Acnodes KD 5170 Einrichtungshandbuch

Rack Mount

LCD-Keyboard Drawer

2U Model Setup and Operating Guide

A Technical Guide for System Integrators

and Service Technicians

The information contained in this document is believed to

be accurate. However, no responsibility is assumed for its

use, nor for any infringements of patents or other rights of

third parties which may result from its use. This information

is subject to change without any notice.

CONTENTS

Introduction ........................................................... 1

Safety Guidelines .................................................. 2

Unpac ing ............................................................. 4

External Views ....................................................... 5

Front View .......................................................................... 5

Side ViewOSD Controls .................................................. 6

Top ViewAudio Components .......................................... 7

Bac ViewConnectors .................................................... 8

System Requirements .......................................... 9

Rac Installation .................................................. 10

Mounting Procedure ........................................................ 10

OSD Controls ...................................................... 14

Using the OSD ................................................................. 15

OSD Menu System .......................................................... 16

Troubleshooting Techniques ............................... 18

Technical Specifications ...................................... 19

Setup and Operating Guide

Introduction

Your Flat Panel Monitor Keyboard Drawer is an integrated

monitor keyboard assembly designed for use with rack

mounted servers. It can be easily set up in a standard 19

equipment rack or cabinet. The monitor keyboard is

mounted on slide rails. The retractable assembly occupies

only 2U space, and its fold down design makes storage and

access a real convenience.

The monitor keyboard consists of a 17 TFT active matrix

LCD monitor with 1280x1024 native resolution, LCD control

ler designed to automatically work with any standard analog

video signal from a computer, a keyboard with built in

touchpad mouse, and power supply. An optional waterproof,

sealed membrane keyboard is also available.

This guide provides step by step instructions for installation

and use of your monitor keyboard drawer.

Setup and Operating Guide

Safety Guidelines

Before you setup your monitor keyboard drawer, it is

important to follow certain basic safety precautions to

prevent damage to the product and to ensure your own

personal safety.

Handling the Drawer Assembly

The monitor keyboard drawer is constructed of heavy gauge

metal and can weight up to 30 lbs. To avoid injury during

installation watch for edges and corners on the assembly.

To prevent the drawer from accidentally sliding out and cause

bodily injury, the unit is shipped with a metal strap installed

across the front bezel. It is recommended that you do not

remove it until the unit is installed in the rack, or when the

unit is set down on a level work area.

Power Connections

The monitor is shipped with a power cord compatible with

the AC wall outlet in your region. Use the supplied power

cord.

Do not remove any of the covers over the power supply and

LCD controller. High voltages are present. Only qualified,

authorized electronics service personnel should access the

electronics components.

Setup and Operating Guide

Care for the LCD

The monitor is an active matrix LCD. Liquid crystal displays

are made of glass which will break or crack if mishandled.

entilation

The ambient temperature within a densely filled rack cabinet

may exceed that of the room temperature. It is important

that nothing blocks the ventilation openings of the power

supply.

Setup and Operating Guide

Unpacking

As you unpack your unit check the packing material to

ensure that you have found all of the proper cables and

accessories. Save all of the shipping material in case you

need it for transporting the unit in the future.

The monitor keyboard comes completely assembled. You

should find these items in your package:

w17 monitor keyboard assembly.

wCombo cable for video, keyboard and mouse.

wPower cord.

wKeys for the key lock.

Setup and Operating Guide

External iews

Front iew

The monitor keyboard drawer includes a flip up LCD.

Unlock the flip up LCD and use the handle to lift the LCD up.

Facing the unit youll find these components:

Slide rail LCD Touchpad

mouse

Keyboard Rack mounting

bracket

Setup and Operating Guide

Side iewOSD Controls

On the left side of the LCD youll find four push buttons. You

use them to adjust the display properties through an OSD

(On Screen Display) menu system (see page 16 for a

description of the OSD).

Power supply OSD controls
