Alesis Ion Bedienungsanleitung

8-Voice Analog Modeling Synthesizer

Quick Start Owner’s Manual

(ENGLISH)

BOX CONTENTS

•SYNTHESIZER

•POWER CABLE

Manual de inicio rápido para el usuario

(ESPAÑOL)

CONTENIDO DE LA CAJA

•SINTETIZADOR

•CABLE DE ALIMENTACIÓN

Schnellbedienungsanleitung

(DEUTSCH)

INHALT DER VERPACKUNG

•SYNTHESIZER

•

ETZKABEL

Manuel d’utilisation du propriétaire

(FRANÇAIS)

CONTENU DE LA BOÎTE

•SYNTHÉTISEUR

•CÂBLE D’ALIMENTATION

Manuale rapido di utilizzazione

(ITALIANO)

CONTENUTO DELLA CONFEZIONE

•SINTETIZZATORE

•CAVO DI ALIMENTAZIONE

This page intentionally left blank.

ION QUICK START OWNERS MANUAL

(ENGLISH)

Connection Diagram

Connecting AC Power

Before making any power connections, make sure the Ion’s power switch

is turned off.

1. Plug the female end of the power cable into the Ion’s

power socket.

2. Plug the male (plug) end into a properly grounded power outlet.

Making Audio Connections

•Stereo. Connect two cables from the Ion’s left and right outputs to

two inputs of an amp or mixer.

•Headphones. Plug a set of headphones into the headphone jack on

the rear panel.

Connecting the Foot Pedals

• (sust pedal) is designed to work with any standard momentary

footswitch. The Ion will calibrate itself to a normally open or normally

closed pedal if the pedal is plugged in when the Ion is powered on.

• (exp pedal) is designed to work with a Roland EV-5 pedal or

equivalent.

The display

The Liquid Crystal Display (LCD) is at the center of the Ion in more ways

than one. Depending on the button or knob you’ve activated, it may

show the program name, which Programs are used in a Setup, the values

of the parameters being edited, or even a graphic representation of a

waveform or an envelope.

The Home page

This is the screen that shows you the most different kinds of information

all at once. If you’re not already there, press the [home] button and

you’ll see something like this:

Here’s what each area of the Home screen means:

•The darkened bar at the top of the screen shows you the name of

the section being displayed. In this case, it reads home.

•Immediately below that are the bank and program number.

•Roughly in the middle you see the program name of the active

Part.

•The fourth line from the bottom shows the Setup number.

•Below that, the outlined rectangle shows the current Setup name.

•The “e box” icons to the right of the Program and Setup numbers

indicate that the Program and Setup have been edited, respectively.

•The filled rectangle on the second line from the bottom shows

which of the four Parts has been selected with the [panel active]

buttons.

Note: the icon on the inside left of this box indicates that the current

Part has been muted.

•The “quarter note” icon, the “equal to” sign (=) and the numbers to

its right tell you what the tempo setting is for the Setup.

•The “G” to the right of the tempo value indicates the setting of the

Global mode parameter tempo source. If the “G” is there, that

means the tempo source parameter is set to global. This causes the

tempo to remain the same when you recall a new Setup or change

Programs. If the “G” is not there, the tempo source parameter is set

to program. In this case, the tempo value can change from one

Setup to the next, or when you call up another program in Part A.

•The “MIDI connector” icon and the number to its right indicate the

MIDI Channel of the currently selected Part.

The Edit pages

Any time a knob is moved or a button is pressed, the Ion enters Edit

mode and displays a screen with parameters related to that knob or

button. The appearances of the pages can vary quite a bit, but there are

some things they have in common:

There can be up to three parameters displayed on any page. If the

desired parameter does not have a front panel knob, select it using a Soft

button and turn the data knob to edit the value.

Sometimes there are several pages of parameters related to a given

function. You will know this is the case by looking on the bottom line of

the page, as in the example below:

The numbers at the bottom of the page tell you how many pages there

are, and which page you are on. In the above example, there are five

pages available, and you are on page 1. When more than one page is

available, you can navigate to the additional pages using the [page X]

and [Wpage] buttons. Note that the arrow in the left corner is “grayed

out.” That means that there are no more pages available in that direction.

The Global pages

•When the [global] button is pressed, the Ion will enter Global mode.

Select the desired parameter using a Soft button and turn the data

knob to edit the value. For a complete description of the Global

mode parameters, see Chapter 3 of your User Manual.

The Mod Matrix pages

•When the [mod matrix] button is pressed, the Ion will enter Edit

mode for the active Program and display parameters related to the

Mod Matrix. This is also where the Tracking Generator is found. For

a complete description of the Mod Matrix and the Tracking

Generator, see Chapter 6 of your User Manual.

LED functions

Two LEDs serve as “speed” indicators: the rate LED and the tempo LED.

The rate LED may blink at a different speed depending on which of

three functions has been selected in the LFO section: [lfo 1], [lfo 2], or

[s&h].

The mod LEDs indicate that an edit has been made in the Mod Matrix

that affects one or more of the parameters in the section where the mod

LED is lit. If it isn’t obvious at first which parameter is being “modded,”

press the [mod matrix] button and look at the lists of sources and

destinations. For more information on the Mod Matrix, see Chapter 6 of

your User Manual.

The loop LED is similar to the mod LEDs in that it indicates that the loop

parameter has been activated inside the selected envelope. More

information about looping the envelopes can be found on pages 71-72 of

your User Manual.

Button functions

[edit] buttons – A green LED indicates that an [edit] button has been

pressed. This means that a particular set of parameters is being shown in

the display for inspection and editing.

Selection buttons – Some buttons allow you to select between different

sets of parameters that share a common knob or set of knobs. For

example, the [lfo 1], [lfo 2], and [s&h] buttons determine which of those

three functions will be controlled by the rate knob, and also call up

parameters from that function in the display. Similarly, the [pitch/mod],

[filter], and [amp] buttons determine which of those three envelopes will

be controlled by the five knobs in the env section.

Parameter buttons – Other buttons edit or toggle the parameter under

their control: for example, the [mono/poly] button or the [octave]

buttons in the osc section. Other examples include the [porta] button,

which enables portamento, and the [waveform select] buttons, which

determine the waveform utilized by each oscillator.

Special cases

[tap tempo] button – This button allows you to match the speed of the

arpeggiator, an LFO, or other effects to the tempo of a song simply by

tapping the button in time to the music! The LED under the button

flashes to give you an idea of what the tempo setting is currently.

[transpose] and [octave] buttons – These three buttons control the

global transposition and octave shift of the Ion’s keyboard. The settings

will affect all programs and setups, as well as the MIDI note output.

Knob functions

volume knob – This is the red knob just above the Pitch wheel. It

controls the level of the main and headphone outputs. Note that this

control has no effect on the aux outputs.

tempo knob – This is the knob in the upper left corner of the Ion. It

controls the speed of any number of functions, most notably the

arpeggiator.

data knob – This is the clear knob to the right of the display. Use it for

fine-tuning your edits, or to edit a parameter that has no front-panel

knob. It is also used for selecting Programs and Setups.

Performance controls

The Ion gives you a number of expressive controls at your fingertips, in

addition to all of the knobs and buttons:

Velocity – The Ion’s keyboard will respond to differences in how hard

you play the keys. You can tailor-make the keyboard’s response to your

playing style by selecting one of the nine keyboard curves found on

Global mode page 1, Soft button 2.

(p) or Pitch Bend wheel – This wheel is normally assigned to bend the

pitch of one or more oscillators, but it may be used as a source in the

modulation matrix to control nearly any parameter.

(m1) wheel – This wheel usually adds vibrato, but it also may be used as

a source in the modulation matrix to control nearly any parameter.

(m2) wheel – This wheel usually sweeps the filter, but it also may be

used as a source in the modulation matrix to control nearly any

parameter.

This page intentionally left blank.
