3Com HomeConnect Bedienungsanleitung

http://www.3com.com/

HomeConnectTM Cable

Modem External with

USB Getting Started

Guide

Part No. 10039995

Published Sept. 2000

3Com Corporation

3800 Golf Rd.

Rolling Meadows, IL

60008

No part of this documentation may be reproduced in any form or by any means or used to make any

derivative work (such as translation, transformation, or adaptation) without written permission from

3Com Corporation.

3Com Corporation reserves the right to revise this documentation and to make changes in content

from time to time without obligation on the part of 3Com Corporation to provide notification of such

revision or change.

3Com Corporation provides this documentation without warranty of any kind, either express or

implied, including, but not limited to, implied warranties of merchantability, and fitness for a particular

purpose. 3Com may make improvements or changes in the product(s) and/or the program(s) described

in this documentation at any time.

If there is any software on removable media described in this documentation, it is furnished under a

license agreement included with the product as a separate document, in the hard copy documentation,

or on the removable media in a directory file named LICENSE.TXT or !LICENSE.TXT. If you are unable to

locate a copy, please contact 3Com and a copy will be provided to you.

UNITED STATES GOVERNMENT LEGEND

If you are a United States government agency, then this documentation and the software described

herein are provided to you subject to the following:

All technical data and computer software are commercial in nature and developed solely at private

expense. Software is delivered as “Commercial Computer Software” as defined in DFARS

252.227-7014 (June 1995) or as a “commercial item” as defined in FAR 2.101(a) and as such is

provided with only such rights as are provided in 3Com’s standard commercial license for the Software.

Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov. 1995) or

FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or deface any portion of

any legend provided on any licensed program or documentation contained in, or delivered to you in

conjunction with, this User Guide.

3Com and the 3Com logo are registered trademarks, and HomeConnect and Connections are

trademarks of 3Com Corporation.

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the US

and/or other countries. Macintosh is a registered trademark of Apple Computer, Inc.

All other company and product names may be trademarks of their respective companies.

All specifications are subject to change without notice.

CONTENTS

1BEFORE YOU BEGIN

Introduction 1

Cable Modem Features 1

Contacting Your Local Cable Service Provider 2

Preparing Your Workspace 3

You Will Need These Items 4

Supplied 4

Also Needed 4

2USB INSTALLATION

Deciding Which Installation Process to Use 5

Using USB with the Windows 98 Operating System 5

Using the Cable Connections™CD 12

Uninstalling the Cable Modem (Windows 98 Operating

System Only) 12

Using USB with the Windows 2000 Operating System 13

Using the Cable Connections CD 17

Uninstalling the Cable Modem (Windows 2000 Operating

System Only) 17

Using USB with the Windows Me Operating System 18

Uninstalling the Cable Modem (Windows Me Operating

System Only) 22

Using the Cable ConnectionsCD 23

Troubleshooting the USB Installation 23

USB Connection Illustration 27

3ETHERNET INSTALLATION

Deciding Which Installation Process to Use 29

Setting Up the Computer to Use an Ethernet Connection 29

Configuring the TCP/IP Protocol 30

Connecting the Cable Modem 36

Using the Cable ConnectionsCD 37

Troubleshooting the Ethernet Installation 38

Ethernet Connection Illustration 42

4CABLE MODEM OPERATION

Interpreting The Cable Modem’s LEDs 43

LEDs on the Front of the Modem 43

LED on the Back of the Modem 44

Connectors and Switches on the Back of the Cable Modem 45

5THE 3COM CABLE MODEM CONNECTION CENTER

Accessing the Home Page 47

Username and Password 48

Registration Indicators 48

Overview of the Connection Center’s Pages 48

Cable Company 48

User Equipment 48

Cable Modem 49

Diagnostic 52

Change Password 52

6SUPPORT RESOURCES

Support Resources 53

World Wide Web 53

90-Day Free Installation Support 53

Technical Support Hotline 53

If You Are Still Having Problems 53

If You Need to Return the Modem to Us 54

7REGULATORY INFORMATION AND LIMITED WARRANTY

Manufacturers Declaration of Conformity 55

FCC Declaration of Conformity 55

FCC Class B Statement 55

FCC Notice: Radio and Television Interference 56

C-UL/UL Listing: 57

Canadian Notice: 57

INTERNATIONAL DECLARATION OF CONFORMITY 58

Electromagnetic Compatibility 58

Safety (Low Voltage Directive) 58

Special Notes: 59

Japan 59

Performance Specifications 59

Export Notices 59

License Agreement 59

3Com Corporation Limited Warranty 60

Hardware 60

Software 60

Year 2000 Warranty 61

Obtaining Warranty Service 62

WARRANTIES EXCLUSIVE 63

LIMITATION OF LIABILITY 63

Disclaimer 64

Governing Law 64

1BEFORE YOU BEGIN

Introduction

You have just purchased a modem featuring a pioneering

new technology, making Internet access possible at speeds

previously only imagined. This external cable modem is one

part of a comprehensive communications system that

utilizes the cable television network to deliver high-speed

data to your computer. Data is requested and sent over the

cable television network at burst rates of up to 38

megabits per second (Mbps)*. This chapter explains how to

prepare your computer system for cable modem

installation.

* Actual speeds will vary depending on computer

hardware, applications, service offered by your cable

service provider, and network traffic.

Cable Modem Features

■Cable line bandwidth allows user data rates of up to 38

megabits per second (Mbps)*, faster than 56K analog

modems, ISDN, or ADSL.

■Two-way design means that the cable modem both

sends and receives data over the cable line.

■Plug-and-play USB operation ensures easy setup and

installation.

■DOCSIS-compliance ensures interoperability with cable

suppliers.

■3Com’s extensive technical support organization

provides you with the quick answers you need to get up

and running.

* NOTE: Please note that the following factors affect the

speeds you may experience: (1) your computer equipment

and configuration, including the speed of your processor,

the amount of RAM on your system, and your available

2CHAPTER 1: BEFORE YOU BEGIN

hard disk space; (2) applications running simultaneously

with the modem which use varying amounts of your

computer’s resources; (3) the capacity of the Internet

service you order from your provider; (4) the level of

network traffic, which varies depending on when and

where you go online.

Contacting Your Local Cable Service Provider

In order to use your cable modem, you need to set up an

Internet access account with your local cable service

provider.

Before contacting your provider to set up an account, have

the following information handy:

■The modem’s serial number. The serial number appears

on the white bar code label on the back of the modem

and consists of 10 characters preceded by the text

“SN=”. In the following example label image, the serial

number is 6LZ1377410.

■Media Access Control (MAC) address. The MAC address

appears on the white bar code label on the back of the

modem and consists of 12 characters preceded by the

text “EA =”. In the following example label image, the

MAC address is 00104B377410. Write both of these

numbers in the following blanks for future reference.

Serial number: SN= __________________

MAC address: EA = __________________

You should now contact your local cable service provider

and verify that:

■The cable service to your home supports two-way

cable modem access. If your cable service provider

does not provide two-way service, this modem will not

Preparing Your Workspace 3

be able to communicate with your cable service

provider’s Internet access service. You should

immediately consult your cable service provider and

place of purchase to determine the proper 3Com®cable

modem to use. You can also visit the following URL for

additional information:

http://www.3com.com/cablemodem

■You have a cable line near your PC and it has been

prepared for cable modem service. If you do not

have a cable line in your home that supports two-way

cable modem access, or if your current cable connection

is not conveniently located near your computer, your

cable service provider can install one. If you use your

current cable line for cable television access, your cable

service provider can also install an additional line for use

with your cable modem.

■Your cable service provider has set up your cable

Internet access account. Your cable service provider

willset up an Internet access account that will allow you

to send and receive e-mail, access the World Wide Web,

and receive other Internet services. This account must

be set up before you can use your cable modem.

Preparing Your Workspace

■Position your computer so that it is located near the

wall cable outlet.

■Position the cable modem so that it is located near the

computer and the wall cable outlet. There should be

plenty of room to guide the cables away from the

modem without crimping them.

■Do not restrict the airflow around the modem.

■Ensure that the temperature in the room where the

cable modem will be operating is between 0 and 40°C

(32 and 104°F). Relative humidity should be between

5% and 90%, non-condensing.

■Familiarize yourself with all of the materials supplied

with the modem. Please read these installation

instructions thoroughly before installing the modem.

4CHAPTER 1: BEFORE YOU BEGIN

CAUTION: Your cable service provider will provide a cable

connection. Do not attempt any rewiring without first

contacting your cable service provider.

You Will Need These Items

Supplied

■Cable modem

■Cable modem power adapter

■Ethernet cable

■USB cable

■This Getting Started Guide

■The Cable ConnectionsTM CD, which contains:

■The software drivers necessary for installation using

the USB port

■Valuable free software products

See “Using the Cable Connections CD”for more

information.

Also Needed

■To use the cable modem’s USB port:

■A PC running Windows®98, Windows 2000, or

Windows Me operating system. The USB setup does

not support the Macintosh®operating system.

■An active USB port on your computer.

■To use the cable modem’s Ethernet port:

■A PC running Windows 95 (or later), or a Macintosh

computer running System 7.6 (or later).

■An active Ethernet port on your computer.

■TCP/IP protocol installed. See the following chapter

for more information on installing the TCP/IP

protocol.

■Windows 95/98/2000/Me CD or diskettes.

■An active two-way cable line.

■An adjustable wrench for securing the cable line to the

modem.

Inhaltsverzeichnis

Andere 3Com Modem Handbücher

3Com

3Com 000839-08 Bedienungsanleitung

3Com

3Com Impact External ISDN Modem Programmierhandbuch

3Com

3Com OfficeConnect 3C892A Bedienungsanleitung

3Com

3Com CMX 3CR292-DE56 Bedienungsanleitung

3Com

3Com 3C16720 Bedienungsanleitung

3Com

3Com 56K Winmodem Bedienungsanleitung

3Com

3Com Cable Modem External Bedienungsanleitung

3Com

3Com HomeConnect 3CP4130 Bedienungsanleitung

3Com

3Com OfficeConnect 3CR29210 Bedienungsanleitung

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router Gebrauchsanweisung

3Com

3Com 8R-002700-00 Bedienungsanleitung

3Com

3Com U.S. Robotics 56K Voice Bedienungsanleitung

3Com

3Com U.S. Robotics 56K Voice Bedienungsanleitung

3Com

3Com EtherLink 3C900B Bedienungsanleitung

3Com

3Com U.S. Robotics 56K Voice Bedienungsanleitung

3Com

3Com 3C892 - OfficeConnect ISDN Lan Modem Router Bedienungsanleitung

3Com

3Com ADSL Modem Ethernet Bedienungsanleitung

3Com

3Com OfficeConnect 3C891A Bedienungsanleitung

3Com

3Com Courier Service-Handbuch

3Com

3Com HomeConnect 3CR29221 Bedienungsanleitung

3Com

3Com 005683-00 - Bedienungsanleitung

3Com

3Com OfficeConnect 3C886A Bedienungsanleitung

3Com

3Com HomeConnect 3CP3647 Bedienungsanleitung

3Com

3Com 3CP5610A - U.S. Robotics 56K V90 PCI Performance Pro Faxmodem... Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
