Adp HandPunch Bedienungsanleitung
ADP Full HandPunch®
Quick Installation Guide
ADP provides this publication “as is” without warranty of any kind, either
express or implied, including, but not limited to, the implied warranties of
merchantability or fitness for a particular purpose.
ADP is not responsible for any technical inaccuracies or typographical
errors that may be contained in this publication. Changes are periodically
made to the information herein, and such changes will be incorporated in
new editions of this publication. ADP may make improvements and/or
changes in the product and/or the programs described in this publication
at any time without notice.
ADP Full HandPunch®Quick Installation Guide (ezLaborManager)
© 2005, 2006, 2008 Automatic Data Processing, Inc.
Document Revision History
Document
Revision Product Version Changes Release Date
AADP HandPunch
Manager v1.2.0.5 New Document November 2005
BADP HandPunch
Manager v1.2.0.7
Removal of 4000
HandPunch Units January 2006
CADP HandPunch
Manager v2.0.0.x
Removal of Soft-
ware Install/New
Data Converter
September 2006
DADP HandPunch
Manager v3.0.0.x Minor edits January 2008
Contents
Tools and Materials.............................................................................. 3
Check the Contents of the Box.........................................................4
Decide Where to Mount the HandPunch......................................... 8
Use the Mounting Guide to Mark the Wall.....................................9
Sheetrock Wall Installation............................................................. 10
Power and Communications Setup ....................................................11
Power and Communications Jack Installation (Direct
Connect)............................................................................................ 12
Power and Communications Jack Installation (Modem
Connect)............................................................................................ 13
Power and Communications Jack Installation (Ethernet
Connect)............................................................................................ 14
Fasten the Mounting Plate to the Wall ......................................... 15
Mount the HandPunch........................................................................ 16
Power and Communications Connection .......................................... 17
Attach the Power and Communications Cables (Direct
Connect)............................................................................................ 18
Attach the Power and Communications Cables (Modem
Connect)............................................................................................20
Attach the Power and Communications Cables (Ethernet
Connect)............................................................................................ 21
Complete the Mounting of the HandPunch ...................................22
Set Up the HandPunch Reader (Ethernet Connect Only) .........23
Appendix A ...........................................................................................25
Cable Specifications (Direct Connect) .....................................25
Cable Connections (Direct Connect)..........................................25
Appendix B: Connecting More than One HandPunch
(Direct Connect).............................................................................26
i
Appendix C: Connecting More than One HandPunch
(Modem Connect)............................................................................27
Appendix D: Connecting More than One HandPunch
(Ethernet Connect)........................................................................28
Appendix E: Bell Relay to HandPunch Wiring...............................29
Appendix F: Door Access Relay to HandPunch Wiring ..............30
FailSafe Lock .................................................................................. 31
FailSecure Lock .............................................................................. 31
Appendix G: Resetting the HandPunch Memory..........................32
ii
1
Congratulations!
You are about to save time and increase
payroll accuracy by automating your
time and attendance.
This guide will show you the basic steps for
installing your ADP Full HandPunch.
WARNING: Installation of your HandPunch will require you to address electrical,
telecommunication and other configurations and arrangements. You are advised to
consult appropriate professional technicians for the installation of your HandPunch.
Any deviation from the installation process contained in this guide or from the
recommended use of the HandPunch may result in damage to the HandPunch, your
facility or personal injury. A damaged HandPunch may incorrectly transmit, alter or
lose your data. In no event will ADP be responsible for any such damage, injury,
alteration or loss.
2
This Quick Installation Guide will take you step by step
through the installation and setup of your ADP Full
HandPunch:
1) We will prepare you for the installation process by:
• Gathering the tools and materials needed
• Checking the contents of the HandPunch box
• Deciding where to mount the HandPunch
2) Then we will help you to install the hardware, including:
• Power and communications equipment
• Mounting your HandPunch
• Communications cabling
3
Tools and Materials
Assemble the following tools and materials:
Phillips screwdriver Tape
Tape measure Drill with ¼" bit
Pencil & Ruler Scissors
4
1. Check the Contents of the Box
Check that the following items are in the HandPunch box, starting
from the top of the box and working your way down:
One power adapter for 110V AC outlets (in a white box)
One
ADP Full HandPunch Quick Installation Guide
One
HandPunch Quick Reference Card - Full & LE Models
One
Supervisor HandPunch Quick Reference Card - Full &
LE Models
One
ADP HandPunch Manager Installation Guide
One
ADP HandPunch Manager
CD
One set of keys
One 8-pin green Phoenix connector (for relay wiring)
Three flat #8 stainless washers
5
One 2-pin Wieland plug
Three molly fasteners
Two auger connectors and screws
One wall mounting plate
One wall mount paper template
One HandPunch instructional poster
One RS-422 wall mount jack
6
Connection equipment as follows:
Direct connect:
Modem connect:
One 6 foot
RS-422 wire
AND
One 12 inch wire
for daisy chaining
One 6 foot
modem cable
AND
One 12 inch wire
for daisy chaining
AND
(Continued on next page.
)
