AED AUDIO FLEX6 Bedienungsanleitung

This manual is subject to change without further notice. No rights can be derived from this manual. No part

of this manual may be reproduced, in any form or by any means, without prior written consent from AED

Distribution NV, Belgium. AED Audio is a registered trademark of AED Distribution NV.

User manual

 Installation and User instructions
Version:
V1.2.0
Date:
04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com





Table of contents

The AED Audio Flex6 Manual.......................................................................................................4
Introduction................................................................................................................................4
Disclaimers ................................................................................................................................4
Intended use..............................................................................................................................4
Symbol description .................................................................................................................... 5
Symbols used......................................................................................................................... 5
Abbreviations used.................................................................................................................... 5
Revision history...................................................................................................................... 5
Contact details Manufacturer..................................................................................................... 6
Manufacturer’s declarations ...................................................................................................... 6
EU declaration of conformity..................................................................................................6
Licenses and credits .............................................................................................................. 6
General Safety information and general safety instructions .........................................................7
Warnings.................................................................................................................................... 7
Safety features & devices of the Product .................................................................................. 7
Other safety notes ..................................................................................................................... 8
Modification................................................................................................................................8
System components...................................................................................................................... 9
General characteristics and technical specifications................................................................. 9
Technical data........................................................................................................................9
 Dimensions drawing ...............................................................................................................10
Transportation, handling and commissioning ............................................................................. 11
Transportation..........................................................................................................................11
Remove the shipping assembly............................................................................................... 11
Installation ...................................................................................................................................11
Loudspeaker configurations........................................................................................................12
Accessories .............................................................................................................................13
Operation.....................................................................................................................................15
Powering on/ off.......................................................................................................................15
Using the main menu...............................................................................................................15
Maintenance................................................................................................................................16
Troubleshooting and repair .........................................................................................................16
Fault list ...................................................................................................................................16

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

Repair ......................................................................................................................................17

Contact details certified repair center .................................................................................. 17

Notes...........................................................................................................................................18

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

The AED Audio Flex6 Manual

Introduction

Thank you for purchasing this AED Audio Flex6.

The FLEX6 loudspeaker is the only professional multipurpose audio product available

worldwide on the market, useable for a variety of applications. Because of its multi-purpose way

of deployment, this 1.300W RMS powered speaker can be used in several ways. Put the FLEX6

on a pole, stack it and create a column array, fly it as a line array up to sixteen cabinets, put two

horizontally on a pole in a sub-top combination, etc.

This manual (hereinafter referred to as the “Manual”) is intended to be used as work of

reference for professional, well trained and authorized users to be able to safely install, use,

maintain and repair the product mentioned on the cover of this document (hereinafter referred to

as the “Product”). The observation of the Manual does not dispense the user from the

observance of the local safety instructions and regulations other than provided by the Manual.

Such safety instructions and regulations must be observed at all time.

For information about specific adjustments, maintenance or repair jobs which are not dealt

within this manual, please contact your Product supplier or AED Audio. If you suspect that the

Product is damaged or detect a potential or actual danger when using the Product, immediately

discontinue use of the Product and contact your supplier. To ensure the safe use of the Product

this Manual must always be kept with the Product in legible condition.

Disclaimers

AED Audio, AED DISTRIBUTION SA, with registered office at Bedrijvenpark De Veert 13/4,

2830 Willebroek (Belgium), or any of its affiliates, does not accept any liability for material

damage, including damage to the Product, or personal injury caused by non-observance by the

user of the safety instructions in the Manual or the applicable laws. As such AED Audio shall

among others not be liable for any damage or injury if the Product is used contrary to or for

purposes other than its intended use, is installed, used, maintained or repaired negligently or

contrary to the instructions mentioned in the Manual or on the Product, when the Product is

modified and when the safety devices and features of the Product are disregarded or

overridden.

Intended use

This system is intended for use by trained personnel for professional applications. The Product

is not intended to be used by minors. Any use, regardless whether or not under the supervision

of an adult, is at own risk.

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

Symbol description

Symbols used

►

Information and tips to ease things for you as you use your AED Audio Flex6.

References to the online AED Audio website, where you can find interesting further

information: https://www.AEDAudio.com

Prompt to take action. This symbol means that you are being prompted to perform

some action.

Abbreviations used

Abbreviation

Definition

Revision history

Version number

date

update

1.0.0

Initial version

1.2.0

Update Overview Accessories

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

Contact details Manufacturer

AED Distribution

Bedrijvenpark De Veert 12,

2830 Willebroek –Belgium

Tel.: +32 3 860 76 66

Mail: [email protected]

http://www.aedaudio.com

Manufacturer’s declarations

EU declaration of conformity

Licenses and credits

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

General Safety information and general safety instructions

For your own safety, please read this instruction manual carefully before turning on the product

for the first time.

Warnings

Always take note of any information marked with the CAUTION or WARNING symbol.

CAUTION

The signal word WARNING points out the potential risk of serious injury.

WARNING

The signal word CAUTION points out the potential risk of slight injury. The

CAUTION symbol is used to draw attention to circumstances which could

cause the machine to become damaged.

Safety features & devices of the Product

The pictograms, warnings and instructions attached to the Product are part of its safety

features. They must not be covered or removed and must be present and legible during the

entire use of the Product. Immediately replace or repair missing, damaged or illegible

pictograms, warnings and instructions.

The products referred to in this manual conform to the European Community

Directives and are therefore marked with CE logo.

Before operate this unit, please carefully read this users guide and keep if

needed in future.

The device can only run with 240V voltage, 50/60 Hz power, don’t connect to

any other wrong power source.

Safety I class device, need to be earth connected.

Keep this device away from children and unauthorized users, the manufacturer

will not take responsibility for the damage due to any disregard of the

information provided in this manual and wrong operation.

Don’t put or install the device on a surface that subject to vibration or bumps.

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

Other safety notes

Errors caused by not following these instructions are not covered by the warranty. The

manufacturer will not accept liability for any resulting defects or problems.

•Keep the unit away from radiators or other heat sources!

•If the unit has been exposed to tremendous temperature changes (e.g. after

transportation), do not turn the device on immediately. The resulting condensation could

damage the unit. Don’t switch the unit on until the device reaches room temperature.

•This device belongs to protection class I. Therefore, it is imperative that the

green/yellow wire is connected to the earth contact or plug. The electrical connection

must be made by a qualified person.

•Make sure that the cable has never been squeezed or damaged by sharp objects.

Check the device and the power cables regulair.

•If the cable is damaged, it must be replaced immediately by the manufacturer, it’s a

service agent or qualified person in order to avoid danger.

•Ensure that wires never come in contact with other wires! Handle the power cord and all

connections with caution!

•Make sure that the line voltage is not higher than the voltage specified in this manual.

•Disconnect the unit from the AC mains when it is not in use or when cleaning it.

•The plug on the power supply cord is used as disconnect device, the socket-outlet shall

be easily accessible.

Modification

Under no circumstances any modification of the Product may be done by any person other than

AED Audio.

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

System components

General characteristics and technical specifications

Technical data

Type

Flex6

Configuration

Multipurpose powered line source speaker

LF transducer

2x 6.5” Neodymium

HF transducer

1x 1.4” 3” voice coil Neodymium

Frequency response -6 dB

65 –18 kHz

Frequency response -10dB

60 –18 kHz

Coverage angle

15° x 100° - rotatable horn

Maximum rated SPL

130 dB

Amplifier

Class D | 1.300W RMS –2.600W peak

AC power input

100 VAC - 3,6A | 120 VAC - 3A | 240 VAC - 1,5A

Controls

Power - Rotary encoder - Selection button - 2x Level

Indicators

LCD display - Rotatable multipurpose front LED indicator (power,

limiter, network, off) - 3x signal LED - Network LEDs

Connectors

2x XLR/F 1/4" combo - 2x XLR/M loop through - 1x XLR/M mix out

- 2x RJ45 4x4 Dante(AES67) & Control

Extra connectivity

Enclosure

Aluminium - Wood

Color

Black (RAL 9011)

Grill

Powder coated steel - Internal lining

Dimensions (WxHxD)

240 x 590 x 395 mm | 9.45 x 23.23 x 15.55 inch

Net Weight

16 kg - 35.27 lb

Attachment

Internal rigging - 2x pole mount

Optional accessories

Yoke –Flex protect - Vertical coupler - Rigging bumper –

Flight case for 2x Flex6 –Touring dolly

Power cable included

Not included

Installation and User instructions

Version:

V1.2.0

Date:

04/10/2023

AED group | Bedrijvenpark De Veert 12, 2830Willebroek - Belgium | +32 3 860 76 66 | www.aedgroup.com

Dimensions drawing

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere AED Sprecher Handbücher

AED

AED MULTI12 Bedienungsanleitung

Beliebte Sprecher Handbücher anderer Marken

argon audio

argon audio IE20 Bedienungsanleitung

Denon

Denon SC-N7 Bedienungsanleitung

Gemline

Gemline Ace 3952 Bedienungsanleitung

Focal

Focal ON WALL 300 Bedienungsanleitung

HEADRUSH

HEADRUSH Maximus HRSP 5024 Bedienungsanleitung

SoundLogic

SoundLogic BCCS-6/6395 Bedienungsanleitung

Peavey

Peavey DTH 218 Bedienungsanleitung

Avantree

Avantree Pluto Air Bedienungsanleitung

Morel

Morel Integra Series INTEGRA OVATION 4 Bedienungsanleitung

Oppo

Oppo SONICA Bedienungsanleitung

Bose

Bose SoundLink Wireless Music System Bedienungsanleitung

Rocksteady

Rocksteady Stadium Bedienungsanleitung

Bowers & Wilkins

Bowers & Wilkins 4 Bedienungsanleitung

Sonance

Sonance SONOS OUTDOOR Series Bedienungsanleitung

Electro-Voice

Electro-Voice EVID FM4.2 Bedienungsanleitung

Pioneer

Pioneer XW-HTD630 Bedienungsanleitung

Onn

Onn BWA16AA002 Bedienungsanleitung

HP GL313AA - USB Speakers PC Multimedia Bedienungsanleitung
