Advantech IPC-644 Series Bedienungsanleitung

IPC-644 Series

4-slot MicroBox

IPC Chassis

User's Manual

This document is copyrighted, May 1999, by Advantech Co.,

Ltd. All rights are reserved. Advantech Co., Ltd. reserves the

right to make improvements to the products described in this

manual at any time without notice.

No part of this manual may be reproduced, copied, translated or

transmitted in any form or by any means without the prior

written permission of Advantech Co., Ltd. Information provid-

ed in this manual is intended to be accurate and reliable.

However, Advantech Co., Ltd. assumes no responsibility for its

use, nor for any infringements of the rights of third parties

which may result from its use.

Acknowledgments

IPC-644, PCA-6104-B and PCA-6104NP2 are all trademarks of

Advantech Co., Ltd.

Part No. 2002064410

2nd Edition Printed in Taiwan May 1999

Contents

Chapter 1 General Information 1

1.1 Introduction.......................................................... 1

1.2 Specifications ...................................................... 1

1.3 Dimensions.......................................................... 4

1.4 Mounting.............................................................. 5

1.5 IPC-644 Exploded Diagrams ............................... 6

1.6 PCA-6104-B Diagram.......................................... 7

1.7 PCA-6104NP2 Diagram ...................................... 8

Chapter 2 System Setup 9

2.1 Removing the Top Cover..................................... 9

2.2 Replacing the Filter............................................ 10

2.3 Installing the FDD and HDD .............................. 11

2.4 Installing the Cards............................................ 13

Appendix A Safety Instructions 15

A.1 English............................................................... 15

A.2 Wichtige Sicherheishinweise ............................. 16

Figures

Figure 2-1: Removing the top cover ................................................................9

Figure 2-2: Replacing the filter.......................................................................10

Figure 2-3: Installing the FDD and HDD ........................................................12

Chapter 1 General Information

1.1 Introduction

The IPC-644 MicroBox IPC chassis is an ultra-compact 4-slot

mini-node chassis that is ideal for embedded applications. Its

small size enables it to fit in mobile environments such as

boats, cars and other vehicles. Naturally, indoor operation is

equally suitable.

The IPC-644 comes with a 4-slot backplane. You can choose

between a 4 ISA backplane, or a 1 ISA / 2 PCI / 1 NLX back-

plane, both of which can hold up to 4 half-size cards. As for

power supply, the IPC-644 can either run on 110/220 V auto-

switching 80 W AC, or on a 24/48 VDC power source.

A drive bay located at the front of the IPC-644 accommodates

one 3.5" floppy drive and one 3.5" hard drive. The front panel

is equipped with a power reset switch and facilitates easy

diagnostics. Other features include two reserved 9/25-pin I/O

ports, two cooling fans for ample heat dissipation, and a fan

filter. All of these are easy to install and maintain.

IPC-644 User's Manual

1.2 Specifications

General

•Construction: Heavy-duty steel

•Controls: AC power on/off and reset switches

•Cooling fans: One 49 CFM filtered cooling fan for inward

airflow, and one 14 CFM cooling fan (flow-in) for outward

airflow

•Mounting: On wall or desktop

•Dimensions (W x H x D):135 x 209 x 305 mm

(5.3" x 8.2" x 12")

•Weight: 3.83 kg (8.4 lbs)

•Driver bay: Vibration damped; holds one 3.5" FDD and one

3.5" HDD

•Indicators: LEDs for HDD activity and power on

•Chassis color: PANTONE 414U

Passive backplanes

PCA-6104-B

•Slots: 4 (1 ISA-bus)

•PC board: 4-layered

PCA-6104NP2

•Slots: 4 (1 ISA / 2 PCI / 1 NLX CPU)

•PC board: 4-layered

Chapter 1 General Information

Power supply

PS-80

•Output rating: 80 watts maximum

•Input voltage: 85 ~ 264 VAC @ 47 ~ 440 Hz

•Output voltage: +5 V @ 8 A, +12 V @ 3.5 A, -12 V @ 1 A

•MTBF: 50,000 hours

•Safety: UL/CSA/TUV/VDE/CB/NEMKO/BABT/CE compli-

ant

•EMI: FCC Class B, CISPR Class B

Environment

•Operating temperature: 0 ~ 50° C (32 ~ 122° F)

•Relative humidity: 10 ~ 95% @ 40° C

•EMI: CE compliant

•Safety: CE compliant, UL and C-UL approved

•Shock resistance: 50 G, 11 ms, 3 shocks per face, half

sine-wave (non-operating)

•Acoustic noise level: Position length = 25 cm,

height = 120 cm, angle = 30°, 55 db (r.m.s.)

IPC-644 User's Manual

Unit = mm

(inches)

1.3 Dimensions

Chapter 1 General Information

1.4 Mounting

The IPC-644 can either be wall mounted or desktop mounted.

Refer to the figures below for how to install the brackets.

Wall mounting Desktop mounting

IPC-644 User's Manual

1.5 IPC-644 Exploded Diagrams

Chapter 1 General Information

1.6 PCA-6104-B Diagram

4 ISA slot backplane

Dimensions: 186 x 95 mm

Unit = mm
