ALDEBARAN Robotics Plato Bedienungsanleitung

Manufacturer: Aldebaran

Original instructions: English

Document version: A01

Use Case: Plato by Aldebaran is a serving Cobiot designed

to assist sta in restaurants (commercial environments)

by delivering dishes to customers and collecting dirty dishes to clear tables.

Model: E02100

Your serving Cobiot

Delivery and Collecting

Accessories

Deutsch EnglishDeutschEspañolFrançais

日本

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 1BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 1 24/10/2022 19:2324/10/2022 19:23

MANUFACTURER : ALDEBAR AN • 43 RUE DU COLONEL PIERRE-AVIA • 75015 PARIS • FR ANCE • D0000058 A00 DELIVERY & BUSSING ACCESSORIES LEAFLE T

Table of contents

Description ........................................................................... p. 

Safety ....................................................................................... p. 

Usage ....................................................................................... p. 

Speciﬁcations ..................................................................... p. 

More information .............................................................. p. 

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 2BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 2 24/10/2022 19:2324/10/2022 19:23

MANUFACTURER : ALDEBAR AN • 43 RUE DU COLONEL PIERRE-AVIA • 75015 PARIS • FR ANCE • D0000058 A00 DELIVERY & BUSSING ACCESSORIES LEAFLE T

Description

1. Drink holder (available soon)

2. Trays

3. Collecting

b. Single rectangular tray (available soon)

a. Round tray

a. Collecting tub

d. Anti-slip mat (available soon)

c. Double rectangular tray (available soon)

b. Collecting top cover

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 3BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 3 24/10/2022 19:2324/10/2022 19:23

4MANUFACTURER: ALDEBARAN   RUE DU COLONEL PIERREAVIA   PARIS  FRANCE  D A DELIVERY & BUSSING ACCESSORIES LEAFLET

Safety

 Plato’s Emergency button must be accessible from 360° at all times

 Do not use the Double rectangular tray, Collecting tub or any large accessories on

Plato’s Top shelf

 Use ONLY the Single tray or the Round Tray on the Top shelf

 Use the Double tray on the Middle shelf ONLY

 Use the Collecting tub on the Bottom shelf ONLY

Make sure the accessory and its contents

are stable before you begin delivering or

collecting with Plato

Maximum load including accessories:

Top and Middle shelves: 10 kg each

Bottom shelf: 20 kg

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 4BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 4 24/10/2022 19:2324/10/2022 19:23

MANUFACTURER : ALDEBAR AN • 43 RUE DU COLONEL PIERRE-AVIA • 75015 PARIS • FR ANCE • D0000058 A00 DELIVERY & BUSSING ACCESSORIES LEAFLE T

 Distribute extra load so that lighter loads are on the upper shelves and heavier

loads are on the Bottom shelf

Food Contact

If an accessory below is not compliant with the Food Contact Directive, do not place

unprotected food (pieces of bread, fruit with edible skin, etc.) directly on it.

FOOD CONTACT

Single rectangular tray NO

Double rectangular tray NO

Anti-slip mat YES

Round tray YES

Collecting tub NO

Collecting top cover NO

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 5BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 5 24/10/2022 19:2324/10/2022 19:23

6MANUFACTURER: ALDEBARAN   RUE DU COLONEL PIERREAVIA   PARIS  FRANCE  D A DELIVERY & BUSSING ACCESSORIES LEAFLET

Please use dishes to deliver food with the

Rectangular trays as they are not suitable for food contact.

Usage

You can increase the payload surface of Plato’s shelves with easy to install delivery

and collecting accessories.

Plato is stable and safe during navigation with loaded delivery and collecting

accessories.

Clean Plato’s delivery and collecting accessories with a soft dry cloth

Installing the trays

Place trays on the dedicated shelves, no tools needed

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 6BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 6 24/10/2022 19:2324/10/2022 19:23

7MANUFACTURER: ALDEBARAN   RUE DU COLONEL PIERREAVIA   PARIS  FRANCE  D A DELIVERY & BUSSING ACCESSORIES LEAFLET

Setting up Plato’s weight sensors

When you use accessories, the weight sensors on each shelf need to be re-calibrated

 Go to Plato’s settings

 Press the Weight sensors button

 Toggle the button ON to activate weighing

 Place empty accessories on the shelves and press the Tare all shelves button on

Plato’s display to calibrate

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 7BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 7 24/10/2022 19:2324/10/2022 19:23

MANUFACTURER : ALDEBAR AN • 43 RUE DU COLONEL PIERRE-AVIA • 75015 PARIS • FR ANCE • D0000058 A00 DELIVERY & BUSSING ACCESSORIES LEAFLE T

More information

Speciﬁcations

ROUND TRAY SINGLE RECTANGULAR TRAY DOUBLE

Installation on robot

Fits on Top shelf,

onMiddle shelf and

on the Collecting

top cover

Fits on Top shelf

Fits on Middle shelf

Food accessible from left,

right and rear of Plato

Overall dimensions .cm diameter  mm ×  mm ×  mm  mm ×  mm ×  mm

Weight . kg . kg . kg

Max. load

Top and middle shelf . kg . Kg . Kg

Bussing shelf . kg . Kg . Kg

Color Black/Gray gray gray

Robot clearance

to avoid collision N/A  cm diameter  cm diameter

English

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 8BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 8 24/10/2022 19:2324/10/2022 19:23

Hersteller: Aldebaran

Original-Anleitung: Englisch

Dokumentenversion: A01

Anwendungsfall: Plato von Aldebaran ist ein Bedienroboter, der dafür entwickelt

wurde, Restaurantpersonal (im gewerblichen Kontext) zu helfen, indem der Cobiot

Kunden ihre Gerichte bringt und Geschirr zum Abräumen einsammelt.

Modell: E02100

Your serving Cobiot

Zubehör zum Liefern

und Holen

Deutsch

BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 9BAT_148_PLATO_03_Accessories_01RG_P01-P32_MULTIL.indd 9 24/10/2022 19:2324/10/2022 19:23

10 HERSTELLER: ALDEBARAN  RUE DU COLONEL PIERRE AVIA   PARIS  FRANKREICH _ D  LIEFER & HOLZUBEHÖR MERKBLATT

Inhaltsverzeichnis

Beschreibung .................................................................. p. 

Sicherheit ........................................................................... p. 

Nutzung .............................................................................. p. 

Technische Details ........................................................ p. 

Weitere Informationen .............................................. p. 

Deutsch
