3Com 3C16411 - Baseline Dual Speed Hub Bedienungsanleitung

Fast and reliable shared connectivity

Ideal for legacy connections, these Dual

Speed Hubs are designed for networks and

applications where shared connectivity is

needed. The standard 1 RU form factor

allows these products to be easily installed

in standard rack systems incorporating

extended systems and solutions (for

example, data storage NAS and SAN

systems). Alternatively, the units can

operate free standing using the supplied

rubber feet.

Plug and play operation

Unmanaged operation and fast

boot-up means connectivity can be

achieved within minutes. As all ports auto-

negotiate to the right speed (10 or 100), all

is needed is to power up the unit and

connect the end stations. Also, the built-in

MDI/MDIX port and manual switch can be

used to daisy chain hubs together without

the need for cross over cables.

Ultra reliability

As with all 3com®products, Baseline hubs

feature sturdy design and construction,

which pays off in high reliability and log

service life.

3COM BASELINE DUAL SPEED HUB 16-PORT 3COM BASELINE DUAL SPEED HUB 24-PORT

3Com Order Number 3C16410 3C16411

10BASE-T/100BASE-TX ports 16 24

LED Indicators Power, network traffic, collisions, LAN segment Power, network traffic, collisions, LAN segment

MDI/MDIX port Port 16, with manual switch Port 24, with manual switch

Telephone Support and ✓✓

3 Year Hardware Warranty

Key Benefits

3Com®Baseline Dual Speed Hubs

•Designed for networks and

applications where shared

connectivity is needed

•Plug-and-play operation and

fast boot-up means connectivity

can be achieved within minutes

•High reliablity

DATA SHEET

3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064

To learn more about 3Com solutions, visit www.3com.com. 3Com is publicly traded on NASDAQ under the symbol COMS.

Corporation. All other company and product names may be trademarks of their respective companies. While every effort is

made to ensure the information given is accurate, 3Com does not accept liability for any errors or mistakes which may arise.

Specifications and other information in this document may be subject to change without notice. 400851-002 09/04

Specifications 3C16410 (16-port)

3C16411 (24-port)

Physical

Width: 440 mm (17.3 in)

Depth: 173 mm (6.8 in)

Height: 44 mm (1.7 in)

Weight: 2.1 kg (5 lb)

Interfaces

16/24 RJ-45 Ethernet

LED Indicators

Power, network traffic, collisions, LAN segment

Functional

ISO 8802-3, IEEE 802.3 (Ethernet), IEEE 802.3u (Fast

Ethernet)

Electrical

Power inlet: IEC 320

AC line frequency: 50/60 Hz

Input voltage: 100-240 VAC

Current rating: 1A (max)

Maximum power consumption: 3C16410 - 25W,

3C16411 - 42W

Maximum power dissipation: 3C16410 - 86 BTU/hr,

3C16411 - 142 BTU/hr,

Safety

UL 1950, EN 60950, CSA 22.2

#950, IEC 60950

Emissions

EN 55022 Class A, FCC Part 15

Subpart B Class A, ICES-003

Class A, VCCI Class A, AS/NZS 3548 Class A, CNS

13438 Class A

Immunity

EN 55024

Environmental

Operating temperature:

0° to 50°C (32° to 122°F)

Humidity: 10 to 90% (non-condensing)

Standard: EN 60068 (IEC 68)

3COM®BASELINE DUAL SPEED HUBS DATA SHEET

Ordering Information PRODUCT DESCRIPTION 3COM SKU

3Com Baseline Dual Speed Hub 16-port 3C16410

3Com Baseline Dual Speed Hub 24-port 3C16411

All Baseline hubs include:

• Plug and play simplicity

•No configuration required

•Compact 1RU high box

•Easy installation and upgrade Rack mounting kit

•Operates free-standing or 19-inch rack-mounted

Hardware Warranty

3 Year Hardware Warranty. For more information, refer to www.3com.com.
