OVEN USER MANUAL

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you

impeccable performance for many years, with innovative technologies that help

make life simpler – features you might not find on ordinary appliances. Please

spend a few minutes reading to get the very best from it.

ACCESSORIES AND CONSUMABLES

In the AEG webshop, you’ll find everything you need to keep all your AEG

appliances looking spotless and working perfectly. Along with a wide range of

accessories designed and built to the high quality standards you would expect,

from specialist cookware to cutlery baskets, from bottle holders to delicate

laundry bags…

Visit the webshop at:

www.aeg.com/shop

CONTENTS

4 Safety information

7 Product description

8 Before first use

9Dailyuse

10 Clock functions

11 Using the accessories

13 Additional functions

13 Helpful hints and tips

23 Care and cleaning

26 What to do if…

27 Installation

30 Environment concerns

31 GREAT BRITAIN & IRELAND -

Guarantee/Customer Service

The following symbols are used in this user

manual:

Important information concerning your

personal safety and information on how to

avoid damaging the appliance.

General information and tips

Environmental information

Subject to change without notice.

Contents 3

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions.

The manufacturer is not responsible if an incorrect installation and use causes injuries and

damages. Always keep the instructions with the appliance for future reference.

Children and vulnerable people safety

WARNING!

Risk of suffocation, injury or permanent disability.

• Do not let persons, children included, with reduced physical sensory, reduced mental

functions or lack of experience and knowledge use the appliance. They must have super-

vision or instruction for the operation of the appliance by a person who is responsible for

their safety.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep children and pets away from the appliance when it operates or when it cools down.

Accessible parts are hot.

• If the appliance has a child safety device, we recommend that you activate it.

Installation

WARNING!

Only a qualified person must install this appliance.

• Remove all the packaging.

• Do not install or use a damaged appliance.

• Obey the installation instruction supplied with the appliance.

• Always be careful when you move the appliance because it is heavy. Always wear safety

gloves.

• Do not pull the appliance by the handle.

• Keep the minimum distance from the other appliances and units.

• Make sure that the appliance is installed below and adjacent safe structures.

• The sides of the appliance must stay adjacent to appliances or to units with the same

height.

Electrical connection

WARNING!

Risk of fire and electrical shock.

• All electrical connections should be made by a qualified electrician.

• The appliance must be earthed.

• Make sure that the electrical information on the rating plate agrees with the power sup-

ply. If not, contact an electrician.

• Always use a correctly installed shockproof socket.

4Safety information

• Do not use multi-plug adapters and extension cables.

• Make sure not to cause damage to the mains plug and to the mains cable. Contact the

Service or an electrician to change a damaged mains cable.

• Do not let mains cables to come in touch with the appliance door, specially when the

door is hot.

• The shock protection of live and insulated parts must be fastened in such a way that it

cannot be removed without tools.

• Connect the mains plug to the mains socket only at the end of the installation. Make

sure that there is access to the mains plug after the installation.

• If the mains socket is loose, do not connect the mains plug.

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

• Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses re-

moved from the holder), earth leakage trips and contactors.

• The electrical installation must have an isolation device which lets you disconnect the

appliance from the mains at all poles. The isolation device must have a contact opening

width of minimum 3 mm.

Use

WARNING!

Risk of injury, burns or electric shock or explosion.

• Use this appliance in a household environment.

• Do not change the specification of this appliance.

• Make sure that the ventilation openings are not blocked.

• Do not let the appliance stay unattended during operation.

• Deactivate the appliance after each use.

• Internally the appliance becomes hot when in operation. Do not touch the heating ele-

ments that are in the appliance. Always use oven gloves to remove or put in accessories

or ovenware.

• Be careful, when you open the appliance door while the appliance is in operation. Hot air

can release.

• Do not operate the appliance with wet hands or when it has contact with water.

• Do not apply pressure on the open door.

• Do not use the appliance as a work surface or as a storage surface.

• Always keep the appliance door closed when the appliance is in operation.

• Open the appliance door carefully. The use of ingredients with alcohol can cause a mix-

ture of alcohol and air.

• Do not let sparks or open flames to come in contact with the appliance when you open

the door.

• Do not put flammable products or items that are wet with flammable products in, near

or on the appliance.

WARNING!

Risk of damage to the appliance.

Safety information 5

• To prevent damage or discoloration to the enamel:

– Do not put ovenware or other objects in the appliance directly on the bottom.

– Do not put aluminium foil directly on the bottom of the appliance.

– do not put water directly into the hot appliance.

– do not keep moist dishes and food in the appliance after you finish the cooking.

– be careful when you remove or install the accessories.

• Discoloration of the enamel has no effect on the performance of the appliance. It is not

a defect in the sense of the warranty law.

• Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent.

Care and Cleaning

WARNING!

Risk of injury, fire or damage to the appliance.

• Before maintenance, deactivate the appliance and disconnect the mains plug from the

mains socket.

• Make sure the appliance is cold. There is the risk that the glass panels can break.

• Replace immediately the door glass panels when they are damaged. Contact the Service.

• Be careful when you remove the door from the appliance. The door is heavy!

• Clean regularly the appliance to prevent the deterioration of the surface material.

• Remaining fat or food in the appliance can cause fire.

• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use

abrasive products, abrasive cleaning pads, solvents or metal objects.

• If you use an oven spray, obey the safety instructions on the packaging.

• Do not clean the catalytic enamel (if applicable) with any kind of detergent.

Internal light

• The type of light bulb or halogen lamp used for this appliance, is only for household ap-

pliances. Do not use it for house lighting.

WARNING!

Risk of electrical shock.

• Before replacing the lamp, disconnect the appliance from the power supply.

• Only use lamps with the same specifications.

Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent children and pets to get closed in the appliance.

6Safety information

PRODUCT DESCRIPTION

General overview

4 632 5

1Control panel

2Control knob for oven functions

3Power lamp/symbol

4Electronic programmer

5Control knob for temperature

6Temperature lamp/symbol/indicator

7Heating element

8Oven lamp

9Fan

10 Rear wall heating element

11 Bottom heat

12 Shelf support, removable

13 Shelf positions

Product description 7

Accessories

•Nonstick wire shelf

For cookware, cake tins, roasts.

•Grill / roasting pan

To bake and roast or as pan to collect fat.

•Trivet

For roasting and grilling.

Use the trivet only with the grill/roasting pan.

BEFORE FIRST USE

WARNING!

Refer to "Safety information" chapter.

Initial Cleaning

• Remove all parts from the appliance.

• Clean the appliance before first use.

Refer to chapter "Care and Cleaning".

Setting the time

The oven only operates after time set.

8Before first use

When you connect the appliance to the electrical

supply or in case of a power cut, the Time func-

tion indicator flashes automatically.

To set the current time use " +" or " - " button.

After approximately 5 seconds, the flashing stops

and the display shows the time of day set.

For time change you must not set an automatic

function (Duration or End ) at the same

time.

DAILY USE

WARNING!

Refer to "Safety information" chapter.

To use the appliance, press the control knob. The control knob comes out.

Activating and deactivating the appliance

1. Turn the control knob for the oven functions to select an oven function.

2. Turn the control knob for the temperature to select a temperature.

3. To deactivate the appliance turn the control knobs for the oven functions and temper-

ature to off position.

Knob symbol, indicator or lamp (depends on the model - refer to the appliance

overview):

• The indicator comes on when the oven heats up.

• The lamp comes on when the appliance operates.

• The symbol shows whether the knob controls one of the cooking zones, the oven func-

tions or the temperature.

Oven Functions

Oven function Application

Light Use this function to light up the oven interior.

True Fan Cooking To bake maximum on three oven levels at the same time.

Decrease the oven temperatures (20-40 °C) compared with

Conventional. And to dry food.

Pizza Setting To bake on one oven level food with a more intensive

browning and a crispy base. Decrease the oven tempera-

tures (20-40 °C) compared with Conventional

Conventional Cooking To bake and roast on one oven level.

Bottom Heat To bake cakes with crispy or crusty bases and to preserve

food

Daily use 9

Oven function Application

Defrost To defrost frozen food.

Grilling To grill flat food in the middle of the grill and to toast.

Fast Grilling To grill flat food in large quantities and to toast.

Turbo Grilling To roast larger joints of meat or poultry on one level. Also

for browning food e.g. gratin.

Electronic programmer

1Function indicators

2Function indicators

3Time display

4Button "+"

5Selection button

6Button "-"

456

1 2 3 2

CLOCK FUNCTIONS

Clock function Application

Time of day Shows the time. To set, change or check the time.

Minute minder To set a countdown time.

A signal sounds, after the time period is completed.

This function has no effect on the operation of the oven.

Duration To set how long the oven has to be in operation.

End To set the switch-off time for an oven function.

Duration and End can be used at the same time, if the oven is to be switched on and

off automatically later. In this case first set Duration , then End .

Setting the clock functions

1. Set an oven function and temperature (necessary only for Duration and End).

10 Clock functions

Inhaltsverzeichnis

Andere AEG Electrolux Ofen Handbücher

AEG Electrolux

AEG Electrolux COMPETENCE B3150-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux B41012-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E43012-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux B8875-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux PREFERENCE E88315-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE E2191-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E33519-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux B4115-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux B 89090-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E3191-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E8931-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux U41116 Bedienungsanleitung

AEG Electrolux

AEG Electrolux EOG 1710 Bedienungsanleitung

AEG Electrolux

AEG Electrolux BP5003021M Bedienungsanleitung

AEG Electrolux

AEG Electrolux E4403-5 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E3051-7 Bedienungsanleitung

AEG Electrolux

AEG Electrolux Ovens Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE B3000-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux E31510-6 Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE B8931-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE B3000-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE B3150-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux COMPETENCE D1100-4 Bedienungsanleitung

AEG Electrolux

AEG Electrolux KB9820E Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
