Allied Telesis www.alliedtelesis.com

Datasheet | intelligent Multiservice Gateways

AT-iMG606BD

Ethernet intelligent Multiservice Gateway

AT-iMG606BD

6x10/100TX LAN ports

1x100BX, SC/UPC fiber WAN port

Applications

Capitalizing on Existing Infrastructure

The AT-iMG606BD offers a bi-directional

optical interface over a single fiber allowing

efficient use of fiber for new infrastructures and

doubling of capacity for existing dual-fiber

installations.The increase in density of fibers at

aggregation points deliverseconomies of scale

in cabinet space and cost of deployment.The

simple termination of a single fiber at the

customer premise with the AT-RG002 faceplate

and associated splicing kit saves time in

deployment of new fiber estates and upgrading

existing ones to accept the feature benefits of

the AT-iMG606BD.

SoftwareReal-time Applications

Optimization

Quality of Service

This is provided within the AT-iMG606BD

through ISO Layer 2 and 3 prioritization

techniques including priority tagging with

IEEE 802.1p as well as Type of Service (ToS).

Optimization for IP Video Streaming

The AT-iMG606BD ‘snoops’ IGMP packets in-

transit allowing simultaneous delivery of

different multicast transmissions such as

different movies or TV channels. This results in

high quality,high-bandwidth multiple video

streaming without impacting Internet browsing

or IP telephony while delivering the fast channel

change that usersexpect from video services.

MPEG video service management and diagnosis

is possible using troubleshooting techniques.

Furthermore, video quality can be monitored

using the unique MPEG stream monitoring tool.

Data Delivery and Security

Differentiated Bandwidth Internet Services

The AT-iMG606BD provides extensive support

for per-port rate-limiting that enables service

providers to deliver tiered data services

catering for the wide spectrum of end-

customer profiles.

Firewall Capability

The AT-iMG606BD has an integral Stateful

Inspection Firewall with NAT, Denial of Service

(DoS) and an Intrusion Detection System (IDS)

with blocking for protecting end-customer

networks.

Management

Easy to Deployand Manage

Fiber-To-The-Home (FTTH) with the

AT-iMG606BD has never been easier. For

installersand builders, a complete fiber splicing

kit with a passive faceplate for hiding the fiber

termination is available to allow for easy

installation, maintenance and replacement using

Plug & Play optical connections. User

intervention is limited to simply sliding-in the

gateway in the already installed slot containing

the terminated fiber.

Zero Touch Configuration with the ZTC

The AT

-iMG606BD is designed to be easy to

deploy and manage. With the Zero Touch

Configurator (ZTC) software platform, the

AT-iMG606BD can be provisioned and

managed remotely.The Zero Touch

Configurator is a distributed configuration

system based on the industry’s standard

Lightweight Directory Access Protocol (LDAP)

database architecture.This provides secure

authentication and registration plus intelligent,

automatic configuration of remote iMG units.

Its XML-based structure enables seamless

integration with service providers’ existing OSS

platforms.

Key Features

•Up to 100Mbps bandwidth delivery

•Small footprint at customer site

•Innovative two-part case

–easy to deploy

•Stateful Inspection Firewall / NAT for security

of customer and provider

•Single bi-directional fiber presentation drives

resource efficiencies and reduces deployment

cost (CAPEX and OPEX savings)

•Zero Touch Configurator Software removes

need for truck-roll deployment

•Service specific management and monitoring

–ensures Quality of Service to customers

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2007 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000112 Rev. E

AT-iMG606BD |Ethernet intelligent Multiservice Gateway

Ordering Information

AT-iMG606BD-xx (990-001132-xx)

6x10/100TX LAN ports

1x100BX, SC/UPC fiber WAN port

1xConsole port

Include fiber outlet with locking mechanism

Options

AT-iMG006G-10 (990-002154-10)

Battery backup

AT-RG008-00 (990-000396-00)

Battery backup cable

AT-RGCONSOLECABLE (990-011748-00)

Console cable

Where xx = 00 for no power cable

10 for U.S. power cord

30 for U.K. power cord

50 for European power cord

Specifications

User’s Ports

6x10/100TX (RJ45)

WAN Ports

100BX single-fiber (BX, SC/UPC)

TX 1310 nm, RX 1550 nm

Range 15 Km

Power budget 17 dB

Layer 2 Operation

Layer 2 wirespeed packet switching

IGMP v1/v2 multicast support

Tag-based IEEE 802.1Q VLANs (16 max.)

IEEE 802.1p prioritization

IEEE 802.1Q tag insertion and stripping

Programmable rate limiting ingress/egress (32,000 steps)

Port mirroring ingress/egress traffic

Double QoS queue on each port

Port speed selection 10, 100 or 10/100

1,000 MAC addresses

Layer 3 Operation

NAT

PPPoE

Stateful Inspection Firewall

Intrusion detection and blocking system

IPSec/VPN passthrough

Virtual server

Global IP address pool

Dynamic portopening

DHCP client, server and relay

DNS proxy

PAP/CHAP authentication

Static and dynamic IP address assignment

RIPv1/v2

Network Management

Zero Touch Configurator

Local console port

Telnet

Remote software upgrade

DHCP

Web GUI (optional)

LED Status Indicators

Power

System

WAN Link/Activity

LAN Link/Activity

Technical Specifications

Power Characteristics

External power supply

Input 12vDC, 1.5A

Power consumption 6W (typical)

10W (max)

Environmental Specifications

Operating temperature 0ºC to 40ºC

Storage temperature -20ºC to 40ºC

Operating humidity 5% to 80% RH

Physical Characteristics

Dimensions 24cm x 15cm x 6cm

(W x D x H) (9.4” x 5.7” x 2.4”)

Weight (Gateway Only) 0.9lb (0.4kg)

Weight (Gateway & Base) 1.4lbs (0.64kg)

Protocols and Standards

IPv4 RFC 791

TCP, UDP RFC 1144

IGMP (v1/v2) RFC 1112, 2236

PPPoE RFC 2516

PAP RFC 1334

CHAP RFC 1994

NATRFC 1631

DHCP RFC 2131

VLAN IEEE 802.1p/Q, IEEE 802.1d,

IEEE 802.2, IEEE 802.3x

SNMP v1,v2,v3

RTP/RTCP

TFTP RFC 1350

Telnet RFC 318

ARP RFC 826

Approvals

CE Marking

Safety UL60950-1,

CAN/CSA-C22.2 No. 60950-1-03,

EN60950-1, EN60825-1

Emission FCC Part 15 Class B

EN 55022 Class B

Immunity EN 55024

Warranty

Two years
