ACBU011/ACLU011 User Manual
Page 1 of 21
ACBU011 / ACLU011
REDUNDANCY CONTROLLER
USER MANUAL
ACBU011/ACLU011 User Manual
Page 2 of 21
Table of contents
I. Specifications ......................................................................................... 3
II.Block Overview ..................................................................................... 4
III.19 pin connector for a PC / Laptop........................................................ 5
IV.Connector for a Waveguide Switch....................................................... 7
V.Redundancy Terminal User Manual...................................................... 9
VI.Web Interface User Manual............................................................... 155
VII. SNMP User Manual…………………………………...……………..19
ACBU011/ACLU011 User Manual
Page 3 of 21
Redundancy Controller
I. Specifications
Redundancy
InputPower12‐55V
MaximumLoadCurrent5A
PowerConsumption10W
LoadCurrentAnalizerYes
Dimentions214mmx188mmx56.5mm
Weight2.6kg
OperatingTemperature‐40°Cto+70°C
StorageTemperatureRange‐40°Cto+80°C
InputInterfaceN‐TypeorF‐type
InternalReferenceYes(Autodetect)
CertainInternalReferencestability±3*10^‐8
InternalReferencePhaseNoice
1Hz<‐85dBC/Hz
10Hz<‐115dBC/Hz
100Hz<‐140dBC/Hz
1000Hz<‐150dBC/Hz
10000Hz<‐150dBC/Hz
InternalReferenceFrequency10MHz
CommunicationInterfaceRS232andRS485
BUCM&CInterface BUCAandB–splitter:RS‐232orRS‐485
4‐wire
AlarmAnalizerYes
Waveguideswitchtype
WR‐137/WR‐229
WR‐75
WR‐28
WR‐112
SwitchtimeFaultdetection,20‐50msec
Totalswitchover,100msecmax
ACBU011/ACLU011 User Manual
Page 4 of 21
II. Block Overview
The appearance of the Redundancy Controller and it`s connectors are displayed on figure 1.1.
Figure 1.1 — Redundancy
Redundancy connection ports from one side:
Two L-band F (or N) connectors for BUC connection provided via coaxial cable;
Switch connector for connection Redundancy Controller with Switch with 19-pin cable
on both sides;
Redundancy Controller to laptop/PC connection provided via 19-pin cable from the
Redundancy side and RS 232 (and/or RS 485) from the PC side;
Redundancy M&C to Unit 1 and Unit 2 connection provided via 19-pin cable on
Redundancy side and two 19-pin on the other side.
And from the other side:
L-band F (or N) connector for BUC connection with modem provided via coaxial cable. It
also can provide power supply from modem and external reference frequency.
Two power ports (DC1 and DC2) connectors provided via 2-pin connectors.
ACBU011/ACLU011 User Manual
Page 5 of 21
III. 19 pin connector for a PC / Laptop
Redundancy Controller connection to PC carried by cable with 19 pin female connector (fig.1) on the one side and
RJ45 (fig. 2), two DB9 (fig. 3) female connectors: RS232 and RS485 on the other side.
Figure 2.1 — 19 pin connector configuration
Figure 2.2 — DB9 connector configuration
Figure 2.3 — RJ45 connector configuration
Interface name Interface pin Pin Name 19-pin Connector
RJ45
3 RX+ C
6 RX- P
1 TX+ L
2 TX- N
R75_TX NC
ACBU011/ACLU011 User Manual
Page 6 of 21
R75_RX NC
GNDISO A
GNDISO
RS485
2 A S
1 B F
4 Z H
3 Y T
5 GNDISO V
GNDISO
NC NC
NC NC
GNDISO G
RS232 5 GNDISO
2 RS232TX J
3 RS232RX E
Figure 2.4 — Redundancy 19 pin connector for a PC/Laptop
ACBU011/ACLU011 User Manual
Page 7 of 21
19-pin Connector Pin Name 20-pin (Unit
2) 20-pin (Unit
1) Ethernet
M MUTE1 17 NC
B ALARM1 18 NC
E RS232_TX1 11 NC
J RS232_RX1 16 NC
G GNDISO
12 NC
20 NC
V GNDISO
NC 12
NC 20
T RS232_TX2 NC 11
S RS232_RX2 NC 16
H MUTE2 NC 17
K ALARM2 NC 18
RX_P 2 2 3
RX_N 6 6 6
TX_P 7 7 1
TX_N 8 8 2
Figure 2.4 — Redundancy 19-pin cable to Unit 1 and Unit 2
IV. Connector for a Waveguide Switch
Redundancy Controller connection to waveguide switch carried by cable with 19 pin female connector (fig. 2.1) on
the both sides. Waveguide Switch schema on figure 2.1:
Figure 3.1 — Switch input pins
ACBU011/ACLU011 User Manual
Page 8 of 21
From Redundancy Interface pin From Switch pin
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
S S
T T
U U
V V
Figure 3.2 — Switch interface
ACBU011/ACLU011 User Manual
Page 9 of 21
V. Redundancy Terminal User Manual
Run Redundancy Terminal v 1.1 on your PC, when it opened you will see next window:
Figure 4.1 — Start window
On the top of the window situated menu tabs.
Interface – consist information about redundancy connection;
Serial port: select COM port you want to connect to;
Exit: select to quit program;
Status – push button Read to get current information about redundancy connector status. You will see next window:
ACBU011/ACLU011 User Manual
Page 10 of 21
Figure 4.2 — Redundancy Status Window
POWER SUPPLY: Redundancy power supply provides by two ways: by DC
power supply (U DC1 and U DC2) and by RF connector from modem (Umodem).
Function displays current income voltage and power port connection. Voltage is
in OK if it’s value within acceptable limits and ERROR if voltage out of limits.
To set voltage limits go to menu tab Parameters.
WS STATUS: displays current position of waveguide switch (fig 3.3).
Figure 3.3 — WS RF paths positions
Current position status will be OK, other will be ERROR;
REF MODE INTERNAL: displays status of reference frequency mode; OK if
Internal mode, ERROR if External mode.
POWER STATUS: displays power or amperage appliance of BUC. Power or
Amperage is in OK if it’s value within acceptable limits and ERROR if out of
limits. Device turn’s off BUC if power or amperage parameters are out of limits.
To set limits go to menu tab Parameters.
