Acnodes FES 8916 Bedienungsanleitung

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

User Manual

FES8916:FanlessEmbeddedController,6-slotsystemwith

Socket P Intel Core 2 Duo Processor

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

Disclaimers

This manual has been carefully checked and believed to contain accurate information.

Acnodes Corporation assumes no responsibility for any infringements of patents or any

third party’s rights, and any liability arising from such use.

Acnodes does not warrant or assume any legal liability or responsibility for the accuracy,

completeness or usefulness of any information in this document.Acnodes does not make

any commitment to update the information in this manual.

Acnodes reserves the right to change or revise this document and/or product at any time

withoutnotice.

No part of this document may be reproduced, stored in a retrieval system, or transmitted,

in any form or by any means, electronic, mechanical, photocopying, recording, or other-

wise, without the prior written permission ofACNODES CO., Ltd.

CorporationAll Rights Reserved

December 2009, Version A2

Printed in Taiwan

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

1. The FES 8916 does not come equipped with an operating system.An operating system must

be loaded first before installing any software into the computer.

2. Be sure to ground yourself to prevent static charge when installing the internal components.

Use a grounding wrist strap and place all electronic components in any static- shielded devices.

Most electronic components are sensitive to static electrical charge.

3. Disconnect the power cord from the FES 8916 before any installation. Be sure both the sys-

tem and external devices are turned OFF.Asudden surge of power could ruin sensitive compo-

nents that the FES 8916 must be properly grounded.

4. The brightness of the flat panel display will be getting weaker as a result of frequent usage.

However, the operating period varies depending on the application environment.

5. Turn OFF the system power before cleaning. Clean the system using a cloth only. Do not spray

any liquid cleaner directly onto the screen. The FES 8916 may come with or w/o a touch screen.

Although the touch screen is chemical resistant, it is recommended that you spray the liquid

cleaner on a cloth first before wiping the screen. In case your system comes without the touch

screen, you must follow the same procedure and not spray any cleaner on the flat panel directly.

6.Avoid using sharp objects to operate the touch screen. Scratches on the touch screen may

cause malfunction or internal failure to the touch screen.

7. The flat panel display is not susceptible to shock or vibration. When assembling the FES

8916, make sure it is securely installed.

8. Do not open the system's back cover. If opening the cover for maintenance is a must, only a

trained technician is allowed to do so. Integrated circuits on computer boards are sensitive to

static electricity. To avoid damaging chips from electrostatic discharge, observe the following

precautions:

Before handling a board or integrated circuit, touch an unpainted portion of the system unit

chassis for a few seconds. This will help to discharge any static electricity on your body.When

handling boards and components, wear a wrist- grounding strap, available from most electronic

component stores.

SafetyPrecautions

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

Table of Contents

Disclaimers...........................................................................ii

SafetyPrecautions...............................................................iii

Classification.........................................................................iv

GeneralCleaningTips..........................................................iv

ScrapComputerRecycling...................................................vi

CHAPTER 1 INTRODUCTION ....................................... 1

1.1 General Description ........................................... 1

1.2 System Specifications.........................................2

1.2.1 MainCPUBoard.........................................................2

1.2.2 I/OSystem...................................................................2

1.2.3 SystemSpecification..................................................3

1.3 Dimensions ......................................................... 4

1.4 I/OOutlets.............................................................5

1.5 Jumper Settings .................................................. 6

1.6 Packing List ........................................................ 11

CHAPTER 2 HARDWARE INSTALLATION .................. 12

2.1 Installing the Processor......................................... 12

2.2 Installing the Memory Module............................... 15

2.3 Installing the Hard Disk Drive................................ 17

2.4 Installing the PCI Card......................................... 19

CHAPTER 3 DRIVER INSTALLATION ..................... 21

3.1 Starting......................................................................21

3.2 Navigation Keys.......................................................21

3.3 The Main Menu.........................................................22

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

3.4 Advanced BIOS Features..............................................23

3.5 PCI PnP Menu................................................................39

3.6 BootMenu......................................................................41

3.7 SecurityMenu.................................................................44

3.8 ExitMenu........................................................................49

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

CHAPTER 1 INTRODUCTION

This chapter contains general information and detailed specifications of the FES 8916 Chapter 1

includes the following sections:

General Description

System Specification

Dimensions

I/O Outlets

Package List

1.1 General Description

The FES8916 is an fanless system that can support Socket P for Intel® CoreTM 2 Duo/ CoreTM

Duo or Celeron® M processors. The FES8916 supports Windows® XP, ® Windows XP embedded,

vista, and Fedora, suitable for the most endurable operation.

Reliable and Stable Design

The FES8916 adopts an anti-vibration hard-drive bay, which makes it especially suitable for vibra-

tion environments, best for industrial automation, digital signage and gaming application.

Embedded O.S. Supported

The FES8916 not only supports Windows® XP, but also supports embedded OS, such as Win-

dows® XP embedded. For storage device, the FES8916 supports one 2.5" HDD driver bay and

one onboard CompactFlash™ socket.

661 Brea Canyon Rd., Suite 3

Walnut, CA 91789

tel: 909.598.7388, fax: 909.598.0218

are subject to change without notice. For latest product information,

please visit Acnodes’ web site at www.acnodes.com.

FES 8916

Fanless Embedded Controller

1.2 Specifications

1.2.1 Main CPI board

CPU:

Socket P Intel Core 2 Duo/ Celeron M processors

System Chipset: Intel GM45+ICH9M chipset

BIOS:

AMI BIOS, with Smartview and Customer CMOS Backup.

System Memory:

Two 204-pin DDR3 800/1066 MHz SODIMM sockets, with maximum up to 8GB

Features:

-Fanless Operation

-Compact & Front IO design

-Supports four PCI or four PCI & PCIe expansion slots

-DC to DC power supply support 10V to 30V

1.2.2 I/O System

Standard I/O Interface- Front:

-ATX power on/off switch

-10VDC to 30VDC with phoenix power plug or External 150WACAdapter

-Two USB 2.0 ports

-HDD access/power LEDs

-One RS-232(COM2/3/4)

-One RD-232/422/485(COM1)

-One VGA connector

-Two G.E. LAN ports
