Akai ARC120 Bedienungsanleitung
Clockradio/CD-player
ARC120
GB 2
NL 15
FR 29
ES 43
DE 57
EL 71
User manual
Gebruiksaanwijzing
Manuel de l’utilisateur
Manual de instrucciones
Gebrauchsanleitung
Οδηγίες χρήσεως
Table of contents
Copyright notice
Design and specications are subject to change without notice.
1. Safety........................................................................... 3
1.1 Intended use ....................................................................3
1.2 Labels in this manual .......................................................3
1.3 General safety instructions ..............................................3
2. Preparations for use................................................... 4
2.1 Unpacking ........................................................................4
2.2 Package contents ............................................................4
3. Installation................................................................... 5
3.1 Battery backup .................................................................5
4. Functions..................................................................... 7
4.1 Clockradio/CD player .......................................................7
5. Operation..................................................................... 9
5.1 Set the time ......................................................................9
5.2 Clock functions.................................................................9
5.3 Alarm function ................................................................10
5.4 Radio functions ..............................................................10
5.5 CD functions ..................................................................11
6. Cleaning and maintenance ...................................... 12
6.1 Handle and care of a disc ..............................................12
7. Troubleshooting........................................................ 13
8. Technical data........................................................... 13
9. Disposal of used electrical and electronic
equipment.................................................................. 14
3
ARC120
Safety1.
Intended use1.1
The Clockradio/CD player wakes you up with music from CD or radio
broadcast. The clock function includes an alarm and sleep program.
Read the manual carefully before the rst use.
Labels in this manual1.2
! WARNING
A warning means that injury or death is possible if the instructions
are not obeyed.
! CAUTION
A caution means that damage to the equipment is possible.
i
A note gives additional information, e.g. for a procedure.
General safety instructions1.3
! WARNING
Do not put force on the appliance. The appliance can fall and can
cause serious injury.
! CAUTION
Do not spill any liquid on the appliance.
! WARNING
Do not insert any objects in the ventilation holes.
! CAUTION
Do not block the ventilation holes.
4
i This appliance is double insulated; therefore no earth wire is
required. Always check that the mains voltage corresponds to the
voltage on the rating plate.
L This appliance employs a laser system. To prevent direct exposure
to the laser beam, do not open the appliance. Visible laser
radiation when open and interlock defeated.
Preparations for use2.
Unpacking2.1
● Unpack the appliance carefully.
● Check the package contents as described below. If any item is missing,
please contact your reseller.
● Remove the labels from the front panel carefully if present.
i We recommend that you retain the original carton and packing
materials in case it ever becomes necessary to return your product
for service. This is the only way to safely protect the product
against damage in transit. If you do dispose of the carton and the
packing materials, please remember to recycle with due care to the
environment.
Package contents2.2
The following items are included in the received package:
1 Clockradio/CD player
1 Operator manual
i
If any item is missing, please contact your reseller.
5
ARC120
Installation3.
● Put the appliance on a horizontal at surface.
● Connect the appliance to the mains.
! CAUTION
● Do not put the appliance near a heat source.
● Do not expose the appliance to direct sunlight.
i This appliance is equipped with rubber feet to prevent it from
moving. The feet are made from non-migrating material specially
formulated to avoid leaving any marks or stains on furniture.
However, certain types of furniture polishes, wood preservatives or
cleaning sprays cause the rubber to soften and leave marks or a
residue on the furniture, and potentially risk the surface to become
damaged. To prevent damage to wooden surfaces, we recommend
that you apply self-adhesive pads to the bottom of the rubber feet
before installation.
Battery backup3.1
In case of a power failure, the appliance relies on battery backup. For this
purpose, the appliance uses two batteries (AAA). The appliance remembers
the time, but does not display it.
6
i
● Batteries are not included with this appliance.
● Batteries are not necessary for normal operation.
Install batteries
● Remove the battery cover.
● Insert the batteries matching the (+) and (-) polarity markings.
● Re-install the battery cover.
! CAUTION
Incorrect installation can cause battery leakage and corrosion
which will damage the appliance. Corrosion, oxidation, battery
leakage and any other gradually acidic defect of this nature will
invalidate the guarantee.
7
ARC120
Functions4.
Clockradio/CD player4.1
1
3
4
5
6
7
8
9
1517181920 162
10 11 12 13 14
1 Headphone jack
2 VOLUME dial
3 ALARM1 button
4 ALARM2 button
5 CLOCK ADJ button
6 PROGRAM button
7 REPEAT/RANDOM button
8 DISPLAY button
9 SLEEP button
10 Display
11 PLAY/PAUSE button
12 STOP button
13 SKIP FORWARD/HOUR button
14 SKIP BACKWARD/MINUTE button
15 TUNING dial
16 FUNCTION switch
17 ON/OFF button
18 OPEN button
19 CD compartment
20 SNOOZE button
8
Display
29 28
22 23 24 25 26 2721
21 ALARM1 indicator
22 ALARM2 indicator
23 SLEEP indicator
24 PROGRAM indicator
25 REPEAT indicator
26 SNOOZE indicator
27 PM indicator
28 RANDOM indicator
29 POWER ON indicator
9
ARC120
Operation5.
● To switch on the appliance, press the ON/OFF button (17). The POWER
ON indicator (29) on the display lights up. To switch off the appliance,
press the ON/OFF button (17) again.
● To adjust the volume level, turn the VOLUME dial (2) until the desired
level is set.
● To connect a headphone, insert the cable plug in the headphone jack (1).
To prevent hearing damage, remember to adjust the volume to
a comfortable level.
Set the time5.1
● Connect the appliance to the mains. The default time (12:00) ashes on
the display.
● To set the correct hour, press the SKIP FORWARD/HOUR button (13).
● To set the correct minutes, press the SKIP BACKWARD/MINUTE button (14).
● To conrm the setting, press the PROGRAM button (6).
● To switch the clock setting between 12H mode and 24H mode, hold the
CLOCK ADJ (5) button for two seconds.
i
● To set the time, the appliance must be switched off.
● During a power failure, or when unplugging the appliance, the time
settings are lost, unless backup batteries are installed.
Clock functions5.2
Setting the SLEEP function
● Select the desired radio station or insert a CD.
● Press the SLEEP button (9). The SLEEP indicator (23) is ON.
● To adjust the sleep time, press the SLEEP button (9) until the desired
period is set (90/60/30/15 minutes). The appliance stops playing after the
chosen time has elapsed.
● To cancel the SLEEP function, press the ON/OFF button (17).
10
Alarm function5.3
This function is available in CD, AM/FM and BUZZER mode. Two time slots
are available (ALARM1 and ALARM2).
● Switch the appliance off.
● Slide the FUNCTION switch (16) to the desired position (CD, AM/FM or
BUZZER). Adjust the volume.
- For AM/FM alarm, tune to the desired radio station
● Press the ALARM1 button (3) to set ALARM1. The clock display ashes.
● Press the HOUR and MINUTE buttons (13 and 14) to set the desired time,
and press the ALARM1 button to conrm the setting. The ALARM1
indicator (21) is ON.
● Press the ALARM2 button (2) to set ALARM2. The clock display ashes.
● Press the HOUR and MINUTE buttons (13 and 14) to set the desired time,
and press the ALARM2 button to conrm the setting. The ALARM2
indicator (22) is ON.
● To cancel the alarm, press the ALARM1 or ALARM2 button once.
Snooze alarm
The default snooze time is: 6 minutes.
● To snooze the alarm, press the SNOOZE button (20) once. The SNOOZE
indicator (26) is ON, and the ALARM indicator ashes. The alarm sounds
again after the snooze time has elapsed.
● To stop the alarm, press the ON/OFF button (17). The alarm is
automatically set for the next day.
Radio functions5.4
● To select the radio band, slide the FUNCTION switch (16) to the AM or FM
position.
● To select a frequency or radio station, turn the TUNING dial (15) until the
desired frequency is set.
i To improve the reception of the FM frequency, extend the aerial
antenna. To improve the reception of the AM frequency, turn the
appliance.
