3Dfactories Profi 3D Maker Bedienungsanleitung
1
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
Thank you for purchasing our 3D printer
Before any manipulation with the printer please carefully
read this user guide
U S E R ‘ S G U D E
T Y P E : P R O F 3 D M A K E R
T Y P E : P R O F 3 D M A K E RT Y P E : P R O F 3 D M A K E R
T Y P E : P R O F 3 D M A K E R
2
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
Content
1.
IMPORTANT SAFETY NOTICE ..................................................................................................................................................3
2.
PACKAGE CONTENTS ..............................................................................................................................................................4
3.
DESCRIPTION OF PARTS ..........................................................................................................................................................5
4.
MINIMUM PC REQUIREMENT ................................................................................................................................................6
5.
INSTALLATION G3DMAKER .....................................................................................................................................................6
6.
CONNECTION .........................................................................................................................................................................6
7.
USB DRIVER INSTALLATION ....................................................................................................................................................7
8.
G3DMAKER SETTINGS .......................................................................................................................................................... 1
9.
BEFORE FIRST PRINT............................................................................................................................................................. 11
9.1.
F
EW STEPS EFORE FIRST PRINT
..........................................................................................................................................................11
9.2.
Z
AXIS CALI RATION
.........................................................................................................................................................................11
9.3
INTRODUCTIONS OF FILAMENT
............................................................................................................................................................12
9.4.
H
OW TO USE
3
D GLUE
.....................................................................................................................................................................13
1 .
REMOVING MODEL FROM THE PLATFORM ...................................................................................................................... 14
11.
G3D MAKER PRINT SETTINGS ........................................................................................................................................... 14
11.1.
F
UNCTIONS
..................................................................................................................................................................................14
11.2.
LOAD MODEL
................................................................................................................................................................................15
11.3.
W
ORK WITH MODEL
......................................................................................................................................................................15
11.3
P
RINT PARAMETERS
........................................................................................................................................................................15
12.
ADVANCED PRINTING SETTINGS ...................................................................................................................................... 16
12.1.
C
OMMON SETTINGS
......................................................................................................................................................................16
12.2.
C
OOLING
.....................................................................................................................................................................................17
13.3.
S
PEED
.........................................................................................................................................................................................17
12.4.
A
DVANCED
..................................................................................................................................................................................18
12.5.
M
ATERIAL EDITOR
.........................................................................................................................................................................19
13.
MAINTENANCE ................................................................................................................................................................ 19
13.1.
S
HAFT LU RICATION
......................................................................................................................................................................20
13.2.
N
OZZLE CLEANING
.........................................................................................................................................................................20
14.
PROBLEM SOLVING .......................................................................................................................................................... 2
14.1.
N
OZZLE TOO LOW
.........................................................................................................................................................................20
14.2.
N
OZZLE TO HIGH
...........................................................................................................................................................................20
14.3.
L
OW AMOUNT OF MATERIAL
...........................................................................................................................................................21
14.4.
R
ETRACT
.....................................................................................................................................................................................22
14.5.
M
ODEL ACCURACY
........................................................................................................................................................................22
14.6.
O
UT OF MEMORY
..........................................................................................................................................................................22
3
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
1. IMPORTANT SAFETY NOTICE
1. CAUSING DAMAGE A 3D PRINTER DUE TO FAILURE OF FOLLOWING INSTRUCTION IN THIS USER MANUAL,
EXPIRING THE WARRANTY VOID.
2. SECOND MATERIAL FOR DAMAGES AND PERSONAL INJURY CAUSED BY THE PRINTER MISAPPLICATION IN
VIOLATION OF THIS USER'S MANUALS OR FAILURE TO SAFETY REGULATIONS IS FULLY RESPONSIBLE USER OF THIS
DEVICE.
3. RISK OF A POSSIBLE BURNS CAUSED BY THE ACCIDENT! BE CAREFUL!
4. THIS DEVICE IS NOT TOY! KEEP AWAY FROM CHILDREN!
5. NEVER LEAVE EQUIPMENT WORK WITHOUT SUPERVISION!
6. CAUTION HOT ITEMS ABOVE 7 ° C! RISK OF BURNS!
7. PERSONS WHO ARE NOT ABLE TO MENTALLY OR MOTORIZED EQUIPMENT FULLY OPERATE, MAY OPERATE THIS
DEVICE ONLY UNDER THE SUPERVISION OF A COMPETENT PERSON.
8. BEFORE USING MAKE SURE THAT THE PRODUCT IS COMPLETE.
9. RISK OF ELECTRIC SHOCK.
10. DEVICE MAY OPERATE AT LEAST 18 YEARS OF AGE, OTHERWISE UNDER ADULT SUPERVISION.
11. DEVICE MAY NOT BE DISPOSED OF VIA STANDARD WASTE.
PRINTER CAN BE ONLY IN A PLACE THAT IS:
• DRY WITHOUT DUST
• STABLE
• GOOD VENTILATION
• NEAR AN EASILY ACCESSIBLE POWER OUTLET
• AWAY FROM OBJECTS THAT MIGHT BLOCK THE VENTILATION HOLE OF THE PRINTER AT A SAFE DISTANCE FROM
FLAMMABLE OBJECTS (EG CURTAINS) AWAY FROM SPLASHING LIQUIDS, AWAY FROM ORGANIC GASES (SUCH
AS AMMONIA)
• AWAY FROM DIRECT SUNLIGHT
• SEVERE TEMPERATURE FLUCTUATIONS
• AWAY FROM OUTLETS HEATING, VENTILATION AND AIR CONDITIONING SYSTEMS
4
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
2. PACKAGE CONTENTS
1X 3D p
rinter PROFI
3
DMAKER
1
X CD
1
x Allen key
1
x
3
D glue
2
X power source
1
x Spatula
1
X US
5
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
3. DESCRIPTION OF PARTS
Extruder
Axis Y
Axis X
Axis Z
Print bed
6
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
4. MINIMUM COMPUTER REQUIREMENT
- CPU 2,8Ghz
- RAM1G
- Intel HG Graphics or better
- HDD 50G
- CD ROM
- US port
- Windows XP and newer
- Screen resolution 1200x800
5. INSTALLATION OF G3DMAKER
Put CD into CR ROM and open it.
There you can find installation for G3D MAKER. Choose installation for your system (32 bit or 64 bit ).
Double click and follow instruction. Together is G3DM is installed windows visual studio. If you have newer version
installation will tell you and you can skip this part of installation.
CD contents NetFabb studio, this is power instrument for repair of STL files. Install it also for check and repair STL.
6. CONNECTION
The printer is connected to computer via US cable (included in the package). The printer has two adapters 24W
7.5A for heating bed and 5A for printer. The higher jack is for heating bed. The lower is for other function of printer.
Switch
Print bed
24
V
7.5
A
US
Printer
24
V
5
A
7
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
7. USB DRIVER INSTALLATION
Connect the printer to the computer and switch printer on.
Some operation system will install US driver automaticly. Or ask you for driver. Than link the OS to the folder on CD
"../drivers US /FTDI US drivers".
If the driver is not installed automaticly or OS does not ask you for link of the driver install it manually.
Windows:
8
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
Click right mouse on US serial port or on icon with warning triangle.
Choose actualize driver software and link to the CD driver folder.
9
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
10
Version 1/2013
© Aroja s.r.o. 2013
www.
3
dfactories.com
8. G3DMAKER settings
Start G3DMAKER. First time the software will control if is on server some actualization. If is, download and installation
will run automatically.
After this the program will start and you can configure it.
You will see this window:
efore first start of printer click on printer setting icon.
Choose COM port
TOP point
Heated print bed yes/no
Stop button actions
If have printer heated bed you can
set preheat temperature.
Choose COM
printer
