AirLive Smart Home Kit Bedienungsanleitung
SmartLife IOT
For Home
Smart Home Kit QIG
Setup the IoT Package
Start to use IoT Gateway
Start to use IoT Device
Start to use AirLive SmartLife Plus
1
8
13
Appendix
Exclude Devices
Include Sensors and Smart Plug (Option)
Include SmartCube 300W (Option)
16
19
23
Page 00
Setup the IoT Package
Start to use IoT Gateway
Download the AirLive Smart
Life Plus APP
Please visit App Store or Google Play
to download AirLive SmartLife Plus
APP. You can use QR code scanner
software directly or simply search
the “AirLive SmartLife Plus”.
01
Page 01
SmartLife IOT
For Home
Start to use IoT Gateway
AirLive SmartLife Plus
AirLive SmartLife Plus
AirLive SmartLife Plus
App Store Google Play
IOT
For Home
Connect the gateway to the Router
by Ethernet cable
Note: When the internet connection is
built, a white LED light will turn
ON.
Click the “AirLive
SmartLife Plus”
icon on your smart
phone
Page 02
Setup the IoT Package
Start to use IoT Gateway
Install the Gateway
02 Execute the APP
03
5V DC Power Ethernet
IOT
For Home
e
Page 03
Please select "QR Code" to add
gateway.
Remove the back holder of the
Gateway by sliding it down and
then, Please scan the QR code to
add the gateway.
Setup the IoT Package
Start to use IoT Gateway
Select QR code to Add
Gateway
04 Scan the QR code
05
Back of the gateway
QR code
Or click "LAN search" to add the
gateway if QR code not work.
Note: Make sure your phone and
gateway are on the same
network segment Note: You can input your desired name
into Name field.
Key in gateway ID and password to
field. The default ID is "admin" and
the password is "airlive". Press the
Eye to see your password
Page 04
Setup the IoT Package
Start to use IoT Gateway
Select LAN Search to Add
Gateway
06 Key in the password
07
Note: If the sensors are not listed or you
want to add new sensors, please
go to “Include sensor” chapter.
After Login into the Gateway, the
APP will display the Scenes page by
default to see your devices. Click
"Devices" tab, all included sensors
should be shown on screen.
Page 05
Setup the IoT Package
Start to use IoT Device
Devices Screen
08
When the Siren is not displayed in
the Devices tab, then go to "Setting"
>> "Options" and check mark "Show
Gateway Siren" The siren will now
be shown in the Device tab.
Siren
09
1
2
1. Click the Icon to see the Device
information.
2. Click the Text to Activate the
Actuator (Sensor cannot be
Activated.
By default the Wifi in the Gateway is
turned on. The default SSID is
Airlive-XXXXX were XXXX is the
wireless MAC address of your
Gateway. The default WIFI password
is 12345678 It is highly recommend
that you change the WIFI settings to
your own after setting up the
Gateway. For example turn the WIFI
Off or change the SSID and
Password.
Page 06
Setup the IoT Package
Start to use IoT Gateway
Control Info
10 Wifi Notice-1
11
12
To change the Wifi settings Go to
"Setting" and "Gateway
Information" Click on the Wireless
icon to change the settings
Page 07
Setup the IoT Package
Start to use IoT Device
Wifi Notice-2
12
In the Wifi menu you can select OFF
to turn the Wifi of the Gateway Off.
Or for AP Mode/ STA mode. AP mode
is the default mode select this mode
to change the SSID and Wifi
Password. Select STA mode when
you like to connect the Gateway as
client to a Wifi network.
Wifi Notice-3
13
1
3
2
SmartLife IOT
For Home
Start to use IoT Device
You can click "Question mark" to
download the user's guide for APP
operation.
Page 08
Setup the IoT Package
Start to use IoT Gateway / Start to use IoT Device
Download APP User's Guide
14
