AIRFLO AFS9 Bedienungsanleitung
INSTRUCTION MANUAL
Steam Mop
model AFS9
Handle
Water tank
Trigger / Light indicator
Body
Microfiber
cloth
pad
Glider
Head
Upper cord wrap
Lower cord wrap
2
ASSEMBLY AND USAGE
1. Attach the head to the body.
2. Insert the handle into the body.
3. Place the microfiber cloth pad on the head and fasten it by pulling
the cord.
4. When using your steam mop on carpet, place the head on the
glider. CAUTION! Never use steam mop without the microfiber
cloth pad on.
5. To remove the water tank, push it up and detach from the body.
6. Pour two measuring cups of water into the water tank. The
maximum capacity for the water tank is 800ml. Note: Never overflow
the water tank as it can cause water leakage.
7. Twist the upper cord wrap clockwise. Unwrap the power cord and
plug it into a grounded outlet.
8. Slowly pass over the surface to be cleaned, pressing the trigger to
release steam when needed. It is recommended to sweep or vacuum
floor prior to using steam mop.
9. When you are done using the steam mop, unplug the power cord
from the outlet, empty the water tank and carefully remove the
microfiber cloth pad.
WARNING! The microfiber cloth pad can be very hot.
3
SAFETY CONDITIONS. IMPORTANT INSTRUCTIONS ON SAFETY OF USE
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
The warranty conditions are different, if the device is used for commercial purpose.
1. Before using the product please read carefully and always comply with the following
instructions. The manufacturer is not responsible for any damages due to any misuse.
2. The product is only to be used indoors. Do not use the product for any purpose that is
not compatible with its application.
3. The appliacable voltage is 220-240V, ~50Hz. For safety reasons it is not appropriate to
connect multiple devices to one power outlet.
4. Please be cautious when using around children. Do not let children to play with the
product. Do not let children or people who do not know the device to use it without
supervision.
5. WARNING: This device may be used by children over 8 years of age and persons with
reduced physical, sensory or mental capabilities, or persons without experience or
knowledge of the device, only under the supervision of a person responsible for their
safety, or if they were instructed on the safe use of the device and are aware of the
dangers associated with its operation. Children should not play with the device. Cleaning
and maintenance of the device should not be carried out by children, unless they are over
8 years of age and these activities are carried out under supervision.
6. After you are finished using the product always remember to gently remove the plug
from the power outlet holding the outlet with your hand. Never pull the power cable!!!
7. Never leave the product connected to the power source without supervision. Even when
use is interrupted for a short time, turn it off from the network, unplug the power.
8. Never put the power cable, the plug or the whole device into any liquid/water. Never
expose the product to direct sunlight or rain, etc. Never use the product in humid
conditions.
9. Periodically check the power cable condition. Do not use the product if the power cable
is damaged.
10. Never use the product with a damaged power cable or if it was dropped or damaged
in any other way or if it does not work properly. Do not try to repair the defective product
by yourself as it can lead to electric shock. All repairs should be done only by authorised
service professionals.
11. Never put the product on or close to hot or warm surfaces like the electric oven or
gas burner.
12. Never use the product close to combustibles.
13. Do not let cord hang over edge of counter.
14. Do not immerse the motor unit in water.
15. Always unplug the mop from the power source after use. Do not pull the power cord.
16. Never handle the steam mop with wet hands or when not wearing shoes.
17. Never insert any objects into the mop nozzles. If any of the nozzles is blocked, do
not use the mop.
4
18. Do not use the mop without placing the cleaning pad over the mop head. Do not use
the mop when the water tank is empty.
19. Be extra cautious when using the steam mop on stairs.
20. Store the device in an upright position in a cool and dry place.
21. When using the mop, make sure that the surface to be cleaned is well lit.
22. Never pour any cleaning solutions into the water tank as it can damage the device.
23. Never block the steam nozzles. Never use the mop on soft surfaces because the steam
nozzles may get blocked. Always clean the steam nozzles by removing all the fuzz, hair
etc.
24. Use only the attached accessories recommended by the manufacturer.
25. Never direct the steam towards people or animals.
26. Do not use the steam mop on unprotected wood surfaces. The hot steam may remove
the wax when you use the mop on waxed surfaces. Never leave the mop running on wood
surfaces for a long period of time.
27. Be careful when using the mop on vinyl floors, linoleum or any temperature-sensitive
surfaces. Always test the mop on a small floor area in an inconspicuous place. Before use,
read the floor manufacturer's instructions for cleaning to make sure that the surface may be
steam-cleaned.
28. The steam mop may be used for disinfecting floors in the bathroom, kitchen, shower,
etc. To disinfect the area, hold the running mop on the surface being cleaned for at least 8
seconds but no longer than 15 second.
29. Leaving the steam mop running in the same spot without moving it for longer than
recommended may result in accumulation of sediment. The sediment can be removed with
a descaling solution or a few drops of vinegar.
30. Steam mop should be used only on sealed floors.
5
CLEANING AND MAINTENANCE
1. Before cleaning unplug the mop from the power outlet.
2. Microfiber cloth pad can be washed in the washing machine. Steam mop should be
used only with a microfiber cloth pad from the manufacturer.
3. Wipe the mop with a rug. Never immerse the unit in any liquid/water.
4. At least once a month, clean off the dirt /sediment from the steam mop.
TECHNICAL DATA:
Power source:
Power: 220-240V ~50Hz
1300W
