ADTRAN SMART/RG SR360n Bedienungsanleitung

SR360n

Quick Start Guide

Installation

Connect one end of the supplied DSL cable to the port labeled DSL on the gateway

and connect the other end t the DSL wall jack installed by your provider.

For all other devices, connect an Ethernet cable from that device to any of the LAN

ports on the gateway.

Plug the power cord into the wall outlet and into the power jack on the back of the

gateway. For additional protection, connect the power cord to a surge protector.

Turn on the unit by pressing the power button on the gateway.

Your gateway is now automatically being set up to connect to the Internet. This

process may take a few minutes to complete before you can begin using your Inter-

net applications (browser, email, etc.). If you are unable to connect to the Inter-

net, verify that all cable connections are in place and that the router’s power is

turned on.

5 min

POWER LAN 1-4 WL AN DSL INTERNET

DSL sync in progress

DSL sync acquired and gateway online

Gateway online and data transfer in progress

IP connection failure

WiFi enabled on modem

PC / network activity / data transfer

WPS Setup procedure in progress

WPS Connection completed successfully

: On : Off : Blinking / Active

LED Indicators

The LEDs on the front of the SR360n

can assist you in better understanding

the current state of your gateway.

Quick Gateway Configuration

Warning: Do not press the Reset button unless you want to clear the current settings. The

Reset button is in a small circular hole on the rear panel. If you want to restore the default

settings, insert a thin wire (such as a paper clip) into the hole, press gently for 1 second, and

then release the button. The system reboots and returns to the factory defaults.

Logging in to your gateway

To change the settings on your gateway, you must log in to the gateway's interface. Make

sure that you have completed the steps in "Installation" before you begin.

1. Open your internet browser application and type 192.168.1.1 into the address line.

The login dialog appears.

2. Enter the default username and password: admin/admin, and click OK. The Device

Info summary page appears.

Note: Your service provider may use other settings. Please contact your provider for

Configuring the WAN manually

If the automatic connect process is unsuccessful, refer to the Advanced Setup >Layer 2

Interface and WAN Services sections of the SmartRG SR360n Gateway User Manual to manu-

ally establish a connection.

WiFi Setup

Two methods, WPS and Manual, are available for WiFi setup. Perform the steps on this

page for both methods, and then follow the instructions for the method you desire.

In the left navigation bar, click Wireless >Basic.

If not already selected, click Enable Wireless.

If desired, in the SSID field, enter the network name to which you want your client

devices connected. Continue with the steps in the method you prefer.

WPS Method

If the device you want to connect to the Internet via your SmartRG gateway supports the

WPS secure WiFi connection method, you may follow these steps.

1. In the left navigation bar, click Wireless >Security.

2. If the Enable WPS field is not already set to Enabled, select it now.

3. Click Apply/Save to commit your selection.

4. On the top of the gateway, press the WPS button.

5. Within 2 minutes, activate WPS on the 3rd party device to which you wish to connect.

It may have a pushbutton on its exterior or a software interface is used to initiate

WPS connection. To learn how to use the WPS feature on your client device, refer to

its documentation.

Your device should now be connected to your router wirelessly using WPS. If you encounter

problems with the WPS setup such as connection failure, refer to your client device for fur-

ther instructions.

Manual Method

Set up your gateway’s parameters first, then follow these steps.

1. In the left navigation bar, select Wireless >Security and scroll down to the Manual

Setup AP section.

2. If your gateway supports multiple wireless networks, select the SSID of the network

you wish to configure. You will need this ID for step 7.

3. Select the desired Network Authentication. Make sure that the host devices you

intend to use support the selected authentication type.
