USER INSTRUCTIONS

MOWBRAY LITE PLUS

N53909 Mowbray Lite Plus

General Safety Warning

Please make sure that you read and follow these

instructions carefully. Keep these instructions in a

safe place for future reference.

Maximum User Weight

30st

190kg

1. INTENDED USE

The height and width adjustable Mowbray Lite Plus toilet frame and seat with lid has been designed to assist those

who have diﬃculty in lowering onto or rising from a standard toilet. The comfortable plastic moulded seat oﬀers

support in a natural position. The seat lid adds discreet style and helps to improve cleanliness and hygiene. An

optional ﬂoor ﬁxing kit is also available (F11572).

2. SAFETY

WARNING: The maximum user weight must not be more

than 190Kg (30st).

DO NOT: Attempt to stand or climb on the product.

MAKE SURE: All legs are set at equal height to avoid

rocking.

3. UNPACKING

Remove the packaging and check all parts carefully.

Contact your supplier immediately if parts are missing or

damaged and do not try and assemble.

3.1 Contents:

1. Toilet Seat & Lid x 1

2. RH Frame Assembly x 1

3. LH Frame Assembly x 1

4. Leg Extensions x 4

5. Crossbar x 2

6. E-clip x 8

4. ASSEMBLY/INSTALLATION

4.1 Fitting the Crossbars:

1. Slot the 2 x crossbars onto the side-frame assemblies

and adjust to the correct width for the toilet and the user.

2. Align the holes and secure with the 4 x E-clips.

Note: Make sure that the side-frames and crossbars

have been set to the same width/adjustment holes.

4.2 Fitting the Leg Extensions:

3. Slot the 4 x leg extensions into the side-frame

assemblies and adjust to the correct height for the toilet

and the user.

4. Align the holes and secure with the 4 x E-clips.

4.3 Fitting the Seat

Place the seat on the frame in the correct position, with

the front of the seat and curve of the armrests facing

forwards.

Push down ﬁrmly on the seat until it snaps into position

on both the front and rear cross bars.

5. INSTALLATION

5.1 To install the Mowbray Lit Plus:

Place the frame over the toilet ensuring that the internal

splash guard is central over the toilet bowl.

6. IN USE

Adjust the height and width* for the toilet and user before

installation.

6.1 Adjust the Height

1. Remove the 4 x leg extension E-clips.

2. Slide the leg extensions to the required height, align

the holes and replace the E-clips.

Note: Make sure the seat and toilet frame are fully secure

before use.

6.2 Adjust the Width

1. Remove the 4 x cross bar E-clips.

2. Slide the side frame assemblies to the required

width, align the holes and replace the E-clips.

Note: Make sure the side frame assemblies have been

set to the same width.

Note: Make sure the seat and toilet frame are fully secure

before use.

6.3 Fitting the Optional Floor Fixing Kit

Please refer to the user instructions provided with the

optional ﬂoor ﬁxing kit (F11572).

7. MAINTENANCE

Check that all ﬁxing clips are inserted correctly and that

there is no excessive movement.

If a ﬂoor ﬁxing kit has been ﬁtted, check the ﬁxing screws

are secure.

Inspect the product regularly for signs of wear or damage,

pay particular attention to the condition of the ferrules.

Any suspected faults or damage should immediately be

reported to the supplier and the product taken out of use.

8. CLEANING INSTRUCTIONS

Clean regularly using a general purpose, neutral detergent

and warm water.

Please check the suitability of the cleaning products

before use. Do not use abrasive cleaners or cloths as

these could permanently damage the surface and

invalidate any warranty.

To disinfect, wipe with a dilute bleach solution and rinse

thoroughly with fresh water.

Allow the product to dry fully prior to use/storage.

9. ACCESSORIES & SPARE PARTS

F11572 - Floor Fixing Kit

N43218 - E-clips x 4

For further information please visit our website or call

Customer Services on the details below.

10. PRODUCT DISPOSAL

This product must be thoroughly cleaned/sterilised prior

to disposal.

This product is manufactured from metal & plastic and

can be disposed of through Local Authority Household

Waste and Recycling Centres or through Local Trade

Waste Collectors.

11. PRODUCT GUARANTEE

NRS Healthcare guarantee this product for a period of

12 months, from the date of purchase, against faulty

materials and workmanship.

This guarantee does not cover; abuse, misuse,

interference or tampering with any part of the product.

Any guarantee issued by NRS Healthcare does not

aﬀect your statutory rights.

N53909-UI-4 28-06-2022

NRS HEALTHCARE Sherwood House, Cartwright Way, Forest Business Park

Bardon Hill, Coalville, Leicestershire, LE67 1UB, UK.

Tel: Customer Services: 0345 121 8111 Email: [email protected]
