PXI-7931

4x8 2-Wire Matrix Module

User’s Manual

Manual Rev.: Rev. 1.1

Date: February 8, 2020

Part Number: 50-17009-1010

Revision History.

1.00

09-07-2004

Initial release

1.1

08-02-2020

Remove Star Trigger Out functionality

Disclaimer

The information in this document is subject to change without prior notice in

order to improve reliability, design, and function and does not represent a

commitment on the part of the manufacturer.

In no event will the manufacturer be liable for direct, indirect, special,

incidental, or consequential damages arising out of the use or inability to use

the product or documentation, even if advised of the possibility of such

damages.

This document contains proprietary information protected by copyright. All

rights are reserved. No part of this manual may be reproduced by any

mechanical, electronic, or other means in any form without prior written

permission of the manufacturer.

Trademarks

NuDAQ™, NuIPC™, NuDAM™, NuPRO™are registered trademarks of

ADLINK Technology Inc. Other product names mentioned herein are used

for identification purposes only and may be trademarks and/or registered

trademarks of their respective companies.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to

global environmental preservation through compliance

with the European Union's Restriction of Hazardous

Substances (RoHS) directive and Waste Electrical and

Electronic Equipment (WEEE) directive. Environmental

protection is a top priority for ADLINK. We have enforced

measures to ensure that our products, manufacturing

processes, components, and raw materials have as little

impact on the environment as possible. When products

are at their end of life, our customers are encouraged to

dispose of them in accordance with the product disposal

and/or recovery programs prescribed by their nation or

company.

Battery Labels (for products with battery)

廢電池請回收

California Proposition 65 Warning

WARNING: This product can expose you to chemicals including

acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-

propyl)phosphate (TDCPP), 1,4-Dioxane, formaldehyde, lead,

DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to

the State of California to cause cancer, and acrylamide, benzene, cadmium,

lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC,

and vinyl materials, which are known to the State of California to cause birth

defects or other reproductive harm. For more information go to

www.P65Warnings.ca.gov.

Getting Service

Customer Satisfaction is top priority for ADLINK Technology Inc. If you need

any help or service, please contact us at Ask an Expert:

http://askanexpert.adlinktech.com.

ADLINK Technology, Inc.

Web Site

http://www.adlinktech.com

Sales & Service

[email protected]

Telephone

+886-2-8226-5877

Fax

+886-2-8226-5717

Address

9F, No. 166, Jian Yi Road, Chungho District, New Taipei County

Taiwan 235

Table of Contents • i

Table of Contents

How to Use This Manual..............................................................ii

Chapter 1 Introduction ..............................................................1

1.1 Features.............................................................................1

1.2Applications........................................................................2

1.3 Specifications.....................................................................2

1.4 Software Support...............................................................3

Chapter 2 Installation ................................................................5

2.1 Contents.............................................................................5

2.2 Unpacking..........................................................................5

2.3 Mechanical Drawing...........................................................6

2.4 Installing the switch module into a PXI Platform................6

Chapter 3 Signal Connection....................................................9

3.1 PXI-7931 Topology ............................................................9

3.2 PXI-7931 Pin assignment & Description..........................10

3.3 TB-6231 Terminal Board..................................................11

Chapter 4 Operation Theorem................................................21

4.1 Hardware Block Diagram.................................................21

4.2 Operation Mode...............................................................22

4.3 Handshaking....................................................................22

4.4 Trigger Bus ......................................................................28

4.5Auxiliary Digital I/O...........................................................29

4.6 Hot-Swap .........................................................................30

4.7 Emergency Shutdown......................................................30

4.8 Watchdog Timer...............................................................31

Warranty Policy........................................................................33

How to Use This Manual

This User Manual is designed to assist users in the installation of the ADLINK

PXI-7931, 4x8 2-Wire Matrix PXI Switch module.

Chapter 1 Introduction

Gives an outline and overview of ADLINK switch modules’

features, specifications, and applications.

Chapter 2 Installation

Describes how to install a switch module into a PXI chassis. For

software library and utilities installation, please refer to the

Software Users’ Guide.

Chapter 3 Signal Connection

Shows the pin assignments and terminal board connection of the

switch module.

Chapter 4 Operation Theorem

Describes function blocks on ADLINK switch modules and

operation instructions.

ii • How to use this Manual

Introduction • 1

Introduction

ADLINK PXI-7931 is a matrix module with 32 cross-point 2-wire relays (DPDT,

2 Form C). The default configuration of the PXI-7931 is a 4-group 2x4 2-wire

matrix. With the termination board, TB-6231, users can flexibly choose one of

the configurations: one 4x8, two 4x4, one 2x16, two 2x8, and four 2x4. Any

contact of the PXI-7931 can connect to other contacts at the same bank,

individually, or in combination. The PXI-7931 matrix module simplifies wiring

and makes it easy to change the internal connection path.

The contact position of the relays can be changed either by direct software

commands or by following the instructions previously stored in the on-board

scan list. The scan list advances upon the trigger from external measurement

devices, such as a DMM. The scan list can also advance when the scan-delay

timer expires. PXI trigger functions are supported and software programmable.

Multiple modules can be synchronized without additional field wiring.

1.1

Features

•PXI specifications Rev. 2.0 compliant

•3U Eurocard form factor, CompactPCI compliant (PICMG 2.0R3.0)

•PICMG 2.1 R2.0 CompactPCI Hot-Swap specificationscompliant

•32 DPDT (2 Form C) non-latching relays

•Contact rating

•2A switching, 2Acarrying

•220VDC, 125VAC

•200 operations per second

•1k-sample scanlist for deterministic scanning

•Provides handshaking signals to trigger external instruments

•Programmable emergency shutdown function and Watchdog timer for

safety critical applications

•Eight auxiliary 3.3 V/TTL digital inputs/outputs with 5Vtolerance

•Supports PXI backplane triggers to synchronize multiple modules

•Fully software programmable

1.2

Applications

•Industrial ON/OFF control

•External high power relay driving and signal switching

•Laboratory automation

•Industrial automation

•Switch contact status sensing

•Limit switch monitoring

•Cooperating with other modules such as A/D and D/A peripherals to

implement a data acquisition and control system

1.3

Specifications

Relay Output

•Number of cross-points: 32 (2-wire)

•Relay type: DPDT (2 Form C), non-latching

•Switching capacity:

•Max. switching current: 2A

•Max. switching voltage: 220VDC, 125VAC

•Max. switching power: 60VA, 60W

•Failure rate: 10µA, 10mVDC

•Contact resistance: 100mΩ max.

•Relay set/reset time

•Operate time: 4msmax.

•Release time: 4msmax.

•Bounce time: 1ms max.

•Expected life:

•Mechanical life: 108operations min.

•Electrical life: 105operations min. (2A @ 30VDC, resistive load)

•Data transfer: Programmed I/O

Auxiliary Digital I/O

•Numbers of channel: 8inputs/outputs

•Compatibility: 3.3 V/TTL (5Vtolerant)

•Data transfers: programmed I/O

Handshaking Signals

•Programmable polarity

•Logic level: 3.3 V/TTL (5V tolerant)

•Trigger In source: AUX1, PXI trigger bus, PXI star trigger in

•Scanner Advanced destination: AUX0, PXI trigger bus

2 • Introduction

Introduction • 3

Safety functions

•Emergency shutdown

•Logic level: 3.3 V/TTL (5V tolerant)

•Active with logic low (for AUX2/SHDNn pin)

•Emergency shutdown sources: AUX2/SHDNn, PXI star trigger

input, PXI trigger bus

•Watchdog timer

•Base clock available: 10MHz, fixed

•Counter width: 32-bit

•Watchdog Timer Overflow sources: Onboard 32-bitwatchdog

timer, PXI star trigger input, PXI trigger bus

General Specifications

•I/O Connector: 62-pin D-submale

•Operating temperature: 0 to 55°C

•Storage temperature: -20 to 70°C

•Humidity: 5 to 95% non-condensing

•Power requirements (when all relays are activated simultaneously)

+5V +3.3V

1A 400mA

•Dimensions (not including connectors)

•160 mm x 100 mm

1.4

Software Support

ADLINK's ADL-SWITCH driver package is for Microsoft Windows operating

systems, including Windows 98/ME/NT/2000/XP.

The driver package also provides utilities to test your switch module, as well as

programming samples and source codes in Microsoft Visual Basic and Visual

C/C++.

For other operating systems, please contact ADLINK for more information.

4 • Introduction

This page intentionally left blank.

Inhaltsverzeichnis

Andere ADLINK Technology Steuereinheit Handbücher

ADLINK Technology

ADLINK Technology cPCI-3938 Bedienungsanleitung

ADLINK Technology

ADLINK Technology COM Express Express-CFR Bedienungsanleitung

ADLINK Technology

ADLINK Technology NuDAM-6017 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-R6500 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology cExpress-HL Bedienungsanleitung

ADLINK Technology

ADLINK Technology Express-HR Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-6830 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology USB-2405 Bedienungsanleitung

ADLINK Technology

ADLINK Technology MPC-8164 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3840 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology USB-1210 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-8168 Bedienungsanleitung

ADLINK Technology

ADLINK Technology NuDAM-6018 Bedienungsanleitung

ADLINK Technology

ADLINK Technology Express-SL Bedienungsanleitung

ADLINK Technology

ADLINK Technology SMARC NXP iMX 8M Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology AVA-5500 Series Bedienungsanleitung

ADLINK Technology

ADLINK Technology ND-6021 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-R6100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology HSL-4XMO Bedienungsanleitung

ADLINK Technology

ADLINK Technology HSL-DI32-UD Bedienungsanleitung

ADLINK Technology

ADLINK Technology COM Express nanoX-BASE Bedienungsanleitung

ADLINK Technology

ADLINK Technology USB-7230 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3534 Bedienungsanleitung

ADLINK Technology

ADLINK Technology SMARC LEC-PX30 Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
