808audio HEXSL2 SP892 Bedienungsanleitung
QUICK START
GUIDE
Instructions en français............ 9
Instrucciones en español......... 17
HEXSL
WIRELESS SPEAKER
SP892 QSG 03
2
Back
Make sure the following
items came in this package.
Step 1: Unpack
HEX SL2
Wireless Speaker
Micro-USB
charging cable
Before you start using the speaker for the first time, it’s a
good idea to charge it completely.
Step 2: Charge the Speaker
To charge the speaker: Plug the
included micro-USB charging cable into
DC IN jack on the back of the speaker.
Plug the other end of the USB charging
cable into a power source, like a
computer or a USB charging adapter.
The charging indicator on the back of
the speaker is red while the speaker
is charging. It turns green when the
speaker is fully charged.
3
Step 3: Turn on
Press and hold the button on the
front of the speaker. The speaker
makes its power-up sound and the
indicator light starts on the front of
the speaker starts blinking.
After a few seconds, the speaker
goes to Bluetooth pairing mode to
set up with your smartphone.
Enable Bluetooth on your
smartphone or other device.
Step 4: Pair + Connect
Wi-Fi
Bluetooth
Bluetooth Settings
VPN Settings
Wi-Fi Settings
8:45PM
Make sure the indicator light
on the front of the speaker is
blinking rapidly. (If it isn’t, give
a short double-press on the
button. The speaker gives an
audio signal.)
Continues on the next page...
Front
4
If you’ve previously paired your phone or other Bluetooth device with this
speaker, the speaker will automatically attempt to reconnect to that device
when you turn it on. If you want to pair to a new device, give a short double-
press to the speaker’s button. The speaker gives an audio signal and its
indicator light starts blinking.
Choose 808 SL2 from the pairing options on your
smartphone. (If it’s not in the list, choose “Scan” from your
phone’s Bluetooth menu.)
The speaker gives an audio signal when it’s finished pairing
and connecting to your smartphone. Its indicator light turns
solid blue.
Note: The process of enabling Bluetooth and connecting varies from device
to device. See your device’s owners manual for more information and specific
instructions.
Bluetooth Wireless Connection Tips
•Make sure the Bluetooth capability of your device is turned on.
•Make sure there’s nothing plugged into the speaker’s AUX IN jack when you’re
trying to use Bluetooth.
• The Bluetooth wireless connection works up to a range of roughly 33 feet (10
meters). This range may vary, however, based on other factors, such as room
layout, wall material, obstacles, your device’s Bluetooth performance, etc. If
you’re having problems connecting to this speaker, move closer to it.
•If your device asks you for a password to connect, use “0000”.
•If you’ve paired your device with the speaker before but you’re having trouble
reconnecting when you turn the speaker back on, give a short press to the
button while the indicator light on the front of the speaker is flashing. The
speaker will attempt to connect to a previously paired device.
5
To adjust the volume of your audio: Press the + and –
buttons on the front of the speaker (or use the volume
controls on your phone).
Set your device’s volume for music
to 50%.
Note: This is to make sure the sound from the
speaker isn’t too loud when you start streaming.
Start playing music or other audio
on your device. Within seconds, the
speaker starts streaming the audio
wirelessly via Bluetooth.
Step 5: Play music
8:45PM
Now playing
Media volume
8:45PM
Controlling Playback from the speaker
If you’re playing music via Bluetooth, it’s easy to play/
pause and skip tracks from the speaker.
To play/pause: press once on the speaker’s button.
To skip forward: press and hold the speaker’s +button.
To skip backwards: press and hold the speaker’s –
button.
6
If your paired smartphone features a virtual assistant, like
Siri or Google Assistant, you can use these features with
the SL2 speaker.
To use a virtual assistant from the speaker: Press and
hold the button on the front of speaker until you hear
an audio signal from the assistant (like a double beep
from Siri). Then speak normally (toward the speaker). Your
phone will respond through the speaker.
IMPORTANT: Your phone must be paired and connected to
the speaker in order for this to work!
To use Siri or Google Assistant from your phone: Invoke
Siri or Google Assistant from your phone as you normally
would. Then speak normally (toward the speaker). Your
phone will respond through the speaker.
Using Siri® and Google Assistant™
You can answer, conduct, and end calls from your paired
phone through the SL2 speaker, like a speakerphone.
To answer the call from the speaker: Press the button
on the front of speaker and speak normally (toward the
speaker).
To end the call from the speaker: Press the button on
the front of speaker.
IMPORTANT: Your phone must be paired and connected to
the speaker in order for this to work!
Using the speaker as a speakerphone
7
Tour of the 808 SL2
Front
– / + decrease or increase
the volume of the speaker’s
audio. They also skip forward
or backward (press and hold)
when audio is playing via Bluetooth.
The button has four functions:
• it turns the speaker on and o (press and hold)
• it puts the speaker into pairing mode (short double-
press when the speaker’s on) to connect to a new
Bluetooth device
• it attempts to reconnect to the last paired device
(short single-press when the speaker’s on)
• it plays/pauses playback when audio is playing via
Bluetooth
The button answers and ends phone calls through your
paired phone (press). It also engages voice services on
paired phones that oer these services (press and hold).
Bluetooth indicator shows the Bluetooth status of the
speaker:
• fast blinking blue while pairing
• slow blinking blue while reconnecting
• solid blue when paired
• solid white when the AUX IN jack is in use
Indicator light
Microphone
8
Back
Charging indicator shows
the charging status of the
speaker:
• red when the speaker’s
charging
• green when the speaker’s
fully charged.
Siri is a registered trademark of Apple Inc.
Google Assistant is a trademark of Google, Inc.
All other trademarks are the property of their respective owners.
Charging indicator
DC IN jack connects to the provided micro USB charging
cable to recharge the speaker’s battery.
AUX IN jack lets you connect an audio device directly to the
speaker using a 3.5mm audio cable.
Turning the 808 Sounds On and O
(Silent Mode)
The 808 Hex SL2 speaker provides status/alert sounds when you
turn the speaker on and o, as well as when you’re pairing.
To turn status/alert sounds on/o: press and hold the + and –
buttons on front of the speaker (while it’s on) until the speaker
beeps twice.
9
GUIDE DE
DÉMARRAGE
RAPIDE
Instructions in english............... 1
Instrucciones en español......... 17
HEXSL
HAUT-PARLEUR
SANS FIL
10
Dos de
l’appareil
Vérifier que les articles suivants
sont inclus dans l’emballage.
Étape 1 : Déballer
Haut-parleur sans fil
HEX SL2
Câble de recharge
micro-USB
Avant de commencer à utiliser le haut-parleur pour la première fois,
il est conseillé de le charger complètement.
Étape 2 : Charger le haut-parleur
Pour charger le haut-parleur : Brancher le
câble de chargement micro-USB inclus dans la
prise DC IN située à l’arrière du haut-parleur.
Brancher l’autre extrémité du câble de charge-
ment USB sur une source d’alimentation,
comme un ordinateur ou un adaptateur
chargeur USB.
Le voyant de charge à l’arrière du haut-parleur
est rouge pendant la charge. Il devient vert
lorsque le haut-parleur est complètement
chargé.
