Advantech AIMB-224 Installations- und Betriebshandbuch

AIMB-224 Startup Manual 1

Before you begin installing your single board, please make

sure that the following materials have been shipped:

1. 1 x AIMB-224 Mini ITX Motherboard

2. 1 x CD-ROM or DVD-ROM contains the following:

- User’s Manual

- Drivers

3. 1 x Serial port cable

4. 2 x SATA HDD Data cable

5. 2 x SATA Power cable

6. 1 x I/O shield

7. 1 x CPU cooler

8. 1 x Startup manual

9. 1 x Warranty card

AIMB-224 Mobile AMD R-series Qual Core/Dual Core

FS1r2 socket Mini-ITX Motherboard with VGA/LVDS/

Display Port, 6 COMs and Dual LAN

Startup Manual

Processor System

• CPU: Support AMD R-series Quald Core 2.3 GHz/Quad

Core 1.9 GHz/ Dual Core 2.7 GHz / Dual Core 2.5 GHz

FS1r2 socket type processor

• Max. Speed: 2.3 GHz (Quald Core)

• L2 Cache: 1 MB/per core

• Chipset: A75M

• BIOS: 16 Mbit SPI

Expansion Slot

• Mini-PCIe: 2 (1 Full-size colay mSATA/ 1 Half-size)

• PCIe: PCIe x 8 (PCIe gen 3)

Memory

• Technology: Dual channels DDR3 1333/1600 MHz

• Max. Capacity: 16 GB

• Socket: 2 x 204-pin SODIMM

Graphic Interface

• Controller: AMD Radeon™ GPUs (RadeonTM HD 7xxx),

support DirectX 11, UVD3

• VGA: Supports up to 4096 x 2400 @ 60 Hz

• LVDS:Supports 24-bit dual channel and 1920 x 1200

• Display Port: Two dual model display port, max resolu-

tion: 1920 x 1200@60 Hz

• Triple Display: Supports Triple display of CRT/LVDS/DP

• Dual Display: Supports dual display of any two display

device (CRT, LVDS, DP)

Ethernet Interface

• Interface: 10/100/1000 Mbps

• Controller: GbE LAN1: RTL8111E;

GbE LAN2: RTL8111E

• Connector: RJ-45 x 2

SATA Interface

• Max Data Transfer Rate: 600 MB/s

• Channel: 3

Rear I/O

• VGA: 1

• DP: 2

• Ethernet: 2

• USB: 4 (2 USB 3.0 / 2 USB 2.0)

• Audio: 3 (Mic-in, Line-out, Line-in)

• Serial: 1 (RS-232)

• PS/2: 1

• DCIN Jack: 1

Specications

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/epc

For technical support and service, please visit our

support website at:

http://service.advantech.com.tw/eservice/

This manual is for the AIMB-224 series Rev. A1

Part No. 2006022410 1st Edition

October 2011

Packing List

2 AIMB-224 Startup Manual

Internal Connector

• LVDS & Inverter: 1

• USB: 6 (USB 2.0 compliant)

• Serial: 5 (1 RS-232/422/485, 4 RS-232, COM3 supports

5 V/12 V by jumper selection; COM6 supports RS-

232/422/485 function)

• SATA: 3

• DIO: 8-bit GPIO

Watchdog Timer

• Output: System reset

• Interval: Programmable 1 ~ 255 sec/min

Power Requirement

• Typical: DCIN 12 V or ATX 4 pin 12 V

Environment

• Temperature:

0 ~ 60° C (32 ~ 140° F), Operating

-40 ~ 85° C (-40 ~ 185° F), Non-operating

Physical Characteristics

• Dimensions: 170 mm x 170 mm (6.69” x 6.69”)

The board has a number of connectors and jumpers that

help conﬁgure the system to suit your application require-

ments. The tables below list the function of each of the

connectors and jumpers.

Connector List

Label Function

FPAUD1 Front Panel audio connector

AUDIO1 Audio connector

CMOS1 CMOS clear ( Default 1-2 )

DIMM1_A1/B1 Memory connector channel

COM3-6 Serial port: 3RS232/1RS-232-422/485

COM2 Serial port: RS-232

CPU_FAN1 CPU FAN connector(3-pin)

DIO_CN1 GPIO Header

DCIN1 DC IN

ATX12V1 ATX 12V connector

ATX_5V1 PS_ON , 5VSB

LVDS2 LVDS connector (Internal)

INV2 LVDS Inverter Power

JVBR2 LVDS Brightness control selector for

Analog or Digital (Default 1-2, Analog)

JLVDS3 LVDS voltage jumper (default 1-2, 3.3V)

JLVDS4 LVDS 12V voltage jumper

VCON2 LVDS JEIDA/VESA jumper selection

JFP1+JFP2 Power switch/HDD LED/SMBus/

speaker

JFP3 Power LED and Keyboard lock

JSETCOM6 COM6 RS-232/422/485 Jumper setting

JSETCOM3 COM3 5V/12V Jumper setting

PCIEX8_1 PCI Express X8 slot

KBMS1 PS/2 Keyboard and Mouse external

connector

KBMS2 PS/2 Keyboard and Mouse internal

connector

LAN1_USB01 LAN1 / USB port 1, 2

LAN2_USB23 LAN2 / USB port 3, 4

MINI_PCIE1/2 Mini PCI express connector

PSON1 AT(1-2) / ATX(2-3) ( Default 2-3 )

S ATA 1 Serial ATA data connector 1

SATA2 Serial ATA data connector 2

SATA3 Serial ATA data connector 3

SATA_PWR1 SATA POWER

SATA_PWR2 SATA POWER

DOM_PWR DOM POWER

SPI1 SPI connector

SPI_CN1 SPI ﬂash update connector.

SPDIF_OUT1 Digital Audio connector

SYS_FAN1 System FAN connector(3-pin)

USB456789 USB port 4,5, 6,7,8,9 (on board)

DUAL_DP1 Two Display port connector

VGA1 VGA connector

COM1 COM PORT CONNECTOR

JOBS1+JWDT1 OBS Alarm and Watchdog Reset

BAT1 Battery holder

Jumpers & Connectors

Specications (Cont.)

AIMB-224 Startup Manual 3

LVDS2

Pin Signal

1 VDDSAFE

2 VDDSAFE

3 GND

4 GND

5 VDDSAFE

6 VDDSAFE

7 LVDS_L0_N

8 LVDS_U0_N

9 LVDS_L0_P

10 LVDS_U0_P

11 GND

12 GND

13 LVDS_L1_N

14 LVDS_U1_N

15 LVDS_L1_P

16 LVDS_U1_P

17 GND

18 GND

19 LVDS_L2_N

20 LVDS_U2_N

21 LVDS_L2_P

22 LVDS_U2_P

23 GND

24 GND

25 LVDS_CLKL_N

26 LVDS_CLKU_N

27 LVDS_CLKL_P

28 LVDS_CLKU_P

29 GND

30 GND

31 LVDS_CH7511_DDC_CLK

32 LVDS_CH7511_DDC_DATA

33 GND

34 GND

35 LVDS_L3_N

36 LVDS_U3_N

37 LVDS_L3_P

38 LVDS_U3_P

39 N22140709

40 VCON

JLVDS3 (LVDS Voltage jumper selection)

Pin Signal

pin1 12 V

pin 2 VDDSAFE_IN

JLVDS4 (LVDS voltage jumper selection)

Pin Signal

PIN1-2 3 V

PIN2-3 5 V

LVDS Inverter PWR

Pin Signal

1 12 V

2 GND

3 BL_EN

4 BL_CNL

5 5 V

JVBR2 (Brightness control selection)

Pin Signal

1 BL_Control

2 GND

3 NC

JWDT1+JOBS1

Pin Signal

1 NC

2SIO_WG

3SYS_RST

4ERR_BEEP

5BEEP

Jumpers & Connectors

4 AIMB-224 Startup Manual

9 +5 V

10 GND

PSON1

Pin Function

1 FRP_PANSWIN#_AT

2 FRP_PANSWIN#

3 NC

SPDIF_OUT

Pin Function

1 +5 V

3 SPDIF_0

4 GND

JSETCOM3

Pin Function

1 COM3P9SEL

2 RRI3

3 COM3P9SEL

4 5 V

5 COM3P9SEL

6 12V

JSETCOM3

Pin Signal

1 +12 V

2 RI6xPOWERxJMP

3 COM6_RI#

4 RI6xPOWERxJMP

5 +5 V

6 RI6xPOWERxJMP

USB45

Pin Signal

1 +SBV45

2 +SBV45

3 USBP4-

4 USBP5-

JFP1+JFP2

Pin Signal

1 +5 V

2 HDLED+

3 FRP_PANSWIN#

4 SPK_CN17P2

5 HDD_LED-

6 GND(R1160:100OHM)

7 SPK_CN17P4

8 SMBDATA_R

9 FRP_RST#

10 SPK_CN17P3

11 SMBCLK_R

12 GND

JFP3

Pin Signal

1POWER LED

2NC

3GND

4KEYLOCK

5GND

ATX5V1

Pin Function

1 5 VSB_IN

2 GND

3 PS_ON#

DIO_CN1

Pin Function

1 DIO0

2 DIO4

3 DIO1

4 DIO5

5 DIO2

6 DIO6

7 DIO3

8 DIO7

Jumpers & Connectors

AIMB-224 Startup Manual 5

5 USBP4+

6 USBP5+

7 GND

8 GND

10 GND

USB67

Pin Signal

1 +SBV67

2 +SBV67

3 USBP6-

4 USBP7-

5 USBP6+

6 USBP7+

7 GND

8 GND

10 GND

JCMOS1

Pin Signal

1 NC

2 RTC_RST#

3 GND

SPI_CN1

Pin Signal

1 +V3.3M_SPI

2 GND

3 SPI_CS#

4 SPI_CLK

5 SPI_MISO

6 SPI_MOSI

8 NC

CPU_FAN, SYS_FAN

Pin Signal

1GND

2+12VPWM

3Sensor

3 6 9 12

2 5 8 11

1 4 7 10

JFP1+JFP2

PIN Signal

1 +5V

2 HDLED+

3 FRP_PANSWIN#

4 SPK_CN17P2

5 HDD_LED-

6 GND(R1160:100OHM)

7 SPK_CN17P4

8 SMBDATA_R

9 FRP_RST#

10 SPK_CN17P3

11 SMBCLK_R

12 GND

Declaration of Conformity

The device complies with the requirements in Part 15 of

the FCC rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference;

2. This device must accept any interference received,

including interference that may cause undesired

operation.

Software Installation

The CD disc contains a driver installer program that will lead

you through the installation as various device drivers are

needed to take full advantage of your motherboard.

Caution! The computer is supplied with a battery-powered

real-time clock circuit. There is a danger of explo-

sion if the battery is incorrectly replaced. Replace

only wih same or equivalent type recommended

by the manufaturer. Discard used batteries ac-

cording to manufaturer’s instructions.

Jumpers & Connectors Installation Note

6 AIMB-224 Startup Manual

MINI_PCIE1

SATA_PWR

CPUFAN1

SATA_PWR2

KBMS2

ATX12V1

COM2

SATA2

SATA3

USB89

DOM_PWR1

SATA1

USB45

USB67

SPI1

BAT1

INV2

SPDIF_OUT

JCMOS1

FPAUDIO1

JAMP1

SYSFAN1

DDR_PWR1

JWDT1+JOBS1

JFP3

JFP1+JFP2

PSON1

DIO_CN1 JESTCOM6

DIMM_B1

DIMM_A1

ATX5V1

COM3-6

JSETCOM3

SPI_CN1

JVBR2

JLVDS4

VCON2

JLVDS3

EDP1

LVDS2

DCIN1 KBMS1 DUAL_DP1 COM1 VGA LANUSB01 LANUSB23

AUDIO1

MINI_PCIE2

Board Diagram

Inhaltsverzeichnis

Andere Advantech Hauptplatine Handbücher

Advantech

Advantech PCI-7020F PCI-7020VG PCI-7020LV PCI-7020 Bedienungsanleitung

Advantech

Advantech MIC-3355 Bedienungsanleitung

Advantech

Advantech PCM-5824 Installations- und Betriebshandbuch

Advantech

Advantech PPC-MB-610 Installations- und Betriebshandbuch

Advantech

Advantech ASR-1000K-00A1E Installations- und Betriebshandbuch

Advantech

Advantech RSB-4680 Bedienungsanleitung

Advantech

Advantech AIMB-U217 Bedienungsanleitung

Advantech

Advantech AIMB-330F Bedienungsanleitung

Advantech

Advantech MIC-3385 Bedienungsanleitung

Advantech

Advantech PCA-6166 Bedienungsanleitung

Advantech

Advantech ASMB-925 Series Bedienungsanleitung

Advantech

Advantech ASMB-920IR Bedienungsanleitung

Advantech

Advantech AIMB-U117 Bedienungsanleitung

Advantech

Advantech AIMB-785 Installations- und Betriebshandbuch

Advantech

Advantech PCA-6144V Bedienungsanleitung

Advantech

Advantech RSB-6410 Bedienungsanleitung

Advantech

Advantech INTEL PCM-9587 Bedienungsanleitung

Advantech

Advantech MIO-2360 SBC Installations- und Betriebshandbuch

Advantech

Advantech PCE-7129 Installations- und Betriebshandbuch

Advantech

Advantech AIMB-782 Bedienungsanleitung

Advantech

Advantech AIMB-281 Bedienungsanleitung

Advantech

Advantech RSB-4210 Evaluation Kit Bedienungsanleitung

Advantech

Advantech AIMB-270 Bedienungsanleitung

Advantech

Advantech AIMB-740 Series Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
