AIW-357 DK-G2U

User Manual

Applicability Type

AIW PN

MPN

Description

AIW-357 DK-G2U

XS5G03-GBO

MediaTek T700 NR SUB6/LTE FDD/LTE

TDD/WCDMA M.2 3052 module B key, W/O SIM

holder; w/o voice function; Only USB communication

interface, for USA, Europe, Japan and Taiwan

region

Revision History

Version

Date

Description

V1.0

2023-06-07

First issue

V1.1

2023-07-10

Section 2.10 edit LED Signal picture

V1.2

2023-08-16

Add Section 5.1 Product picture

V1.3

2023-08-23

1. Add Section 2.1 pin map schematic

2. Add Section 2.6.1~2.6.3 USIM N.C./ N.O. description

Overall Description

1.1 Function Overview

Features

Description

Dimensions

(L × W × H): 52 mm × 30 mm × 2.4 mm (Max)

Weight

8.7g

Voltage

3.135V ~3.63V, typical 3.3V

Operating Temperature

-30 ~ 70℃

Operating Humidity

less than 85% R.H.

Storage Temperature

-40 ~ 85℃

Storage Humidity

less than 60% R.H.

Extend Temperature

-30 ~ 80℃

Table 1-1 Features

Note:

Thermal solutions are necessary to be put on module, so that module can work smoothly

in operating temperature range. For example, thermal pad, heat sink, fan.

1.2 Product Specification and Frequency Bands

AIW-357 DK-G2U is standard version with GPS function.

Cellular

Item

AIW-357 DK-G2U

5G NR

Standard

3GPP Release 15

SA Bands

n1/2/3/5/7/8/20/25/28/30/38/40/41/48/66/71/ 77/78/79

NSA Bands

n1/2/3/5/8/20/28/38/41/66/71/77/78/79

Sub-6 CA

FDD/TDD+FDD/TDD DL CA*

DL 4x4 MIMO

n1/2/3/7/25/30/38/40/ 41/48/66/77/78/79

UL 2x2 MIMO

n41/77/78/79

Model

AIW-357 DK-G2U

4G LTE

LTE Category

Cat 12

LTE Bands

B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/

28/29/30/32/34/38/39/40/41/42/43/46/48/66/71

DL CA

4x4 MIMO, 3CC

UL CA

2CC

UMTS/

WCDMA

Bands

B1/2/4/5/8

GPS

UL 2x2 MIMO

GPS/GLONASS/BeiDou/ Galileo

Frequency Band

Table 1-2 Product Specification and Frequency Bands

1.3 Circuit Block Diagram

The circuit block diagram is shown in Figure 1-1.

The major functional units are listed below:

Power Management

Baseband Controller

MCP (4Gb LPDDR4X+4Gb Nand Flash)

RF Circuit

eSIM (option)

Figure 1-1 Circuit block diagram of the module

1.4 Application Interface

Features

Description

External Power Supply:

DC 3.3V Typical

USB Interface:

USB3.1 Gen1 x 1, USB2.0 x 1

Audio Interface:

I2S x 1

I2C Interface:

I2C × 1

USIM Interface:

USIM × 1, eSIM x 1 (optional)

RF Ipex4 connector:

RF Ipex4 connector × 4

Table 1-3 Application Interface

Description of the Application Interfaces

2.1 M.2 Key B Interface

Pin No.

AIW-357 DK-G2U M.2 module uses standard key B interface

Pin No.

+3.3V

CONFIG_2 (GND)

+3.3V

VIO_CFG

+3.3V

GND

CONFIG_1 (GND)

SIM Detect (I) (1.8V)

RESET# (I) (1.8V)

COEX1 (IO) (1.8V)

ANTCTL3 (O) (1.8V)

COEX2 (IO) (1.8V)

ANTCTL2 (O) (1.8V)

COEX3 (IO) (1.8V)

ANTCTL1 (O) (1.8V)

MIPI2_D_SDATA (IO) (1.8V)

ANTCTL0 (O) (1.8V)

MIPI2_D_SCLK (O) (1.8V)

GND

I2C_IRQ# (I) (1.8V)

GND

I2C_SDA (IO) (1.8V)

I2C_SCL (O) (1.8V)

GND

USIM1_PWR (O)

USB3.0_RX+

USIM1_DATA (IO)

USB3.0_RX-

USIM1_CLK (O)

GND

USIM1_RESET (O)

USB3.0_TX+

I2S0_LRCK (IO) (1.8V)

USB3.0_TX-

W_DISABLE2# (I) (3.3/1.8V)

GND

I2S0_DO (O) (1.8V)

DPR (I) (1.8V)

I2S0_DI (I) (1.8V)

WOWWAN# (IO) (1.8V)

I2S0_BCK (IO) (1.8V)

CONFIG_0 (GND)

Notch

LED1# (O) (3.3V)

GND

W_DISABLE1# (I) (3.3/1.8V)

USB_D-

FULL_CARD_POWER_OFF# (I)

(3.3/1.8V)

USB_D+

+3.3V

GND

+3.3V

GND

CONFIG_3 (NC)

Figure 2-1 AIW-357 DK-G2U Pin Map

Pin Name

Description

Voltage

Type

CONFIG_3

Setting vale: NC

The interface of AIW-357 DK-G2U

module is configured as the WWAN –

PCIe Gen3, USB3.1 Gen1

+3.3V

Power supply for Module

3.135-3.63V

GND

Module ground pin

+3.3V

Power supply for Module

3.135-3.63V

GND

Module ground pin

FULL_CARD

Pull high to 1.4V~module input

3.3/ 1.8V

_POWER_OFF#

voltage to enable power of the module

USB_D+

USB2.0 differential data –plus

AIO

W_DISABLE1#

The pin use for WWAN disable,

3.3/ 1.8V

active low

USB_D-

USB2.0 differential data –minus

AIO

LED1#

Open drain, active low signal.

3.3V

The signal is used to allow the add-in

card to provide status indicators

via LED devices that will be provided

by the system.

GND

Module ground pin

Notch
