AIPTEK PocketCam 1.3M Smart Leitfaden
E-Manual
MegaCam
Manager
MegaCam
Manager
Chapter 1: How to Use Your Digital Camera
Introduction
The built-in memory of your camera is 16MB (128Mbits) memory. It supports
two kinds of quality - high quality(1248x960) pictures and normal quality
(640x480) pictures. It also supports AVI Movie mode( 624x480) and
(304x240) for high quality and normal quality. Besides, your camera offers
several functions on the LCD, showing the number of taken pictures as well.
With a USB cable, you can transfer all the pictures to your PC.
Installing batteries
Your camera is powered by 2 AA alkaline batteries or by a PC via a USB
cable.
Your camera
Shutter Switch
View Finder
Lens
Power
Flash
USB port
Flash Dial
Mode Switch
LCD Display
Battery Cover
AVI Movie Mode
Self Timer
Good Battery
Still Image
Erase All
Erase Last
Quality
Digit Counter
LCD Display
Plug in USB Cable
Flash Strobe
The LCD display
Press the power button to turn on/off the camera.
Press the mode button, the LCD indicates still image, AVI movie,
Self-timer, erase last, erase all, quality and good battery icons in
order.
To use the function of the icons, press the shutter button.
AUTO
H
L888
Icon Functions Description
Still Image mode - takes still pictures
AVI Movie mode - takes AVI Movie pictures
Self Timer - starts 10 second self-timer to take a picture
Erase Last - erases the last picture
Erase All - erases all of the pictures in the memory
Normal quality
Digit Counter - displays the number of the pictures you take
Good battery - indicates good battery status
Low battery - indicates low battery status
High quality
Still image mode
(1248x960), up to 40 pictures
AVI Movie mode
( 624x480 ), up to 30sec/8fps
(640x480), up to180 pictures
( 304x240 ), up to 120sec/8fps.
Still image mode
AVI Movie mode
- indicates USB cable is plugged in
- starts Flash strobe function
Plug in USB Cable
Flash Strobe
H
L
AUTO
888
Taking a picture
Press the shutter switch to take a picture. A high pitched beep indicates that a
picture is taken successfully and the counter increases as well. A beep with
blinking LCD display suggest that the camera is full.
Chapter 2: Taking Pictures
Press the mode button.
The LCD shows the Still Image Mode icon.
Press the shutter button to take a single picture.
Still Image Mode
Turning on / off your camera
Press the power button to turn on/off the camera.
Your camera turns off automatically
when idle over 60 econds.
s
ON
AVI Movie Mode
Press the mode button.
The LCD shows the AVI Movie Mode icon.
Keep pressing the shutter button to take AVI Movie.
Also, AVI Movie can be made with a click on the shutter.
Release the shutter button to stop AVI Movie Mode.
Press the mode button.
The LCD shows the Self Timer icon.
Press the shutter button.
Your camera starts a 10-second countdown and takes a picture.
Self Timer
Erase Last
Press the mode button.
The LCD shows the Erase Last icon.
Press the shutter button.
The Erase Last icon starts to blink.
Press the shutter button again and the last stored picture
or AVI Movie is cleared.
Digit Counter
It shows the total taken images and AVI Movies.
Your camera beeps with blinking LCD to remind you the
memory is full.
When running out of power, the LCD changes from a good battery
icon to a low battery icon. It tells you to replace batteries.
Battery Indicators
Good Battery Battery Status
Press the mode button.
The LCD shows the Erase All icon.
Press the shutter button.
The Erase All icon starts to blink.
Press the shutter button again and all the stored picture
and AVI Movie are cleared.
Erase All
Flash Strobe
Flash Strobe Button: It is on the back of your camera, supporting
three functions as the picture shown below.
Auto / On/ Off
Auto: Adjust the flash strobe button to
the Auto flash symbol
automatically appears.
On: The flash is turned on.
Off: The flash is turned off.
888
AUTO
H Good You should use high quality when you need very good image quality.
LNormal You should use low quality when you need standard image quality.
Quality
Quality
Choosing the Quality
Press the mode button until a star icon with H or L is shown.
To change "H" or "L" quality, press the shutter.
Select a function icon to take a picture, such as Still Image mode.
Press the shutter and a picture is taken.
Note : Still image mode and AVI Movie mode automatically selects different resolutions.
The following chart shows the differences.
Still image mode
AVI Movie mode
High quality:
Normal quality:
(1248x960), up to 40 pictures
(640x480), up to180 pictures
High quality: ( 624x480 ), up to 30sec/8fps
Normal quality: ( 304x240 ), up to 120sec/8fps.
Chapter3: How to Transfer Photo and
Video to PC
Connect the smaller end of the USB cable to
the USB port of your camera.
Plug the larger end of the USB cable to
the USB port of your PC.
Hardware Installation
USB
