Adtron 610200094 Bedienungsanleitung
Adtron Corporation
Rev. 003
PN: 610200094
I
I3
35
5M
MB
B
-
-
3
3.
.5
5”
”
M
Mi
ir
rr
ro
or
re
ed
d
H
Ha
ar
rd
d
D
Di
is
sk
k
O
Op
pe
er
ra
at
ti
io
on
ns
s
M
Ma
an
nu
ua
al
l
March 2006
ESD Warning
Before handling the I35MB, or any media associated with the I35MB, ensure that you are working in an ESD-safe
environment.
Notice
This manual describes the features of the Adtron I35MB. Adtron reserves the right to modify, amend, or in any way change the
contents and/or products described herein, at any time, without notification.
The information contained in this document is provided for reference only. Adtron Corporation does not assume any liability arising
out of the application or use of the products described herein. This document may contain or reference information or products
protected by copyrights or patents and does not convey any license under the patent rights of Adtron Corporation, nor the rights of
others. Errors in this document may be reported in writing to the following address:
Adtron Corporation
4415 E. Cotton Center Blvd.
Phoenix, AZ 85040
Tel: 602-735-0300, Europe +41-56-496-5640
Fax: 602-735-0359, Europe +41-56-496-5648
www.adtron.com
Adtron Corporation is an ISO 9001:2000 certified company.
Adtron logo is a trademark of Adtron Corporation.
All other names mentioned are trademarks, registered trademarks, or service marks of their respective companies.
2006 Adtron Corporation. All rights reserved.
Rev. 003, PN: 610200094
i
Table of Contents
Introduction 1
I35MB Features 1
Related Documents 2
I35MB Jumper Settings 2
Setting Master/Slave and Cable Select 3
Setting a Remote-Mounted Activity LED 3
Interface Connectors 4
I35MB Installation 4
Introduction 4
Inserting the I35MB 5
Removing the I35MB 6
Basic Operation 6
Partitioning and Formatting 6
Operating System Installation 6
I35MB LEDs and Mirror Control Buttons 7
Mirror Control Button Functions 8
Advanced Operations 8
Managing Faults 8
Bank Hard Faults 9
Bank Soft Faults 9
Turning the Buzzer Off 10
Changing Media 10
Resetting Mirroring Indicators 12
Rebuilding a bank 13
Rebuilding a Bank Off-line 13
Using Different Size Media 13
Aborting a button press 14
Using the I35MB Rail Kit 15
S.M.A.R.T. (Self-Monitoring, Analysis and
Reporting Technology) Attributes 16
S.M.A.R.T Attribute Table 17
S.M.A.R.T Attribute Notes 18
LED Indicators 19
IDLE State – No host access 19
ACTIVE State – Host access 20
I35MB Dimension Drawings 21
Appendix I 22
Sales and Technical Support 23
Standard Warranty 23
Revision Control 24
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
1
Introduction
The Adtron™ Diskpak™ Model I35MB with Adtron ActiveRAID™ technology
incorporates RAID-1 mirroring in a 3.5-inch hard disk form factor. RAID-1 mirroring
between two hard disk drives provides data redundancy and rebuild independent
from the host CPU. With both disk drives functioning properly, the I35MB keeps
both disk drives automatically updated. If one of the drives fails, the system
continues to operate on a single disk drive until the I35MB is removed from the
chassis and the failed drive is replaced. When the I35MB is reconnected and
powered up, a rebuild can be initiated on the I35MB concurrent with host activity.
Once the rebuild is manually started, it continues unattended until complete.
ActiveRAID technology significantly reduces the probability of a data storage failure
causing an overall system failure.
Figure 1 I35MB
I35MB Features
•Adtron ActiveRAID™ technology, featuring RAID-1 mirrored disk drives
independent of host CPU
•ATA/ATAPI-5 ANSI NCITS340-2000 compliant; supporting PIO, Multiword
DMA, and Ultra DMA interfaces and transfer rates
•Standard IDE 40-pin connector, high speed parallel ATA interface
•S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) Attributes
(Refer to the section of this manual titled S.M.A.R.T. Attributes for more
information)
•Audio and visual indicators warn of faults
•Operator initiated, automatic rebuild functions transparent to the host CPU
•Host operations continue with a single faulted disk drive or during a rebuild
•Full error detection and management without host intervention
•Field upgradeable firmware prevents future obsolescence
Power Connector
Bank 0
40-pin Connector
IDE Jumper Options
LEDs, Buzzer, and
Mirror Control
buttons
Flex Cable
Bank 1
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
2
Related Documents
•ANSI NCITS 340-2000 ATA/ATAPI-5 Specification
•I35MB Product Specification
•I35MB Installation Manual
Static Sensitive – The I35MB is a static sensitive device. While setting
jumpers, take precautions to ensure that static does not discharge into the
I35MB.
I35MB Jumper Settings
The master/slave and remote LED jumper is located on the front of the I35MB,
between the IDE and power connectors. This jumper is used to set master, slave,
cable select configurations and to mount a remote Activity LED. Refer to Figure 2 for
the location of this jumper.
The following figure shows the jumper location on the I35MB:
40-pin connector
IDE jumper options
Power connector
40 2 4 1
5 1
6 2
39 1
Figure 2 I35MB Jumper Locations
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
3
Setting Master/Slave and Cable Select
This IDE jumper is only for the configuration of master, slave, cable select and to
mount a remote Activity LED. Figure 3 shows the pins of the IDE jumper on the
I35MB.
1
3
42
5
6
1
3
42
5
6
1
3
42
5
6
Master Setting
Slave Setting
Cable Select Setting
4
42
2
7
8
7
8
7
8
Figure 3 IDE Jumper
When a jumper is placed on pins 3 and 4, the I35MB is the master device (default).
With a jumper placed on pins 1 and 2, the I35MB is the slave device. When a jumper
is placed on pins 1 and 3, the cable select configuration is utilized. Refer to the above
Figure for pins and jumper placements.
Setting a Remote-Mounted Activity LED
A remote-mounted Activity LED may be used with the I35MB. Refer to Figure 4 for
the pin location and setting.
1
3
42
5
6
+3.3V
-EXTLED
Through 120 ohm on-board resistor
7
8
Figure 4 I35MB Remote LED
Pins 5 and 6 in Figure 4 are used for a remote-mounted Activity LED. Pin 6 runs
through a 120 Ohm resistor to +3.3V. See the I35MB Product Specification for signal
descriptions.
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
4
Interface Connectors
The I35MB has an interface connector located on the front panel. Using an 80-
conductor cable (40-pin connector); connect the I35MB to the primary or secondary
ports on the IDE controller. Plug a power cable from the computer’s power supply
into the I35MB power connector. The I35MB does not require 12V. Refer to the
Figure below, for the location 40-pin connector and power supply.
40-pin connector 4-pin Power
connector
Figure 5 I35MB interface
I35MB Installation
Introduction
The I35MB is a 3.5-inch hard disk drive and mounts into a standard 3.5-inch hard
disk drive bay. The drive may be mounted from the side or the bottom.
DO NOT exceed the maximum insertion depth of 3.8mm [.150”] from drive edge.
Consider the length of the screw used and thickness of the mounting surface. A
common screw length of 3/16” is provided, but may not be correct in all
applications.
Refer to Figure 6 on page 5 for mounting hole locations.
Static Sensitive - The I35MB is a static sensitive device. When installing
and uninstalling the I35MB, take precautions to ensure that static does not
discharge into the I35MB.
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
5
Inserting the I35MB
To install the I35MB in the hard disk drive bay:
1. Power down the computer and remove the cover.
2. Make sure that you are properly grounded.
3. Set the master/slave to desired configurations. By default, the I35MB is set to
master.
4. Select a 3.5-inch drive bay that houses either a floppy or hard disk. If the chassis
provides a front removable panel, the buzzer reset and fault LEDs can be viewed
by removing the plastic panel on the chassis.
5. Using an 80-conductor cable (40-pin connector) connect the I35MB to the IDE
primary or secondary IDE ports.
6. Connect the power supply to the I35MB.
7. Mount the I35MB into the appropriate disk drive bay, using screws to secure the
I35MB in the chassis. See Figure 6 for mounting holes, screw size and maximum
depth.
8. Put the cover on the chassis and screw it down.
9. Power on the computer.
6-32 x 3.8mm[.
150"] MAX. DEPTH
Figure 6 Mounting Holes
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
6
Removing the I35MB
To remove the I35MB from the hard disk drive bay:
1. Make sure that you are properly grounded.
2. Power down the computer.
3. Remove the chassis casing.
4. Disconnect the 80-conductor cable and the computer power supply cable from
the I35MB.
5. Unfasten the mounting screws and remove the I35MB from the disk drive bay.
Basic Operation
The I35MB operates as a storage subsystem that can be used as a boot device or as
additional storage.
Partitioning and Formatting
To the operating system, the I35MB looks like a single disk drive. All RAID-1
functions occurring in the I35MB are transparent to the operating system. Use the
operating system utilities to partition and/or format the I35MB hard disk drive.
Operating System Installation
The I35MB can be formatted like any standard hard disk drive – bootable for
operating system function or not bootable. Any standard disk partitioning and
formatting utility can be used. Any operating system chosen that is compatible with
IDE devices will be acceptable for use with the I35MB. The method of installing a
specific operating system can vary, so consult the operating system documentation
for instructions.
Adtron I35MB Operations Manual
Rev. 003, PN: 610200094
7
I35MB LEDs and Mirror Control Buttons
D14
D13
D12
D11
D10
Activity LED
Bank 0 Access LED
Bank 0 Fault LED
Bank 1 Access LED
Bank 1 Fault LED
S4
Buzzer Reset
S2
Bank 0 Mirror Control
S3
Bank 1 Mirror Control
Figure 7 LEDs and Mirror controls
The LEDs are used to indicate individual Bank status (access/fault), media activity
(read/writes) and Mirror status. Table 1 describes LED states, mirror status and
controls.
The following table describes the LED states:
Activity LED (D10) Description
Green No access; Power is on
Orange - flashing Reads or writes occurring on hard disk
Orange – flashing in a
set pattern
Indicates an issue with the I35MB
Bank LED Description Color - State
D11 Bank 0 access Green solid – Power on
D12 Bank 0 fault Orange solid – Hard fault
Orange flashing – Soft fault
D13 Bank 1 access Green solid – Power on
D14 Bank 1 fault Orange solid – Hard fault
Orange flashing – Soft fault
Mirror Control Description Function
S4 Buzzer reset Audible alarm indicates
error. Push button to turn
off.
S2 Bank 0 Mirror control Controls Bank 0 mirroring
S3 Bank 1 Mirror control Controls Bank 1 mirroring
Table 1 I35MB LED states and Mirror controls
