AG Neovo SC-17P Bedienungsanleitung

www.agneovo.com

A cost-effective 17” surveillance

display with the quality, connectivity

and performance essential for any

security environment.

With the AG Neovo SC-17P, security centres can keep an eye on

budgets without losing sight of performance. Digital and analogue

video inputs, including looping BNC I/O, minimise installation

cost. Auto NTSC/PAL detection, settings key lock and auto settings

adjustment reduce maintenance hassle. Quick signal-switching and

rapid response time improve surveillance eciency, while built-in

speakers provide an additional level of security. All this and more

make the SC-17P the perfect value display choice for any security

environment.

> High 1280 × 1024 SXGA resolution

> Anti-Burn-inTM technology

> Built-in Image Enhancer: 3D Comb Filter/Deinterlace/Noise Reduction

> Versatile connectivity (BNC in/out, S-Video, VGA, HDMI, Audio in/out)

> Looping BNC video inputs for multiple connections

> Quick signal-switching time ( ≤ 0.8 sec. )

> NTSC/PAL auto-detection

> Selectable signal source

> PC compatible

> Built-in speakers

> Key lock function

> Auto-adjustment for optimal setting

> Security socket

> VESA standard wall mount

> Tilt capacity from -2° ~ 20°

SC-17P

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: SC7P00 Version 1.1, 20140414

Specications SC-17P

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

LED-Backlit TFT LCD

17.0” (432 mm)

SXGA 1280 x 1024

0.264 mm

250 cd/m2 (Typical)

1000:1 (Typical)

170°/160° (Typical)

16.7M

3 ms (GTG)

Horizontal

Resolution

TV Lines 600TVL (NTSC), 600TVL (PAL)

Frequency (H/V) H: 31.5 kHz - 80 kHz

V: 50 Hz - 75 Hz

Input Analogue

HDMI

CVBS

S-Video

15-Pin D-Sub

HDMI

BNC x 1

4-Pin mini DIN

Out CVBS BNC x 1

Audio Audio In

Audio Out

Speaker

3.5ø mm audio jack

1W x 2

Power Power Supply

Power Requirements

Consumption

Internal

100 ~ 240V, 50 - 60Hz

< 18 W (On)

< 0.5 W (Off)

Plug & Play VESA EDID

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

10% ~ 95%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt -2° ~ 20°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

372 x 385.2 x 184mm

(14.6” x 15.2” x 7.2”)

450 x 467 x 138mm

(17.7” x 18.4” x 5.4”)

Weight Product Weight

Packaged Weight

2.9 kg (6.4 lbs)

3.7 kg (8.1 lbs)

Regulation

Approval

Certications &

Compliance

CB, FCC, CE, REACH, GOST-R,

WEEE, RoHS

Accessories Supplied User manual, power cord,

15-Pin D-Sub cable, audio

cable, warranty card

SC-17P

Video versatility, including VGA, HDMI, S-Video

and BNC In/Out

Stylish and slim design ideal for

professional security environments

Looping BNC video inputs allow multiple

display connections

Built-in speakers enable more rigorous

security monitoring
