Presenter
User’s Manual
RC132/610/611
RF132, Presenter with RF wireless technology
!!! Attention!!!
A. Do not allow minors to use the laser pointer unsupervised.
Laser pointers are not toys.
B. Avoid direct eye exposure.
C. Never shine the laser pointer at anyone. The laser pointer is
designed to illustrate inanimate objects.
D. Do not point the laser pointer at mirror-like surfaces. A
reflected beam can act like a direct beam on the eye.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
1
RF132, Presenter with RF wireless technology
Table of Content
INTRODUCTION ....................................................................3
FEATURES...............................................................................4
PACKAGE CONTENTS..........................................................5
SYSTEM REQUIREMENTS..................................................5
INSTALLATION AND OPERATION....................................6
1. OPEN THE BATTERY COVER AND INSTALL BATTERIES....6
2. INSTALLRECEIVER...........................................................6
3. PRESENTER BUTTON FUNCTION.........................................7
4. INSTALL aimMasterEZ.......................................................8
5. USE aimMasterEZ............................................................ 11
TROUBLE SHOOTING........................................................14
V1.0
2
RF132, Presenter with RF wireless technology
Introduction
Thank you for purchasing Presenter.
Please read this user’s manual carefully before operating the unit,
and keep it for future reference.
The wireless presenter is the ideal wireless remote controller for
large-scale presentations and conference rooms. 2.4GHz of
wireless technology lets you concentrate on your presentation.
The preset RF connection enables true plug-and-play capability;
no driver is required. The presenter features dedicated
PowerPoint®page-up and page-down control keys, a 360-degree
mouse, and a laser pointer. The software, aimMaster EZ allows
you to put marks during the presentation to attract the audiences’
attention. A travel-friendly design that stores the receiver dongle
into presenter also turns off the switch to conserve power.
We make no representation for the errors, omissions or updates
of this document.
3
RF132, Presenter with RF wireless technology
Features
1. 2.4 GHz RF wireless transmission provide up to 20 meters omni-
directional working range.
2. Built-in laser pointer for presentation guidance.
3. Built-in cursor mouse for 360-degree control.
4. Plug and Play. No driver required.
5. Store wireless USB receiver inside presenter.
6. Useful and friendly software, aimMaster EZ, works under Windows
2000/ XP/ Vista OS and allows you to put marks to attract audiences’
attention.
7. Compact design uses hidden dongle as on/off power switch of RF
and laser.
8. Bright laser beam provides easy to see pointer visibility.
9. Compatible with MS, Openoffice, Google Docs
10. TwoAAA batteries provide long and reliable usage.
4
RF132, Presenter with RF wireless technology
Package contents
zPresenter
zUSB type RF Dongle receiver (RF610 – with 4GB USB device ;
RF611 – with microsd card reader)
zaimMaster EZ Software and User’s Manual CD-ROM
zTwo AAA batteries
zQuick Guide
System Requirements
zMicrosoft®Windows®2000/XP/ Vista and Mac OS
z512MB RAM recommended
zCD-ROM drive or DVD-ROM Drive
zUSB Port; PC platform
5
RF132, Presenter with RF wireless technology
Installation and operation
1. Open the battery cover and Install batteries
Open the battery cover of presenter and take off the receiver with 45
degrees angle from the receiver dock before you start to use.
(Please insert the receiver into the receiver dock of the presenter with
45 degrees angle after the presentation. The Power Switch inside the
presenter dock will turn off the power when you put the receiver in)
Put in two AAA batteries and close the battery cover.
Power on/off button
Receiver dock
2. Install Receiver
Plug receiver into the USB port of your computer. Please put your
presenter closed to the receiver around within distance 5 cm and press
any button of the presenter around 3 seconds except laser button, the red
indicator of presenter will keep flash if quick-link is successful. If the
receiver is inserted correctly, the blue indicator of receiver will flash once
6
RF132, Presenter with RF wireless technology
when Presenter key is pressed.
3. Presenter button function Red indicator
PAGE UP LASER
PAGE UP
PAGE DOWN PAGE DOWN
Mouse STICK
LEFT RIGHT
Power on/off button
Receiver dock
7
RF132, Presenter with RF wireless technology
Button Function
or PAGE UP button (suit for left-handed or
right-handed user)
or PAGE DOWN button (suit for left-handed or
right-handed user)
LASER button (if receiver is put into presenter,
the laser power is off and can’t operate)
Mouse LEFT button
Mouse RIGHT button
Mouse STICK (use your finger tip to push
STICK to any direction.)
Power on/ off button (on/off power switch of
presenter)
4. Install aimMaster EZ
Insert the CD to your computer. The following window will pop up.
Click “Next”
8
RF132, Presenter with RF wireless technology
Click “Next”
Click “Install”
9
