A&D HJ-150 Bedienungsanleitung

HJ-150 Compact Scale

Operating Instructions

Cautions

GAvoid installing / leaving the scale in direct sunlight / high humidity.

GPlace the scale on a flat and solid surface in a place free from wind.

GAvoid vibration, strong electric or magnetic fields and rapid changes in

temperature or humidity.

GAvoid using the scale near other electronic equipment.

GDo not mix the battery types. Replace all of the batteries at same time.

GIf the scale is not to be used for a long period of time, remove the

batteries.

GAvoid over / shock load that could cause damage to the scale.

GKeep the protective cover attached when you carry the scale.

GWait for more than 6 seconds to let the scale warm up after turning on

the power.

GWhen the location to be used or the ambient environment has

changed, calibrate the scale before use.

Specifications

Capacity 150 x 0.1 g / 5.29 x 0.01 oz

Display 7 segment LCD with backlight (Character height 8 mm)

Power 2 x “AAA” size batteries

Pan size 60 (W)x 64 (D) mm / 2.36 (W) x 2.52 (D) in.

Accessories Instruction manual, 100g weight, 2 monitor batteries

LCD LIGHT/CAL

Weighing pan

ON/ZERO/OFF

Protective cover

Battery cover

g / oz

Open

Battery +

Switches

ON/ZERO/OFF Switch:

Press to turn the scale on. In the operation mode, press briefly to set

the display to zero. Press and hold approximately 3 seconds to turn

the scale off.

LIGHT/CAL Switch:

In the operation mode, press briefly to turn the LCD backlight on.

Press and hold approximately 3 seconds to enter the calibration mode.

g / oz Switch:

In the operation mode, press the switch located on the bottom of the

scale to change the weighing unit between “g” and “oz”.

Installing / Replacing batteries

Remove the battery covers and insert 2 AAA size batteries into each

housing, taking care with the polarities. Attach the battery covers again.

GKeep the protective cover attached when installing and/or replacing

batteries, to prevent excessive force from being added to the

weighing pan.

Weighing procedures

1. Turn on / off the scale

Press the ON/ZERO/OFF key to turn on the scale. The scale shows

all segments for a few seconds and displays zero. The backlight will turn

on for about one minute. Press and hold approximately 3 seconds to

turn the scale off.

2. Select the weighing unit

Press the g / oz switch to select a weighing unit from “g” and “oz”.

3. Weighing

Verify the reading is zero. If not, press the ON/ZERO/OFF key to

zero the display. If you use a container for weighing, place an empty

container on the weighing pan and press the ON/ZERO/OFF key to

zero the display.

Place the objects to be weighed on the pan or in the container. Wait for

the display to become stable and read the weight.

Gaeaa means overload. Remove the objects from the pan immediately.

Automatic power-off function

The automatic power-off function turns power off after approximately 2

minutes of stable display during the object(s) applied. When there is no

object applied, it will turn off after 30 seconds.

Calibration

1. Make sure that there is nothing on the weighing pan, press and hold

the LIGHT/CAL key approximately 3 seconds. The display shows

Cal . Release the key.

2. The scale memorizes the zero point and automatically displays

100.0 g.

3. Place the calibration weight of 100g on the center of the pan within 10

seconds.

4. After approximately 8 seconds, the scale will display ffor

success and efor failure. Then, the scale automatically turns off.

5. Turn the scale on again to start the operation.

GIf calibration fails, check if anything is touching the weighing pan,

there is vibration or wind, and the calibration weight is correct.

Dimension

(mm)

Scale Protectivecover

20.3

66 70

3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013 JAPAN

Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-6148

A&D ENGINEERING, INC.

1555 McCandless Drive, Milpitas, CA. 95035 U.S.A.

Telephone: [1] (408) 263-5333 Fax: [1] (408) 263-0119

A&D INSTRUMENTS LTD.

Unit 24/26 Blacklands Way Abingdon Business Park, Abingdon, Oxon OX14 1DY U.K.

Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485

Große Straße 13b 22926 Ahrensburg GERMANY

Telephone: [49] (0) 4102 459230 Fax: [49] (0) 4102 459231

A&D MERCURY PTY. LTD.

32 Dew Street, Thebarton, South Australia 5031 AUSTRALIA

Telephone: [61] (8) 8301-8100 Fax: [61] (8) 8352-7409

A&D KOREA Limited

Manhattan Bldg. 8F, 36-2 Yoido-dong, Youngdeungpo-gu, Seoul, KOREA

Telephone: [82] (2) 780-4101 Fax: [82] (2) 782-4280

WM+PD4000995
