Abus FUMK50020 Bedienungsanleitung

FUMK50020

Secvest mini wireless opening detector

Version 1.0

390350

09-2014

Installation instructions

Mini wireless opening detector

- 16 -

- 17 -

Contents

Preface...........................................................................- 18 -

Battery warning information........................................- 19 -

Safety information........................................................- 19 -

Scope of delivery..........................................................- 20 -

Technical data...............................................................- 20 -

Start-up..........................................................................- 21 -

Assign the detector in zones.......................................- 21 -

Range.............................................................................- 22 -

Installation location......................................................- 22 -

Installation.....................................................................- 24 -

Changing the battery....................................................- 27 -

- 18 -

Preface

Dear customer,

Thank you for purchasing this mini wireless opening detector. This device is built

with state-of-the-art technology and complies with current domestic and European

regulations. Conformity has been proven, and all related certifications are available

from the manufacturer on request (www.abus.com). To guarantee safe operation, it

is essential that you observe these installation instructions. If you have any

questions, please contact your specialist dealer.

This mini wireless opening detector is used to monitor doors and windows. It

wirelessly monitors the status (open/closed) of a door or a window and reports this

to a wireless alarm panel.

This device complies with the requirements of the following EU directive: 1999/5/EG

directive regarding wireless systems and telecommunication transmitters and the

mutual recognition of their conformity.

IMPORTANT

Please observe the notes and instructions in this user guide! If

you do not follow these instructions, any guarantee claim is

invalidated. No liability can be accepted for resulting damage.

The product may not be changed or modified in any way.

- 19 -

Battery warning information

The device is supplied with direct current from a 3.6 V lithium battery. To guarantee

a long lifespan and avoid fire and injury, please note the following:

Do not dispose of the battery in domestic waste.

The battery may not be directly exposed to heat or sunlight.

The battery may not be burned.

The battery may not come into contact with water.

The battery may not be dismantled, pierced or otherwise damaged.

The battery contacts may not be short-circuited.

The battery must be kept away from small children.

The battery cannot be recharged.

Safety information

No part of the product may be changed or modified in any way. Finger contact with

the motherboard should also be avoided.

Be careful with magnets:

Beware fingers becoming trapped.

Keep the product away from children, as its small parts could be swallowed.

In the event that parts are swallowed, seek medical attention immediately,

especially if the magnet is swallowed.

Magnets may damage credit or debit cards with a magnetic strip.

If you have a pacemaker, defibrillator or any other implanted devices, please bear

the following information in mind: the magnet can have an adverse effect on

devices such as these, so maintain sufficient distance between the magnet and

implanted device (approx. 20 cm), particularly during installation.

- 20 -

Scope of delivery

(1.) Motherboard housing

(2.) Backplate

(3.) Dust cover

(4.) Magnet holder attachment

(5.) 7 mm plate

(6.) Magnet bracket

(7.) Fixing screws

(8.) Battery

Technical data

Power supply: 3.6 V lithium-thionyl chloride

Battery type: SAFT LS1425 (please use this battery type only)

Power consumption: 0.03 A Battery life: up to 36 months

Radio frequency: 868.6625 MHz/FM Housing material: ABS

Dimensions (LxWxH): 33 x 89 x 29 mm Weight: approx. 53 g

Environmental class: I (-10 to +55°C) Security level: II

- 21 -

Start-up

Insert the battery into the wireless

opening detector.

IMPORTAN

Ensure that the

polarity is correct.

Assign the detector in zones

See the relevant device information.

Press the tamper switch (anti-removal

wall contact), until the receiver has

received the signal, indicated by a

beep.

- 22 -

Range

The range is dependent on environmental factors. Check whether the detector is

communicating properly with the alarm control panel prior to assembly.

When assembling the detector:

do not assemble it on or near metal surfaces.

keep it at least 1 m from gas, water or power lines.

do not assemble it near electronic equipment such computers, photocopiers or

other transmitters and interferences.

Installation location

The optimal installation position for your wireless opening detector is the top corner

of your window/door frame or leaf. Make sure that you install the detector on an

even surface so that the tamper switch (anti-removal wall contact) operates reliably.

The wireless opening detector can be installed on either the window frame or the

leaf of the door.

Select the installation position best suited to the individual location:

Rabbet

depth

Window/door

frame

Window/door leaf

7 mm magnet

bracket plate

< 19 mm

magnet/detector

optional

> 19 mm

magnet

detector

compulsory

- 23 -

For window/door frames with a rabbet depth of less than 19 mm and sufficient

space, we recommend installing the wireless opening detector on the

window/door frame.

(Reverse installation is also possible in this instance, however.)

For window/door frames with a rabbet depth of more than 19 mm, the wireless

opening detector must be installed on the leaf of the window/door using the 7 mm

magnet bracket plate.

Prior to installation, always check that the distance between the

detector and the magnet is sufficiently short that the magnet can be

reliably detected by the wireless opening detector.

To test the detector's triggering function, we recommend pre-assembling the

magnetic bracket and detector base temporarily, using the attached adhesive film

but not the screws.

Once you have checked this, we recommend installing the magnet bracket and

detector base using the screws to secure it in place permanently (you do not need to

pre drill the plastic).

You should always check the rabbet depth of the leaf before making any screw

connections and avoid the screws emerging on the opposite side. (If necessary,

screws may be shortened.)

- 24 -

Installation

The following section describes how to install the wireless opening

detector on the leaf of the window or door.

(Installation on a window or door frame follows the same procedure.)

Position and screw on the backplate

The holes for the fixing screws must be aligned in the

direction of the wall (and not aligned with the centre of

the door/window).

Distance from the door/window edge: 10 mm

(Figure shows window with DIN on right; installation

with DIN on left follows the same procedure.)

Attach motherboard housing

Attach the motherboard housing in the correct position

and press this into place.

(Figure shows window with DIN on right; installation

with DIN on left follows the same procedure.)

10 mm
