Aiphone AH-108 Bedienungsanleitung

AS-3A FEATURES:

• Push button to call master station

• Call-in activates tone at master

• Call-in LED remains activated for 20 seconds after call

button is released (MP-3S, AP-5M/10M only)

• Hands free communication when master answers

• Desk or wall mount (to 1-gang box or ring)

CALL button

SPECIFICATIONS

AS-Series Sub Stations

For use with AP-M and MP-S Systems

AS-3A

Speaker

COMMON SPECIFICATIONS:

System: AP-M or MP-S

Speaker: 20 ohms

Communication: Hands free at sub

Conductors: 1 pair homerun per sub

Use Aiphone wire #832202

Wiring Distance: AP-M: 490’ w/22AWG; 1200’ w/18AWG

MP-S: 330’ w/22AWG; 720’ w/18AWG

Dimensions: 7” x 5-13/16” x 3-1/16” (H x W x D)

Aiphone Communication Systems • 1700 130th Ave. NE • Bellevue, WA 98005

(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • www.aiphone.com

AS-3N FEATURES:

• Overhead hands free communication with master station

• Remote push button to call master station (optional)

• Call-in activates tone and light at master

• Call-in LED remains activated for 20 seconds after call

button is released (MP-3S, AP-5M/10M only)

• Flush mounts in ceiling with provided equipment

AS-3N

0603MBMK

Speaker

Common Specifications, plus:

Call button: Optional NP-B (with NP-W surface box if req’d)

Mounting: Flush mount in ceiling

Dimensions: 7-1/16” x 1-7/8” (Diameter x Depth)

AH-108 FEATURES:

• Hands free communication with master station

• Remote push button to call master station (optional)

• Weather proof, heavy duty construction

• 8Ω, 10W horn with built-in non-polarized capacitor

• All metal weather proof construction for indoor or outdoor use

• Universal swivel mount base

• Beige baked enamel finish

AH-108

Cone

Common Specifications, plus:

Call button: Optional NP-B (with NP-W surface box if req’d)

Power Handling Capacity: 10 Watts (Continuous)

Impedance: 8Ω

Dispersion Angle: 120°

Sensitivity as a microphone: -26dBM

(Re: 10 dynes/cm2)

Dimensions: 6-1/8” Bell x 6-1/2” Deep

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Aiphone Gegensprechanlage Handbücher

Aiphone

Aiphone LEF-10C Bedienungsanleitung

Aiphone

Aiphone IX-MV7-HW Bedienungsanleitung

Aiphone

Aiphone NDR-LD Bedienungsanleitung

Aiphone

Aiphone AP-MS Bedienungsanleitung

Aiphone

Aiphone 0311 A OI Bedienungsanleitung

Aiphone

Aiphone GT-1C7 Bedienungsanleitung

Aiphone

Aiphone JK-1SD Bedienungsanleitung

Aiphone

Aiphone AP-1M Bedienungsanleitung

Aiphone

Aiphone GT-2H Bedienungsanleitung

Aiphone

Aiphone JK-DVF-XP Bedienungsanleitung

Aiphone

Aiphone IS-IP4DVF Bedienungsanleitung

Aiphone

Aiphone KB-3MRD Bedienungsanleitung

Aiphone

Aiphone IBG-1HD Bedienungsanleitung

Aiphone

Aiphone LEF-5C Bedienungsanleitung
