AIPTEK PocketDV 4100 Bedienungsanleitung

Users Manual

WELCOME

SAFETY NOTICE

Dear user, thanks for purchasing this product.

Much investment in time and effort has gone into its development, and

it is our hope that it will give you many years of trouble-free service.

1. Do not drop, puncture or disassemble the camera;

otherwise the warranty will be voided.

2. Avoid all contact with water, and dry hands before

using.

3. Do not expose the camera to high temperature or leave

it in direct sunlight. Doing so may damage the camera.

4. Use the camera with care. Avoid pressing hard on the

camera body.

5. For your own safety, avoid using the camera when

there is a storm or lightning.

6. Avoid using batteries of different brands or types at the

same time. This may lead to the potential for serious

damage.

7. Remove batteries during long periods between usage,

as deteriorated batteries may affect the functionality of

the camera.

8. Remove batteries if they show signs of leaking or

distortion.

9. Use only the accessories supplied by the manufacturer.

10. Keep the camera out of the reach of children.

TABLE OF CONTENTS

WELCOME 1

SAFETY NOTICE 1

CAMERA PARTS 4

GETTING STARTED 5

LOADING THE BATTERIES 5

INSERTING THE CF CARD (OPTIONAL) 6

ATTACHING THE WRIST STRAP (OPTIONAL) 7

HOW TO OPEN THE CONNECTOR COVER 8

HOW TO HOLD YOUR CAMERA 8

USING THE TRIPOD (OPTIONAL) 9

BASIC OPERATIONS 10

TURNING ON YOUR CAMERA 10

TURNING OFF YOUR CAMERA 10

SETTING THE LANGUAGE 11

RECORDING A VIDEO CLIP 12

TAKING A STILL PICTURE 13

USING THE FLASH STROBE (OPTIONAL) 14

RECORDING A VOICE CLIP 15

PLAYING BACK YOUR RECORDINGS 16

PLAYING BACK YOUR RECORDINGS- THUMBNAILS 17

CONNECTING THE CAMERA TO YOUR TV 18

ADVANCED OPERATIONS 19

CHANGING VIDEO RESOLUTION 19

SETTING VIDEO QUALITY 20

SETTING VIDEO COMPRESS METHOD 21

CHANGING PICTURE RESOLUTION 22

SETTING PICTURE QUALITY 23

SETTING SELF TIMER 24

SETTING FLASH STROBE 25

DELETING FILES 26

VIEWING FILE INFORMATION 27

CAMERA SETTINGS 28

SWITCHING TO SETTINGS MODE 28

SETTING POWER AUTO-OFF 28

SETTING AV OUTPUT MODE 29

SETTING LANGUAGE 29

SETTING TIMESTAMP 30

SETTING DATE 30

SETTING TIME 31

FORMAT MEDIA 31

COPYING FILES TO YOUR PC 32

INSTALLING THE DRIVER TO YOUR PC 32

INSTALLING THE DRIVER TO YOUR PC (CONTINUED) 33

CONNECTING THE CAMERA TO YOUR PC 34

COPYING FILES TO THE PC 35

COPYING FILES TO THE PC (CONTINUED) 36

VIEWING/PLAYING FILES ON YOUR PC 37

FILE LOCATION 38

TROUBLESHOOTING 39

ADDENDA 41

CAMERA PARTS

Power Button ( )

Shutter Button ( )

Mode Dial

Record Button ( )

Back LED

4-Way Buttons ( )

Enter Button ( )

Menu Button ( )

Connector Cover

Card Eject Button ( )

LCD Display

Lens

Front LED

Microphone

Tripod Socket

CF Card Slot

Zoom Lever

Battery Release Lever

Strap Holder (1)

Battery Compartment Cover

Strap Holder (2)

TV-out Connector

Speaker

USB Connector

13 Flash Strobe

4-Way Buttons ( )

Menu Button ( )

Enter Button ( )

GETTING STARTED

Loading the batteries

Push the battery release lever to the

unlock position, and then pull the

battery compartment cover downward

and lift the cover up to remove the

cover.



Do not use batteries of different types or brands at the same time.

Alkaline batteries or rechargeable NiMH batteries are recommended for high perfor-

mance.







Place the batteries into the compart-

ment. Note that the positive(+) and

negative(-) ends cannot be reversed.

After the batteries are properly

installed, replace the battery compart-

ment cover.

Inserting the CF card (optional)

In addition to 16MB (128Mbits) of

built-in ﬂ ash memory, your camera

can store data on a Compact Flash

(CF) card or a microdrive. The sup-

ported memory size ranges from

8MB to 1GB (1024MB).

To insert a CF card, gently push

the card as indicated until the card

reaches the end of the slot.

To remove the card, ﬁ rst make sure

that the power is off. Then open

the LCD panel, and push the card

eject button to pop out the card or

microdrive.

Do not remove the CF card when the camera is powered on.

When a CF card is inserted, the camera will use the card as the main storage media.

Files stored in the camera’s built-in memory will become inaccessible until the CF card

is removed.

If the CF card cannot be identiﬁ ed by your camera but is usable on other device, it is

probably because of incompatible format. Please see the Troubleshooting section for

more information.



Attaching the wrist strap (optional)

Unfold and spread the wrist strap as

illustrated.







Follow the instructions as illustrated to

thread and fasten the wrist strap.

Fold the wrapping cover to secure the

wrist strap.

How to hold your camera

Please put your hand through the wrist strap and ﬁrmly hold the camera as

illustrated. While taking still pictures or recording video clips, avoid blocking the

lens to retain the best result.

How to open the connector cover

When you want to connect the camera to your PC, TV or earphone, you need

to open the connector cover. Please open the cover gently in the sequence as

illustrated below.

Using the tripod (optional)

Use a tripod to minimize camera movement and ensure optimal image quality,

especially while shooting self-portraits or having video conference.
