Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 1
Gas Safety Products
Merlin Gas Detectors
Installation, operating and maintenance
Read these instructions carefully before operating or servicing
Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 2
Attention
The unit should be installed by a competent person only.
The expected life time of the detector/sensor element is:
LPG, Methane and Hydrogen = 10 years. CO = 5 years.
The unit should be stored in cool, dry conditions.
We do recommend that this product is serviced annually.
If the unit is found to be damaged –Contact us.
IMPORTANT: Carbon Monoxide (CO).
This apparatus is designed to protect individuals from the acute effects of Carbon Monoxide exposure.
It will not fully safeguard individuals with specific medical conditions.
If in Doubt consult a medical practitioner.
Table of Contents
1 General information .....................................................................................................3
2 Installation ......................................................................................................................3
3 Operation.......................................................................................................................3
4 Specification..................................................................................................................4
Wiring Diagram .......................................................................................................................5
Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 3
1General Information
American Gas Safety LLC supply a full range of remote gas detectors that are compatible with
our range of Merlin panels. These consist of carbon monoxide, natural gas, LPG detectors.
2Installation
2.1 Mounting & Position
The control panel is designed for surface mounting using two mounting screws. Removing the
back plate gives access to the circuit board. Do not attempt to remove the PCB.
For the positioning of specific gas detectors please see below:
Natural Gas –12” from the ceiling.
Hydrogen Gas –12” from the ceiling.
LPG –40” from ground level.
Carbon Monoxide –Commercial Kitchens: 67” from ground level.
Commercial Plant Room: 40” from ground level.
2.2 Power Supply
A 12 –24VDC electrical supply should be supplied to the panel and should be connected to
the terminals marked [POWER + -].
2.3 Alarm Relay
Our range of Merlin Gas Detectors can work with various Merlin systems.
If you are using our GDP range you will need to use the [C/L] terminal as an alarm relay
whereas on most other systems gas detectors should be wired to the gas detector terminal on
the Merlin panel using the [N/C] & [COM]. See Wiring Diagram at the end of this document.
xxxTo Avoid Electrical Interference. All low volt connections should be made using a screened cablexxx
3Operation
3.1 Detector ON & OFF
ON - Supply power to the detector
OFF - Remove power to the detector
3.2 LED STATUS
Power - Detector is ON.
Low - When the detector has reached low level alarm –LOW LED will illuminate.
High - When the detector has reached High level alarm state this will illuminate and
the buzzer will sound.
Please see below for further LED information.
Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 4
4Technical Specification
Power supply
7-30VDC, 80mA max
Gas Sensor
Methane/LPG/Hydrogen - Semiconductor Type
Carbon Monoxide –Electro-Chemical Type
Typical Measuring Range
Methane 300-10000 ppm
LPG 300-10000 ppm
Carbon Monoxide 10-10000 ppm
Hydrogen 100-10000 ppm
Power Up - Warm Up Time
1 minute
Low Level Alarm
(pre-alarm)
Methane 8%LEL by volume
LPG 0.16% by volume
Carbon Monoxide 30ppm
Hydrogen 8%LEL by volume
High level alarm
Methane 10%LEL by volume
LPG 0.2% by volume
Hydrogen 10%LEL by volume
Carbon Monoxide
30 ppm for 2 hours
50 ppm for 1 hour
100 ppm for 10 minutes
300 ppm for 1 minute
Volt Free Relay Output
240VAC 500mA, 30VDC 2A switching current (resistive load)
Net weight
Dimensions
180g
(W)x5.27”(H)x3.66”(D)x1.45”
Installation standard
See Section 2
Carbon Monoxide (CO)
Fixed Unit Location Recommendation
Take in to account the design of the air flow within the space. Positioning CO detectors near
draft will greatly diminish their reliability. Multiple detectors may be required to adequately
protect the space.
Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 5
Wiring Diagram
[+] Power supply, Positive connection from Merlin panel.
[-] Power supply, Negative connection from Merlin panel.
[CL] Alarm relay, Alarm signal to GDP panel.
[N/C] Alarm relay, Volt free connection. Normally Closed.
[COM] Alarm relay, Volt free connection. Common.
[N/O] Alarm relay, Volt free connection. Normally Open.
For more information, contact us.
PLEASE NOTE
MAINS AND LOW WIRING SHOULD NOT RUN IN THE SAME CONDUIT
Merlin Gas Detectors User & Installation Manual
Rev: 08 Date: 18-10-18 6
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF ELECTRICAL & ELECTRONIC EQUIPMENT
When this product has reached the end of its life it must be treated as Waste Electrical & Electronics Equipment (WEEE).
Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment,
recovery and recycling of the materials used. Please contact your supplier or local authority for details of recycling
schemes in your area.
CONTACT US:
AGS Head Office
Tel: (727) 608-4375
Fax: (727) 538-4237
info@americangassafety.com
AGS is the owner of this document and reserves all rights of modification without prior notice.
