Acer M900 Bedienungsanleitung

Acer M900

Quick Guide

Acer M900 Smartphone Quick Guide2

Acer M900 Smartphone Quick Guide

First issue: March 2009

Acer M900 Smartphone

Model number: __________________________________

Serial number: ___________________________________

Date of purchase: ________________________________

Place of purchase: ________________________________

Acer M900 Smartphone Quick Guide4

Table of Contents

Unpack your smartphone . . . . . . . . . . . . . . . . . . . . . . 7

Get to know your smartphone . . . . . . . . . . . . . . . . . . 8

Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

LED indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Install the SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Open the battery compartment . . . . . . . . . . . . 11

Insert the SIM and replace the battery . . . . . . 11

Remove the SIM card and battery . . . . . . . . . . . . . . 12

Charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Power LED status during charging . . . . . . . . . . 13

Turn on for the first time . . . . . . . . . . . . . . . . . . . . . 14

Install add-on applications . . . . . . . . . . . . . . . . 14

Set up fingerprint security . . . . . . . . . . . . . . . . 15

Enter your PIN code . . . . . . . . . . . . . . . . . . . . . 16

Activating a new SIM card . . . . . . . . . . . . . . . . 16

The Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Before making a call . . . . . . . . . . . . . . . . . . . . . . . . . 19

Make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Connect to your PC and synchronizing data . . . . . . 20

Use the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Use the stereo headset . . . . . . . . . . . . . . . . . . . . . . . 22

Use a Bluetooth headset . . . . . . . . . . . . . . . . . . . . . . 22

Acer M900 Smartphone Quick Guide6

7Unpack your smartphone

Unpack your smartphone

Your Acer M900 Smartphone comes packed in a cardboard

box. Carefully unpack the box and remove the contents. If any

of the following items are missing or damaged, contact your

dealer immediately:

• Acer M900 Smartphone

•Stylus

• Battery

• Quick Start Guide

• Getting Started CD

•USBcable

• AC adapter

• Headset (not shown)

Acer M900 Smartphone Quick Guide8

Get to know your smartphone

Views

No. Item Description

1 Mini USB connector

Connect to a USB cable/headphones/

charger.

2 3-way rocker wheel Scroll through items on the display. Press

inwards to activate the selected item.

3 Micro SD card slot Expand your device’s memory capacity.

4 Video conference

camera

Camera for video calls.

5 Light sensor Senses ambient light to adjust screen

brightness for comfortable viewing.

6 Bluetooth/WLAN/GPS

indicator

Indicates Bluetooth, WLAN and GPS status.

9Get to know your smartphone

7 Phone speaker Emits audio from your smartphone; suit-

able for holding to your ear.

8 Charge indicator Indicates battery charge status.

9 Touchscreen 800 x 480 pixel screen to display data,

phone content and enter information.

10 Talk/send button Activate phone/dial/view recently dialed

numbers/answer a call.

11 End button

Press to end a call/disconnect GPRS; press

and hold to turn the phone function on/off.

12 GPS button Activate the GPS viewer.

13 Back button Return to the Home screen.

14 Fingerprint reader Secure your phone using Biometrics; navi-

gate through items on the screen.

15 Microphone Internal microphone.

16 Stylus Use to enter information or select items

on the touch screen.

17 Power button Press to turn the screen on/off or enter

sleep mode; press and hold to turn the

Smartphone off.

18 Record button Press to launch the recording toolbar.

19 Reset pinhole Insert the stylus into this hole to reset the

device.

20 Camera button Activate the camera or take a picture.

Press down halfway to auto-focus.

21 Speaker Emits audio from your smartphone; suit-

able for handsfree use.

22 Main camera A 5-megapixel camera for taking high-res-

olution images.

23 Flash Used to illuminate an object when taking

photos in low-light conditions.

24 Battery cover Covers the battery/SIM card bay.

25 Lower locking panel Moves up and down to lock the battery

cover in place.

No. Item Description

Acer M900 Smartphone Quick Guide10

LED indicators

Bluetooth/WLAN/GPS indicator:

Charge indicator:

LED

Color

State Description

White Flashing GPS active

Amber Flashing WLAN connected

Blue Flashing Bluetooth on

LED

Color

State Description

Red Flashing Battery is low and needs recharging/alarm

notification (missed call, new message, etc.)

Steady Battery is charging

Green Flashing Phone is active

Steady Battery fully charged
