ThefollowingleafletinformsyouaboutthemostimportantstepsforeasycommissioningofyourEthernet
I/Omodule.Pleasefindmoredetailedinformationinthedeliveredmanual.
Overview
ConnectingtheEthernet I/O module
Afterhavingreadthesafetyprecautions(yellowleaflet),connectyourEthernetI/Omoduleasfollows:
A) Connectthetransducers
B) ConnecttheEthernetcabletotheEthernetI/OmoduleandthePC
C) Connectthecablefortrigger/synchrosignalstotheEthernetI/Omodule(optional)
-Start yourPC -
D) Connectthecurrentsupplycable(MSX-E3701)orcurrentsupplybinder(MSX-E3700)totheEthernet
I/Oandcurrentsource
E) CheckthestatuswiththehelpoftheLEDdisplay
PowerOn: -lightsgreen =CurrentsupplyisOK
Port0ACT/Link: -blinksyellow =EthernetcableconnectedtoPort0
Port1ACT/Link: -blinksyellow =EthernetcableconnectedtoPort1
Status: -lightsgreen =Modulereadyforwork
-lightsyellow =Moduleisbooting
-lights/blinksred =Errorduringbooting
AssoonastheStatusLEDlightsgreen,youcanstartwiththesoftwareinstallation.
Connectingthe MSX-E3701
Trigger/Synchro
Trigger/SyncOut(female
connector,5-pin,M12)
Pin1:Triggerinp.- brownlead
Pin2:Triggerinp.+ whitelead
Pin3:Synchro+ bluelead
Pin4:Synchro- blacklead
Pin5:Ground greylead
Currentsupply
PowerOutput(female
connector,5-pin,M12)
Pin1:24V brownlead
Pin2:24V whitelead
Pin3:Groundbluelead
Pin4:Groundblacklead
Pin5:Shield greylead
