1-1
SECTION 1
General Description
••••••••••••••••••••••••••••••••••••••••••
In This Section
♦Application and Description
♦Control Panels Supported ♦Differences between the 4285 and 4286 VIP Module
♦4286 VIP Module Specifications
••••••••••••••••••••••••••••••••••••••••••
Application and Description
The Ademco 4286 Vista Interactive Phone (VIP) Module is an add-on acces-
sory that can be used with certain Ademco controls* to provide an interactive
phone capability to the security system. This feature will permit access to the
security system via any Touch-tone phone (either on premises or by a call-in
when away from the premises).
Only one 4286 VIP Module can be used in a system.
1. The 4286 VIP Module can only be used with systems using address-
able keypads. Addressable keypads that may be used are: 4137AD,
5137AD, 6128, 6137, 6138, and 6139.
2. For controls that do not support addressable keypads (such as the
VISTA-10(SE), VISTA-20 (all models), and VIA-30P(SE), an address-
able keypad must still be used and set to the non-addressable mode.
The non-addressable mode, for units with DIP switches all toggled to
the UP position, is address 31.
•See the control's Installation Instructions for information on
whether the control can support a VIP Module
All controls that support a 4285 Voice Module can support the 4286 VIP Module
as well. Existing 4285 Voice Module programming and downloading fields for the
control panel still apply.
4286 VIP Module Installation and Setup Guide
1-2
When connected, the 4286 VIP Module will enable the user to do the follow-
ing via any Touch-tone telephone:
1. Receive synthesized voice messages over the phone regarding the
status of the security system.
2. Arm and disarm the security system and perform most other com-
mands using the telephone keypad, with voice annunciation being
provided as confirmation after any command is entered.
3. Turn certain lights/appliances on and off via the telephone using the
Relay Command Mode. This capability is possible only with the 4286
VIP Module and with controls supporting the Relay Command Mode.
If the system has relays, but does not support the Relay Command Mode, they
still can be controlled via the phone (in same way as from a wired keypad), but
no voice feedback will occur.
The on-premises phone system need not have Touch-tone service, but the
phone used for security system access must have Touch-tone capability.
Switchable phones should be set for Touch-tone temporarily before attempt-
ing phone access. However, an off-premises phone that does not have Touch-
tone service and uses pulses for dialing may not permit switching to Touch-
tone after dialing; in such a case, phone access from that phone will not be
possible.
Control Panels Supported
These following control panels require specific software revisions for use with
the 4286 VIP Module:
Vista-10SE, Via-30PSE Rev. 13 (micro. WA6764V10) or above; Vista-20SE
Rev. 7 (micro WA7840V6) or above; Vista-40 Rev. 12 (micro. WA4142P2-22) or
above; Vista-50P Rev. 5 (micro. WAVIS50P-15) or above; Vista-100 Rev. 4
(micro. WAVIS100-14) or above; Vista-128FB Rev. 1 (micro WAVIS128FB-11)
or above.
Differences between the 4285 and 4286 VIP Module
The 4286 VIP Module offers increased capabilities when used with a control
that supports the 4285. These include:
•Thermostat control (using 4500 thermostats). Temperature settings
can be adjusted and room temperature can be monitored from a touch
tone phone on or off the premises.
Section 1. General Description
1-3
®
The 4500 thermostat cannot be used in UL installations.
•Synthesized voice prompts to instruct the user on how to initiate
common user commands, such as arming or disarming the system,
relay and thermostat control, etc.
•Panic alarms can be activated from a premises touch tone phone.
•Audio output capable of driving a loudspeaker, providing system
status, warnings, and confirmation of user commands
•Telephone programming mode for 4286 installation options.
4286 VIP Module Specifications
Physical: 6-7/16” (163mm) W x 4-1/4” 108mm)
H x 1-1/4” (32mm) D.
Electrical: Input voltage: 12VDC (from control)
Current Usage: 300 mA; 220 mA if the warning
speaker is not used
Device Address: Factory set to address 4, not
changeable
FCC Registration No.: AC3USA-74659-KX-N
Ringer Equivalence: 1.0 B
The 4286 VIP Module complies with FCC RULES, Parts 15 & 68.
4286 VIP Module Installation and Setup Guide
1-4
2-1
SECTION 2
Mounting and Wiring
••••••••••••••••••••••••••••••••••••••••••
In This Section
♦Mounting the 4286 VIP Module
♦Wiring Connections
♦Speaker Connections and Volume Control
♦Caller ID Units
••••••••••••••••••••••••••••••••••••••••••
Mounting the 4286 VIP Module (All Controls)
•Mount the 4286 VIP Module in the control cabinet if space is available, or
on the side of the cabinet or adjacent to it. Pry off the 4286’s cover prior
to wiring.
•If mounted inside the cabinet with the control, use double-sided adhesive
tape to attach the Module to the interior surface of the cabinet, or hang
on two screws. Do not mount on the cabinet door or attempt to at-
tach it to the PC board. The 4286's cover can be left off if the Module
is mounted within the cabinet.
•To mount the 4286 outside the cabinet, use the screw holes at the rear of
the Module, which can be mounted horizontally or vertically (double-
sided adhesive tape may be used in place of screws, if preferred). Wires
can be brought out from the side or back (use the round breakout on the
back). When the 4286’s wiring is completed (as shown below), replace the
Module's cover (with label affixed, as indicated next).
•Affix the supplied connections label to the inside of the 4286's cover if the
cover is to be used. Otherwise, affix the label to the inside of the control
cabinet's door.
4286 VIP Module Installation and Setup Guide
2-2
Wiring Connections
1. Make 12V (+), Ground (–), Data in, and Data out connections from the
4286 VIP Module to the keypad terminals on the control Using the con-
nector cable supplied and referring to Summary of Connections located on
the inside back cover on page A-7, wire as follows:
Color Lead Terminal On Control
GREEN to DATA IN
BLACK to AUX GROUND (–)
RED to AUX +
YELLOW to DATA OUT
2. Insert the keyed connector at the other end of the above leads into the
mating header on the 4286. Refer to Summary of Connections.
3. Connect terminals 1 through 5 on the 4286 as indicated in Figure 1 and
Table 2-1. Use an RJ31X jack (CA38A in Canada) with a direct-connect
cord and make all connections exactly as shown. If the leads on the di-
rect-connect cord are too short to reach their assigned terminals, splice
additional wires to them, as required.
Some controls may require different wiring connections than those indicated in
Table 2-1 and shown in Summary of Connections located on back inside cover
depending on whether other devices that connect to the telephone lines are also
being used (for example, an Audio Alarm Verification unit). Refer to the 4286 VIP
Module section in the control’s installation instructions for information on any
wiring variations that might be necessary.
Speaker Connections (optional) and Volume Control
•Single Speaker: Connect an Ademco 746 Indoor Speaker or any other 8-
ohm speaker between speaker terminals 6 and 7 on the 4286 as shown in
Summary of Connections on page A-7. Do not use a single 4-ohm
speaker in this setup. If you only have 4-ohm speakers, you must con-
nect two of them in series.
•Dual Speakers: Connect the speakers in series between the 4286 VIP
Module speaker terminals 6 and 7. Note that there will be a decrease in
volume from each of two 8-ohm speakers in series as compared to when
only a single 8-ohm speaker is connected. The same is true if two 4-ohm
speakers in series are used in this setup.
•Speaker Volume Control: The speaker volume control is located near
the transformer on the 4286 board. Refer to Summary of Connections.
Note that this control does not adjust the volume of the output from the
4286 to the phone handset.
Andere Handbücher für 4286 VIP
1
Inhaltsverzeichnis
Andere ADEMCO Steuereinheit Handbücher
ADEMCO
ADEMCO 4297 Gebrauchsanweisung
ADEMCO
ADEMCO 4140XM Bedienungsanleitung
ADEMCO
ADEMCO TeleSmart Montageanleitung
ADEMCO
ADEMCO 4208U Montageanleitung
ADEMCO
ADEMCO LYNX-AVM Montageanleitung
ADEMCO
ADEMCO TeleCommand Bedienungsanleitung
ADEMCO
ADEMCO VISTAKEY Montageanleitung
ADEMCO
ADEMCO 5800GDO Montageanleitung
Beliebte Steuereinheit Handbücher anderer Marken
Festo
Festo Compact Performance CP-FB6-E Stücklistenhandbuch
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung
JS Automation
JS Automation MPC3034A Bedienungsanleitung
JAUDT
JAUDT SW GII 6406 Series Kurzanleitung
Spektrum
Spektrum Air Module System Bedienungsanleitung
BOC Edwards
BOC Edwards Q Series Bedienungsanleitung
