User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 1 of 28
User Manual
Revision 1.
English
IEC 61850 Server / Modbus TCP Master -
Converter
(Order Code: HD67735-A1 )
For Website information:
www.adfweb.com?Product=HD67735
For Price information:
www.adfweb.com?Price=HD67735-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For other IEC 6185 server products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com?Product=HD67733 Modbus Master)
www.adfweb.com?Product=HD67734 Modbus Slave)
www.adfweb.com?Product=HD67736 Modbus TCP Slave)
www.adfweb.com?Product=HD67737 BACnet Master)
www.adfweb.com?Product=HD67738 BACnet Slave)
www.adfweb.com?Product=HD67739 CAN)
www.adfweb.com?Product=HD6774 CANopen)
www.adfweb.com?Product=HD67741 DeviceNet Master)
www.adfweb.com?Product=HD67742 DeviceNet Slave)
www.adfweb.com?Product=HD67743 EtherNet/IP Master)
www.adfweb.com?Product=HD67744 EtherNet/IP Slave)
www.adfweb.com?Product=HD67745 J1939)
www.adfweb.com?Product=HD67746 KNX)
www.adfweb.com?Product=HD67747 MQTT)
www.adfweb.com?Product=HD67748 NMEA 0183)
www.adfweb.com?Product=HD67749 NMEA 2000)
www.adfweb.com?Product=HD6775 PROFIBUS Master)
www.adfweb.com?Product=HD67751 PROFIBUS Slave)
www.adfweb.com?Product=HD67B82 PROFINET Master)
www.adfweb.com?Product=HD67752 PROFINET Slave)
www.adfweb.com?Product=HD67753 SNMP Manager)
www.adfweb.com?Product=HD67754 SNMP Agent)
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67 3
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 2 of 28
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 1
USE OF COMPOSITOR SW67735 11
NEW CONFIGURATION / OPEN CONFIGURATION 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
IEC 6185 ACCESS 18
MODBUS SET ACCESS 19
TLS KNOWN CERTIFICATE 22
UPDATE DEVICE 23
MECHANICAL DIMENSIONS 25
ORDERING INFORMATIONS 26
ACCESSORIES 26
DISCLAIMER 27
OTHER REGULATIONS AND STANDARDS 27
WARRANTIES AND TECHNICAL SUPPORT 28
RETURN POLICY 28
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision
Date Author Chapter
Description
1. 18/ 9/2 18
Ff All First Release
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 3 of 28
SECURITY ALERT:
G
ENERAL
I
NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I
NTENDED
U
SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q
UALIFIED
P
ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R
ESIDUAL
R
ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE
CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 4 of 28
EXAMPLES OF CONNECTION:
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 5 of 28
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67735-A1
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 6 of 28
CHARACTERISTICS:
The HD67735-A1 are IEC 6185 / Modbus TCP Master - Converters.
It allows for the following characteristics:
Up to 512 Modbus reading requests and 512 Modbus writing requests;
Isolation between Ethernet - Power Supply;
Two-directional information between IEC 6185 bus and Modbus TCP bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67735 software on your PC in order to perform the following:
Define the parameters of IEC 6185 line;
Define the parameters of Modbus TCP line;
Define IEC 6185 variables that contains the data read from the Modbus TCP slaves;
Define IEC 6185 variables that contains the data to send to the Modbus TCP slaves;
Update the device.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 7 of 28
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67735-A1 3.5
HD67735-A1
Caution:
Do n
ot reverse the polarity power
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 8 of 28
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for uploading the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 9 of 28
LEDS:
The device has got six LEDs that are used to give information about the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
3: IEC 6185 communication
(green) It blinks when a IEC 6185 request is received Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
4: Modbus communication
(green) It blinks when a Modbus TCP response is received Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
IEC 61850 Server / Modbus TCP Master
Document code: MN67735_ENG Revision 1. Page 1 of 28
ETHERNET:
IEC 6185 and Modbus TCP connection and the updating of the converter must be made using Connector3 and/or Connector4 of the
HD67733-X-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 1 m. The cable has to conform to
the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the device to an Hub/Switch is recommended the use of a
straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable.
