Pan

Lift the seat and lid to slot the commode pan into

position on the frame, see gure 3.

Figure 3: M11090 with Commode Pan (M20303)

tted

5. OPTIONAL FLOOR FIXING KIT

The oor xing kit provides a permanent xing

solution for the Toilet Frame. It helps to prevent

the frame from moving out of position or becoming

unstable during use.

F11572 – Floor Fixing Kit

Available as an accessory from NRS Healthcare.

See the end of this document for contact details.

5.1 Fitting Instructions

Adjust the toilet frame to the desired width, see

Section 4.

To t the legs:

Remove the original leg extensions by removing the

‘E-clips’ and sliding them out of the frame.

Insert the four leg extensions and position at the

desired height.

Align the holes and insert the ‘E-clip’.

Ensure that all four legs are secured at the same

height to prevent rocking and instability.

Please note the height cannot be adjusted once the

legs are secured to the oor.

To x to the oor:

Choose a xing method which is suitable for the

construction of the oor. Use 3 screws per each of

the four legs. See gure 4.

Figure 4:

6. MAINTENANCE

Check that all xing clips are inserted correctly and

that there is no excessive movement.

If a oor xing kit has been tted, check the xing

screws are secure.

Inspect the product regularly for signs of wear or

damage, pay particular attention to the condition of

the ferrules.

Any suspected faults or damage should immediately

be reported to the supplier and the product taken out

of use.

7. CLEANING INSTRUCTIONS

Clean regularly using a general purpose, neutral

detergent and warm water. Pay particular attention

to the toilet seat hinges and underside of lid.

Please check the suitability of the cleaning products

before use. Do not use abrasive cleaners or cloths

as these could permanently damage the surface and

invalidate any warranty.

To disinfect, wipe with a dilute bleach solution and

rinse thoroughly with fresh water.

Allow the product to dry fully prior to use/storage.

8. PRODUCT DISPOSAL

This product must be thoroughly cleaned/sterilised

prior to disposal.

This product is manufactured from metal & plastic

and can be disposed of through Local Authority

Household Waste and Recycling Centres or through

Local Trade Waste Collectors.

9. PRODUCT GUARANTEE

NRS Healthcare guarantee this product for a period

of 24 months, from the date of purchase, against

faulty materials and workmanship.

This guarantee does not cover abuse, interference

or tampering with any part of the products. Issues

arising from fair wear & tear and customer misuse

are not covered.

This guarantee covers domestic use only. If the

product is used in commercial or semi-commercial

settings such as care homes, schools, rental or

communal accommodation etc, the guarantee is

valid for one year only. Consumable parts are also

guaranteed for one year only.

Any guarantee issued by NRS Healthcare does not

a󰀨ect your statutory rights.

3M11090-UI-6 07-08-2023

NRS HEALTHCARE Sherwood House, Cartwright Way, Forest Business Park

Bardon Hill, Coalville, Leicestershire, LE67 1UB, UK.

Tel: Customer Services: +44 (0)345 121 8111 Email: [email protected]

NRS Healthcare is a leading supplier of community equipment and daily living aids.

Please visit one of our websites to view our full range of products:

www.healthcarepro.co.uk or www.completecareshop.co.uk
