LS2400

User Manual

800-356-2671 | Accutech | www.AccutechSecurity.com

Version 1.00

- DRAFT -

FCC ID/DOC for the LS2400T Controller:

FCC ID: JM7-HWHY-662110

IC: 2683A-662110

Compliance Statement (Part 15.19)

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may

cause undesired operation.

Warning (Part 15.21)

Changes or modification not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

FCC ID/DOC for the LS2400T Sensor:

FCC ID: JM7-IGWT-662002

IC: 2683A-662002

Compliance Statement (Part 15.19)

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may

cause undesired operation.

FCC ID/DOC for the S-TAD:

FCC ID: JM7-IGWT-662008

Canada IC: 2683A-662008

This device complies with Part 15 of the FCC rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

800-356-2671 | Accutech | www.AccutechSecurity.com

Contents

Chapter 1: LS2400 System

Alarms

How Accutech Systems Work

Addressing Alarms

Escorting

Chapter 2: Tags

Tag barcodes

Visual Pulse LED

Attaching Tags

Tag and Band Maintenance

Chapter 3: The S-TAD

Powering the S-TAD On/Off

Unlocking the S-TAD

Activating/Deactivating Tags

Programming Mode

- DRAFT -

User Manual

Chapter 1:

LS2400 System

IMPORTANT:

No Security System can replace human vigilance. Creating a safe environment requires the

combined efforts of nursing, physicians, security, and patients. Global policies, procedures,

and processes on patient care should be discussed and disseminated. Education,

communication, and coordination are key. No level of security can replace an informed and

knowledgeable staff. Any electronic or physical security system should be considered as a

supplemental deterrent, but by no means an end-all.

- DRAFT -

1-1 The LS2400 System User Manual

The LS2400 System

Alarms

How Accutech Systems Work

Addressing Alarms

Escorting

The function of the LS2400 System is to alert

facility personnel of the possible egress of a

monitored resident.

The LS2400 can be utilized for special care

residents suffering from wandering malady or

tendencies of straying into unauthorized areas or

leaving a facility, pediatric patients, asset

security, and/or infant security. The system is

designed so that each monitored zone is a stand-

alone system.

When a Tag enters a monitored zone, the system

can automatically:

lock doors

deactivate elevators

sound alarms

flash strobe lights

trigger visual displays

Virtually any hallway, doorway, stairwell, or

elevator can be made to sense a Tag and then

trigger audial and/or visual alarms to prompt a

staff response.

By adding options, most egress opportunities

can be eliminated without restricting staff,

visitors, and non-monitored residents movement.

Additional options that further enhance your

ability to prevent unescorted egress include:

Magnetic Lock(s)

Elevator Deactivation Unit(s)

Central Alarm

Loiter Alarm

Door Ajar alarm

Staff Alert Panels (SAPs)

Graphic Displays Panels (GDPs)

- DRAFT -

User Manual The LS2400 System 1-2

Alarms

Egress

Door Ajar (Optional)

Loiter (Optional)

Supervisor

Tamper

NOTE: In this manual, Egress alarms are

referred to as “Alarms.” Other alarm types are

referred to by name (i.e., Door Ajar, Loiter,

Supervisor, Band Alarm).

Egress

An alarm (i.e., an Egress alarm) occurs

whenever a Tag enters a monitored zone and the

door is opened or a PIR is tripped.

Door Ajar (Optional)

A Door Ajar alarm occurs when a door is open

for longer than the preset time (adjustable).

Loiter (Optional)

A Loiter alarm occurs when a Tag lingers in a

monitored zone for longer than the preset time

(adjustable).

Supervisor

A Supervisor alarm occurs when the

performance of the system has been altered due

to tampering or inadvertent acts such as cut

wires, antenna damage, or interference.

Tamper

The LS2400 System cover panel has been

tampered, removed, or obstructed.

How Accutech Systems Work

Double-conditioning

Door zones

Elevator zones

Hallway zones

This section explains how Accutech Systems

react to a Tag entering a monitored door,

elevator, or hallway as well as alarm definitions.

Double conditioning

At most zones, two conditions are required to

generate an alarm. For example, at a door zone,

a Tag must be detected in the zone and the door

opened or, in hallway zones, a Tag must be

detected in the zone and PIR detection to

generate an alarm. Double conditioning (set

during installation) helps prevent nuisance

alarms.

Door zones

When a Tag enters a monitored door zone, the

system will detect the Tag. At that moment

(provided the door is closed, has a Magnetic

Lock(s), and the Lock is unobstructed) the

Magnetic Lock will energize, locking the door.

The Lock will remain locked for as long as the

Tag is in the monitored zone. When the Tag

leaves the monitored zone, the door will unlock

after an adjustable period of time (unless it is set

to latch when an alarm occurs).

Egress

If a Tag enters a monitored door zone with or

without a Magnetic Lock(s) and the door is

already open (or is opened while the Tag is in

the zone), the LS2400 System will go into

alarm.

- DRAFT -

1-3 The LS2400 System User Manual

Loiter

An optional Loiter function is available to alert

staff personnel if a Tag is lingering in a

monitored zone. The time setting is adjustable

(10-110 seconds) and is factory set for

approximately 15 seconds.

Door Ajar

An optional Door Ajar function is also available

to alert staff personnel if the door in a monitored

zone has been held open for too long. The time

range can be set for immediate or from 10 to 110

seconds and is factory set for approximately 15

seconds.

Elevator zones

Elevator Deactivation Circuitry restricts the

wearer of a Tag from using an elevator.

Egress

If a Tag enters a monitored elevator zone, the

elevator’s call button on that floor will be

deactivated (Call buttons on other floors are

unaffected and no one is restricted from coming

to the floor).

When a Tag is in the zone and the elevator doors

are closed, the doors will remained closed.

When a Tag is in the zone (or approaches the

zone) and the elevator doors are open, the doors

will remain open and an alarm will sound.

If the elevator car is en route to the floor when a

Tag approaches the zone, the elevator will arrive

on the floor, the door(s) will open, and the

system will alarm.

Hallway zones

Egress

If a Tag enters a monitored hallway zone, the

system will detect the Tag and the PIR will

detect motion. The system can then sound

alarms, trigger visual displays and, in special

circumstances, lock nearby doors.

Addressing Alarms

Addressing Egress alarms

Addressing Door Ajar alarms

Addressing Loiter alarms

Addressing Supervisor alarms

Addressing Tamper alarms

NOTE:

Whenever an alarm occurs, always go to the

alarm location to address the alarm.

Addressing Egress alarms

An Egress alarm occurs whenever a Tag enters a

monitored zone and the door is opened or a PIR

is tripped.

When an Egress alarm occurs:

1. Go to the alarm location and take

appropriate action.

2. After taking appropriate action, you may

clear the alarm by entering a valid code

into the zone Keypad and, if necessary,

clear the alarm on the PC.

- DRAFT -

Addressing Door Ajar alarms

A Door Ajar alarm occurs when a door is open

for longer than the preset allotted time.

When a Door Ajar alarm occurs:

1. Go to the alarm location and check to

see if the door is propped open or not

completely closed.

2. Close the door completely.

3. The system may automatically reset or,

if necessary, enter a valid code into the

zone Keypad and/or clear the alarm on

the PC.

Addressing Loiter alarms

A Loiter alarm occurs when a Tag lingers in a

monitored zone for longer than the preset

allotted time.

When a Loiter alarm occurs:

1. Go to the alarm location and check the

following:

a. If a person is loitering in that

zone’s Tx Activation Field?

b. Is a Tag from an adjacent room

being activated by this zone? If

so, call your service technician

for help in addressing this issue.

c. Is there is a misplaced Tag in

the zone?

2. After removing the cause, the system

may automatically reset or, if necessary,

enter a valid code into the Keypad

and/or clear the alarm on the PC.

Addressing Supervisor alarms

A Supervisor alarm occurs when the

performance of the system has been altered due

to tampering or inadvertent acts such as cut

wires, antenna damage, or interference.

When a Supervisor alarm occurs:

1. Go to the alarm location and look for

visible damage to the Accutech

equipment.

2. Check for and remove any objects near

the zone equipment that may be causing

interference (metal carts, monitors or

other medical equipment as well as

personnel using wireless communication

devices).

3. If you locate and correct the cause, the

Supervisor alarm will cease. If

necessary, clear the alarm on the PC.

4. If not, call your service technician for

further assistance.

NOTE: Receiver-related supervise

events can be reset by the Keypad for

the duration of the supervise interval.

This will silence the alarm for up to 16

hours.

Addressing Tamper alarms

A Loiter alarm occurs when the LS2400 cover

panel has been tampered, removed, or

obstructed. Inspect the case for proper

installation.

- DRAFT -
