WT-2000R

Turbo-G Broadband Router

Turbo-GFamily

The AirLive Turbo-G family provides 125Mbps wireless speed at

the same cost as the Wireless-G devices. Unlike the Super-G

mode that uses channel-binding technology, Turbo-G solution can

deliver up to 1.5 times the speed of Wireless-G solution using one

single channel. This means higher and more stable performance.

Best ofall, itis compatiblewith 802.11g and802.11bsolutions.

Wired SpeedRouting Performance

The WT-2000R offers unprecedented IP sharing performance at asurprisingly affordable price. Therouter is

equipped with a powerful processor that can support close to 100Mbps of Internet connection speed which is

the speed of the Fast Ethernet connection. With this amazing throughput and a 10/100Mbps WAN port, the

router isready foruse withthe latestbroadband solutionssuch asVDSL andFTTH. Inaddition, itcomes with4

auto sensingswitching portswith auto-MDI/MDIXfunction toeliminate theneed forcross-over cable.

AirLiveGuard WirelessSecurity

Wireless Security has always been a concern for most users. The AirLiveGuard system is a combination of

multiple layers of wireless protections. Starting with "SSID Hide" that will prevent other users seeing the

wireless network without knowing the exact SSID name. Then the WPA/WPA-PSK/WEP function encryptions

the data, so intruders won't be able to interpret the wireless data. Therefore, unable to use your wireless

connection. At last,the DoubleGuard access controlsystem willlock wirelessaccess toyour PC'sMAC andIP

address. You can choose whether to let PC that are not on the MAC access list to use Internet connection,

associate with wireless, or communicate with LAN PC only. This create a combination of 9 possible access

schemes forthe ultimatecontrollability.

Scheduling Firewall

The URL and domain blocking prevent users from accessing unwanted website by IP or by the domain name.

Email notification function enables the router to send email to notify user about hacker's attack or scheduled

report on connection log. The WT-2000R even offer the Syslog feature, so administrator can have the log

recorded on a separate PC server. Comprehensive content filter and Access Control let administrator monitor

and controlthe networkfor optimalsecurity andperformance.

Wake-on-LAN andSpecial FTPport

The WT-2000R features a specialWake-On-LAN function. So you can loginto the router's UIfrom Remote, then

ask therouter tosend outWOL packetto wakeup specificPCs. Thespecial FTPport allowyour routerto redirect

FTP trafficto adifferent portthan thestandard Port21, soyou cancontinue tooperate theFTP servereven ifyour

ISP blockcertain ports.

Security has always been a primary concern for IP sharing and wireless environment. For

this reason, AirLive has incorporated a full feature firewall that includes SPI, DoS Attack

Prevention, VPNpacket filter, andThreshold monitor. TheSPI (StatefulPacket Inspection)

technology detect situations whereindividual TCP/IPpackets are valid but collectively they

become ahacker attack.

The Router is the first in its price range to feature a policy based Firewall. Therefore, you

can definewhich inboundor outbound traffic areallowed. Moreover, thescheduling feature

allow userto definewhat timeand dayof theweek theservice wouldbe available.

Easy Management

The routerUPnP (UniversalPlug-n-Play) capabilitylet yourrouter configurecorrectly withyour PCand multi-user

Internet application. The webmanagement featurescomprehensive online help toexplain every single function.

Best ofall, the setup Wizard guides userthrough toset up the Internetconnection easily. For ISP andenterprise

customer,the routersupport SNMPmanagement functions.

Global BroadbandStandard Support

AirLive has invested extra software effort to ensure compatibility with the global broadband standard. In

addition tothe standard cable modem,fixed IP, andPPPoE client xDSL support. AirLive has addedsupport for

PPTP client (Holland, Austria, England, Israel, Czech Republic), L2TP(Holland, Israel), Telstra Bigpond

Cable(Australia), and SingTel RAS (Singapore). The WT-2000R is designed to work with most broadband

connections inthe world.

* TheTurbo-G modeworks onlywhen usingwith otherTurbo-G devices.

Ports

·10/100Mbps WANport

·4 x 10/100Mbpsswitching LAN ports

·AutoMDI/MDI-X functions

Wireless

·Antenna

·2 dBidetachable DipoleAntenna

·Reversed SMAConnector

·Frequency

·USA (FCC)11Channels:

2.412GHz~2.462GHz

·Europe (ETSI)13 Channels:

2.412GHz~2.472GHz

·Japan (TELEC)14 Channels:

2.412GHz~2.483GHz

·Modulation

·11gOrthogonal FrequencyDivision

Multiplexing (64QAM, 16QAM,QPSK,

BPSK)

·11bDirect SequenceSpread Spectrum

(CCK, DQPSK,DBPSK)

·Output Power

·11g

·64QAM: 14

·16QAM: 15

·QPSK: 16

·BPSK: 17

·11b

·DBPSK,DQPSK,CCK: 17.5

·Data Rate

·11gmode: 54,48, 36,24, 18,12, 9,6 Mbps

·11bmode; 11, 5.5,2, 1Mbps

·WEP: 64/128-bit

·WPA,WPA-PSK,WPA2,WPA2-PSKSupport

·802.1x RadiusAuthenticator

Specification

·WDS RepeaterMode

·4 x 10/100Mbpsswitching LAN ports

·AutoMDI/MDI-X functions

Configuration

·Web browser

·Web-based SetupWizard

·SNMP Management

·Detailed On-LineHelp

·Configuration Back andRestore

·Firmware Upgradeable

·Reset buttonprovided

Broadband Support

·PPPoE client

·PPTP client

·L2TP Client

·Cable Modem

·Fixed IP

·Telstra BigpondCable

·SingTelRAS

·FTTH

·VDSL

Wake OnLAN

·Wake upPC using MACaddress

·Activate fromDHCP Clientlist orMaintenance-

>Miscellaneous

Management Function

·DHCP Serverfor up to253 clients

·Lease Time, FixeIP mapping

·Including DNS,DNS2, WINsServer,WINS

Server2.

·DHCP clientto acquire dynamicnetwork

configuration from ISP

Specification

·Anyplatform thatsupport Webbrowser

Supported Protocols

·TCP/IP, NAT,ARP, ICMP, DHCPclient/server,

PPPoE, PPP, PAP, CHAP, NTP, HTTP, TFTP,

POP3

Supported Protocols

·TCP/IP, NAT,ARP, ICMP, DHCPclient/server,

PPPoE, PPP, PAP, CHAP, NTP, HTTP, TFTP,

POP3

LED Indicators:Power, WLAN,Status, WAN,LAN x

4 (Link,Speed)

EMI: Meet CE,FCC part15 ClassB, BSMI,VCCI, C-

tick

Dimension: 160 x 115 x 30mm

Weight: 210g

Power: AC 12V, 1A

·Proxy DNS

·Dynamic DNSd

·Virtual Server

·Multi-session PPTP, L2PT, and IPsecVPN

pass through

·Static Routing

·Access Control

·Block

·Packet Filter

·In BoundFilter

·OutBond Filter

·Schedule Control (Time and Dayof theWeek)

·Remote Management

·Session/User Lists

·Syslog

·System Activity

·Debug Information

·Attacks

·Dropped Packets

·Notice

·Email Notification

·Hacker Attack

·Connection Log

·Scheduled

·Firewall

·Stateful Packet Inspection(SPI)

·DoS AttackPrevention

·L2TP, PPTP, IPsecfilter

·Disable WANPING

·OS Support

·Windows 95/98/NT/ME/2000/XP

·Unix

·Macintosh

Ordering Information

WT-2000R Turbo-GBroadband Router
