AGPtek A30X Bedienungsanleitung

User Manual

Music Player Model: A30X

Content

English

Français

Deutsch

Español

日本語

Nederlands

Polski

Svenska

1-12

13-25

26-39

40-53

54-66

67-70

71-74

75-78

Email: support@agptek.com

Manufacturer: Shenzhen RuiZu Digital Technology Co., Ltd.

Address: 6/F, Building D, KeShang Mei Park, Chongqing Road,

Fuyong, Bao’an District, Shenzhen, China

Important Notice

Thank you for buying our AGPTEK music player. For the best user

experience, please read this user manual carefully before use and

keep it for further reference. Specifications are subject to change

without prior notice.

Charge the Player

1. Charge via the computer USB port.

2. Use a 5V/500mA or 5V/1A charger to charge (charger not

included).

Connect to the PC & Download audio files

1. Open the Windows Explorer or “This PC”.

2. Connect the player to a USB port on your PC using the USB cable.

3. Open the new “AGP-A30X”folder in “This PC”.

4. Copy music files to the “AGP-A30X”.

5. In the right sidebar, right-click the “AGP-A30X”folder and select

“Eject”from the menu.

6. Wait until the computer confirms a safe ejection before you unplug

the USB cable.

Notes: Please do not disconnect the USB plug during file

transferring, as it may cause a malfunction of the player and the files.

Warm Tips

Due to product upgrade, the music player itself has no built-in

memory and must be inserted into a TF card for normal use. This

music player comes with a 32GB TF card (already inserted in the

card slot).

1. VOL +

2. VOL -

3. Power On/Off

4. Return

5. Play/Pause/Long press

to enter music playback

interface

6. Submenu

7. Previous Track/Rewind

8. Next Track/Fast

Forward

9. TF Card Slot

10. Reset Button

11. Back-Clip

12. Type-C Charging Port

13. 3.5mm Headphone Jack

14. Speaker Holes

15. Lanyard Hole

Basic Operation

1. Power On/Off Button: Press the button to turn on/off the player.

2. Screen Display: Press the Power On/Off button to activate

screen.

3. Return Button: On any interface, press the Return button to go

back; long press to enter the home menu directly.

4. VOL +/- Button: On the non-list menu, press the buttons to adjust

volume.

5. Previous/Next Track Button: You can switch songs no matter

the screen is on or off; but if there’s no music playing, there will be

no effect pressing the buttons.

6. One Button to Enter the Music Playback Interface: On any

interface, long press the button to enter the music playback

interface.

Product Overview

456

12 13 14

Main Functions

Home Menu

The home menu is the starting point of each application, and has 12

functions including Music, Video, Recording, FM Radio, Bluetooth,

Setting, Alarm Clock, Photo, Wallpaper, E-Book, Folder, and Tool.

Music

Find Music on the home menu interface, click to enter, and a related

list will display:

1. All songs.

2. Resume/Now Playing.

3. Artists/Albums/Genres

4. Favorites. There are 3 default favorites on the player: Favorites

1/2/3.

5. Update Playlist. Update music files.

Play Music

/ Button: On the music playing interface, long press the

button to fast forward, while short press to the next track; long

press the button to rewind, while short press to the previous

track.

Note: Under the off-screen state, short press the buttons to switch

to the next track or previous track, but can not long press to fast

forward or rewind.

Button: Press to play or pause. Long press to enter music

playback interface.

Music Playback Interface Introduction

1. Song name display.

2. Album picture, music rhythm, lyrics display area.

3. Variable speed playback icon: -8, -7, -6, -5, -4, -3, -2, -1, 0, 1, 2, 3, 4,

5, 6, 7, 8.

4. Submenu

A. Equalizer. Off, Rock, Funk, Hip Hop, Jazz, Classic, Electric,

Custom (Customize and set your favorite equalizer).

B. Delete. Delete the music files displayed on the playback

interface.

Video Playback Interface Introduction

5678

5. Press the or button to

the next track.

6. Press the or button to

play/pause music.

7. Press the or button to

the previous track.

8. Play Modes

A. Repeat All . Play all

songs repeatedly.

B. Single Repeat . Play

one song repeatedly.

C. Shuffle . Randomly play

all music.

D. Sequential Play . Play

the list songs in order.

9. Click to collect favorite song to favorite list 1/2/3.

10. A-B Repeat Mode. Click to select the repeat starting point,

click to select the repeat end point, then the A-B section will

automatically play repeatedly, and click the to resume

normal playback.

Video

Find Video on the home menu interface, and click to enter the video

mode.

Recorder

Find Recorder on the home menu interface, and click to enter the

recording interface.

1. Click or button to start recording, and click again to pause.

2. Click to cancel recording.

3. Click to select whether to save the recording file.

4. Click to enter the submenu: Recording Library, Recording File

Format, Recording Bit Rate, FM Recording Bit Rate.

A. Recording Library. View recording files.

B. Recording File Format. MP3/WAV.

C. Recording Bit Rate. 256kbps, 512kbps, 768kbps, 1024kbps,

1536kbps.

D. FM Recording Bit Rate. 128kbps, 192kbps, 256kbps.

1. Click to switch to the previous video.

2. Click to pause/play the video.

3. Click to switch to the next video.

4. Play Modes

A. Shuffle . Randomly play all videos.

B. Single Repeat . Play one video repeatedly.

C. Repeat All . Play all videos repeatedly.

D. Sequential Play . Play the list videos sequentially.

5. Progress Bar. You can fast forward or rewind by pulling the

progress bar during playback.

FM Radio

Find FM Radio on the home menu interface, and click to enter. Note:

Please first plug in the wired headphone as an antenna before you

start the FM Radio.

1. Click to enter the submenu: Auto Tuning, Radio Frequency

Band, Backend Switch, Preset Radio Station, Clear the Presets,

Clear All Presets, Save to Preset Station, FM Recording File, Start

FM Radio Recording.

A. Auto Tuning. Automatically search for radio channels with

signals.

B. Radio Frequency Band. Normal frequency bands, Japanese

frequency bands, European frequency bands.

C. Backend Switch. Select to turn on/off the backend of the

radio.

D. Preset Radio Station. Display the searched radio channels

with signals.

E. FM Recording File. View the recording file.

F. Start FM Radio Recording.

(1). Click or button to start recording, and click again to

pause.

(2). Click to cancel recording.

(3). Click to select whether to save the recording file.

Bluetooth

Find Bluetooth on the home menu interface, click to enter, and a

related list will display: Bluetooth Switch Control (Bluetooth On/Off),

Search Devices, and Paired Devices.

After you turn on Bluetooth, click Search Devices, and the player

will automatically search for connectable Bluetooth devices. Only

supports Bluetooth speakers and Bluetooth headphones.

Note: When listening to the radio by Bluetooth, a wired headphone is

needed as a radio antenna.

Setting

Find Setting on the home menu interface, click to enter, and a related

list will display: Language, Display Setting, Power-saving Shutdown,

Power Off, Date and Time, Information, and Format Device/Factory

Settings.

1. Language. Choose player display language.

2. Display Setting. Set brightness, backlight timer and screensaver.

3. Power-saving Shutdown. If there is not any operation, the player

will automatically shut down when the set time reaches (3mins,

5mins, 10mins, 15mins, 20mins).

4. Power Off. The player will automatically shut down when the set

time reaches (1-99mins).

5. Date and Time. Manually set time and date.
