ADTRAN Total Access Octal DS1 IMA Bedienungsanleitung

The Total Access Octal DS1 IMA Access Module is designed to interface

with the Total Access DS3 Cell Switch Module(CSM). Each of the eight ports

provide DS1 interfaces. These can be used to connect the shelf to an

upstream ATM element or to a DS1 IMA unit of a subtended shelf.

The eight (8) ATM DS1s correspond to the eight port interfaces on the

line card. The Octal DS1 IMA automatically swaps from the online to the

offline multiplexer, if one fails or is physically removed. Each of the eight

ports have a single balanced twisted pair for each direction of transmission.

User access to the Octal DS1 IMA Module is through the SCU via the sys-

tem bus of the Total Access DSLAM backplane. The unit retains provision-

ing data in a nonvolatile memory device for recovery after a power loss and

supports optional autoprovisioning through the SCU.

The module detects CRC errors, Bipolar Violations, and frame bit errors

in the loop side receiver. These are used to calculate Errored Seconds,

Severely Errored Seconds and Unavailable Seconds in accordance with

ANSI T1.231-1997.

The Octal DS1 IMA card is capable of both short and long haul signals.

The interface can be configured for the standard DS1 signal (0 to 22.5 db)

or for DSX-1 measured from 0 to 655 feet.

PRODUCT FEATURES

■Software configurable via menu

access or SNMP

■Supports from one to eight DS1

line interfaces

■Supports standard T1 MIB 1406

for alarm states

■Supports extended NUB protocol

for NTU management

■Supports up to four IMA groups

■DS1 or DSX-1 signal

OCTAL DS1 IMA

TOTAL ACCESS®DSLAM

OCTAL DS1 IMA ACCESS MODULE

Product Specifications

FACEPLATE FEATURES

Indicators

■Power LED

■8 DSL T1 Port indicators

MECHANICAL

■Dimensions: 5.20 in. H x 1.320 in. W x

10 in. D

■Weight: Less than 1 lb.

■Mounting: Occupies two access module

slots in the Total Access 3000 or 3010

chassis

INTERFACES

■Network Interface: ATM upstream through

the Cell Switch Module

■Subscriber Interface: DSX-1, Robbed Bit

Signaling and DS1

ELECTRICAL

■Power Requirements: –42 VDC to –56 VDC

input range

CORPORATE OFFICE

ADTRAN, Inc.

901 Explorer Boulevard

P.O. Box 140000

Huntsville, AL 35814-4000

800 9ADTRAN

256 963-8000

fax: 256 963-7916

fax back: 256 963-8200

e-mail: [email protected]

web site: www.adtran.com

REGIONAL OFFICES

Dallas, TX

800 471-8648

Denver, CO

800 471-8651

Irvine, CA

800 788-5408

Kansas City, KS

800 471-8649

Philadelphia, PA

800 471-8656

San Antonio, TX

888 223-7671

INTERNATIONAL

CONTACTS

Beijing, China

8610 8529-8895

Canada

877 923-8726

Germany

49 6007 930-203

Hong Kong

852 2824-8283

Latin America

954 474-4424

London, U.K.

44 1252 626-730

Melbourne, Australia

61 3 9658-0500

Mexico/Caribbean

954 577-0357

Zürich, Switzerland

41 1 880-2777

ADTRAN is an ISO 9001

registered company.

Printed in the U.S.A. on recycled paper.

61181409L1-8A July 2001

REGULATORY STANDARDS

■NEBS Level 3

■GR-1089-CORE

■UL 1950

MANAGEMENT

■Craft interface, SNMP, TL1

ENVIRONMENTAL

■Operating: –40ºC to + 65ºC

■Storage: –40ºC to + 85ºC

■Relative Humidity: Up to 95 percent,

nocondensing

Ordering Information

EQUIPMENT PART #

Total Access 3000 Octal DS1 IMA.....1181409L1

Specifications subject to change without notice.
