ADTRAN SMART/RG SR501 Bedienungsanleitung

/ Gateway User Manual

Model: SR501

Release 1.4 July 2020

Firmware Version 2.6.2.5

501 SE Columbia Shores Boulevard, Suite 500

Vancouver, Washington 98661 USA

+1 360 859 1780 / smartrg.com

Table of Contents

Welcome! 3

Purpose & Scope 3

Intended Audience 3

Getting Assistance 3

Disclaimer 4

Getting Familiar with your Gateway 5

LED Status Indicators 5

Connections 5

Buttons 6

ON/OFF Switch 6

Reset Button 6

Installing your SmartRG Gateway 7

Logging in to your SmartRG Gateway's UI 7

Device Info 8

Summary 8

WAN 8

Statistics 10

LAN 10

WAN Service 10

xTM 11

xDSL 12

References 16

Route 17

ARP 18

DHCP 18

DHCPv6 19

VPN 20

Advanced Setup 21

Layer2 Interface 21

ATM Interface 21

PTM Interface 24

WAN Service 27

PPP over Ethernet 27

IP over Ethernet 35

Bridging 45

LAN 49

IPv6 Autoconfig 52

Ethernet Config 53

NAT 55

Virtual Servers 55

Port Triggering 57

DMZ Host 59

Security 60

IP Filtering - Outgoing 60

IP Filtering - Incoming 61

MAC Filtering 63

Adding a MAC Filtering Rule 63

Parental Control 64

Time Restriction 64

URL Filter 66

Quality Of Service 66

QoS Config 67

Supported DSCP Values 67

QoS Queue Config 68

QoS Classification 70

QoS Port Shaping 72

Routing 74

Default Gateway 74

Static Route 75

Policy Routing 75

RIP (Routing Information Protocol) 76

DNS 78

DNS Server 78

Dynamic DNS 79

Static DNS 80

DSL 81

Advanced settings 83

UPnP 85

DNS Proxy 86

Interface Grouping 87

IP Tunnel 89

IPv6inIPv4 89

IPv4inIPv6 90

IPSec 91

Advanced IKE Settings 93

Certificate 94

Local 94

Trusted CA 96

Power Management 97

Multicast 98

Diagnostics 101

Ethernet OAM 101

Ping Host 104

Trace Route to Host 105

Management 106

Settings 106

Backup 106

Update 106

Restore Default 107

System Log 108

Security Log 109

Management Server 110

TR-069 Client 110

STUN Config 113

Internet Time 115

Access Control 116

Accounts 116

Add an Account 116

Modify or Delete an Account 119

Default Passwords 119

Services 120

Passwords 121

Access List 121

Logout Timer 122

Update Software 123

Reboot 123

Logging Out 125

Appendix C: FCC Statements 126

FCC - Part 68 126

REN (RINGER EQUIVALENT NUMBERS)

STATEMENT 126

IC-CS03 statement 126

FCC Statement 127

FCC Radiation Exposure Statement 127

Table of Contents

Canada Statement 127

Revision History 129

Welcome!

Thank you for purchasing this SmartRG product.

SmartRG offers solutions that simplify the complex Internet ecosystem. Our solutions include hardware, software, applications,

enhanced network insights, and security delivered via a future-proof operating system. Based in the USA, SmartRG provides local,

proactive software development and customer support. We proudly offer the best, most innovative broadband gateways available.

Learn more at www.SmartRG.com.

Purpose & Scope

This User Manual provides SmartRG customers with installation, configuration and monitoring information for the SR501 gateway.

Intended Audience

The information in this document is intended for Network Architects, NOC Administrators, Field Service Technicians and other net-

working professionals responsible for deploying and managing broadband access networks. Readers of this manual are assumed to

have a basic understanding of computer operating systems, networking concepts and telecommunications.

Getting Assistance

Frequently asked questions are provided on the SmartRG Web site.

Subscribers: If you require further help with this product, please contact your service provider.

Service providers: if you require further help with this product, please open a support request.

The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, trans-

lated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, pho-

tocopying, manual, or otherwise, without the prior written permission of SmartRG, Inc.

Disclaimer

SmartRG does not assume any liability arising out of the application or use of any products, or software described herein. Neither

does it convey any license under its patent rights nor patent rights of others. SmartRG further reserves the right to make changes to

any products described herein without notice. This publication is subject to change without notice.

Any trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective

owners.

Getting Familiar with your Gateway

This section contains descriptions of the SR501 gateway's lights, ports, and buttons.

LED Status Indicators

Your SR501 gateway has four indicator lights (LEDs) on the front. The following table describes the LEDs and their functions.

LED Action Description

Internet Connected to Internet

Authentication failed.

DSL Connecting to DSL

Connected to DSL

Transferring data

LAN Connected to LAN

Transferring data

POWER Unit is on

Connections

Below is a diagram of how to install your SR501 gateway. This information is also in the Quick Start Guide enclosed with your gateway.

ON/OFF DSLPower Reset ETH

Phone jack

The ports depicted in this example are described below.

Port Description

Power Connect the power cord included with your gateway to this connector. Use only the power supply included with your gate-

way. Intended for indoor use only.

ETH The yellow RJ45 port on the back of your gateway is used to connect client devices such as computers and printers to your

gateway

DSL The grey RJ12 port labeled DSL is specifically intended for connection to an internet provider via a DSL (Digital Subscriber

Line) service.

Buttons

ON/OFF Switch

The ON/OFF toggle switch is located on the back of the gateway and turns the gateway on and off.

Reset Button

The Reset button is a small hole in the gateway's enclosure with the actual button mounted behind the surface. This style of push-

button prevents the gateway from being inadvertently reset during handling. Reset must be actuated with a paper clip or similar

implement.

The Reset button is located on the back of the unit.

This pin-hole sized reset button has three functions. The duration for which the button is held dictates which function is carried

out.

Hold Duration Effect

Less than 6

seconds

Performs a modem reset that is equivalent to the Reboot function in the gateway software.

6-20 seconds Performs the software equivalent to the Restore Defaults function in the gateway software.

20 or more seconds Changes the POWER LED to red and the gateway enters CFE mode which is a state associated with performing

firmware updates via Internet browser.

Installing your SmartRG Gateway

The following instructions explain all connection types offered for SmartRG gateways. For instructions specific to your gateway, fol-

low the instructions in the Quick Start Guide included in the box.

1. Attach your computer's RJ45 connection to the SmartRG gateway's LAN port.

2. If your computer is not already set up to acquire IP addresses using DHCP, configure your computer's IP interface to do so.

(For instructions on logging in to a SmartRG gateway configured for "bridge mode" operation, see the Note below.)

Logging in to your SmartRG Gateway's UI

To manually configure the SmartRG Gateway, you can access the gateway's embedded web UI.

1. Open a browser and enter the gateway's default address: http://192.168.1.1 in the address bar. The Authentication

Required dialog box appears.

2. Enter the default username and password: admin/admin, and click OK. The Device Info summary page appears.

Note: The gateway's UI can be accessed via the WAN connection by entering the WAN IP address in your browser's address bar and

entering the default username and password: support/support. WAN HTTP access control MUST be enabled to access the gateway's

UI via the WAN connection. For more information, see the Management Access Control section.

If your SmartRG gateway is configured for "bridge mode" (modem) operation, your PC will NOT be able to acquire an address via CPE

DHCP. Instead, manually configure your PC's interface with an IP address on the default network (e.g., 192.168.1.100).

The remainder of this guide is dedicated to a sequential walk-through of the gateway user interface. Screen captures are provided

along with descriptions of the options available on the pictured page. Where applicable, valid values are provided.

For in-depth "how-to" information for specific scenarios, look at the knowledge base found on our support web site. Access to this site

is restricted to SmartRG customers and partners. Do not share links to this site with your subscribers.

Device Info

In this section, you can view information about your gateway's setup, status or nature of its connection with the provider and with

LAN devices. You cannot change the settings in this section.

Summary

When you log into the gateway interface, the Device Info summary page appears. This page displays details about the hardware and

software associated with your gateway. In addition, the current status of the WAN connection (if present) is shown.

WAN

On this page, you can view information about the connection between your ISP and your gateway. The WAN interface can be DSL or

Ethernet and supports a number of Layer 2 and above configuration options (explained later in this document).

In the left navigation bar, click Device Info >WAN. The following page appears.

The fields on this page are explained in the following table.

Field Name Description

Interface The connection interface (Layer 2 interface) through which the gateway handles the

traffic.

Description The service description such ipoe_0_0_1, showing the type of WAN and its ID.

Type The service type. Options are PPPoE,IPoE, and Bridge.

VlanMuxId The VLAN ID. Options are Disabled or 0-4094.

IPv6 The state of IPv6. Options are Enabled and Disabled.

Igmp Pxy The IGMP proxy.

Igmp Src Enbl The IGMP source option is enabled for this connection.

MLD Pxy The MLD proxy.

MLD Src Enbl The MLD source option is enabled for this connection.

NAT The state of NAT. Options are Enabled and Disabled.

Firewall The state of the Firewall. Options are Enabled and Disabled.

Status The status of the WAN connection(s). Options are Disconnected,Unconfigured,Con-

necting, and Connected.

IPv4 Address The obtained IPv4 address.

IPv6 Address The obtained IPv6 address.
