Allied Telesis www.alliedtelesis.com

Datasheet | Switches

AT-FS708/POE

Unmanaged 8 Port Power Over Ethernet Switch

AT-FS708/POE

8port 10/100TX unmanaged PoE switch

with 1 SFP

High Performance

Providing powerful 10/100 switching solutions

for desktop, conference room and security

applications, the Allied Telesis AT-FS708/POE

unmanaged switch features automatic detection

and classification of an attached PoE device.

With all eight ports PoE capable (four at full

15.4W), this is the perfect solution for a

wireless security or conference room

application.The 10/100 ports on the switch

feature full auto-negotiation.These ports enable

the switches to detect the speed and duplex

modes of attached devices, enabling them to

automatically configure for the best possible

performance. One SFP port is also available for

connecting this device to other switches in your

network, such as the 8500 series of switches.

Simplified Installation

The AT-FS708/POE provides wall-mount,

rack-mount and desktop options giving users

their choice of deployment locations. Fully auto-

configuring AT-FS708/POE switch requires

minimal set-up bythe user. Auto-sensing ports

enable seamless and simple connectivity

between existing 10Mbps Ethernet and

100Mbps Fast Ethernet UTP devices—and

all units can be installed in minutes. Every

AT-FS708/POE switch is equipped with auto

MDI/MDI-X across all ports for simple

connection to other hubs and switches as well

as automatic detection and classification of the

PoE ports. Finally, easy to read top panel

LEDs show ongoing switch status and simplify

troubleshooting.

Quality and Reliability

Allied Telesis is a worldwide leader in unmanaged

Ethernet switches. Shipping more than 250,000

each year, Allied Telesis offers proven reliability and

industryrecognized quality.

Key Features

•810/100TX ports

•1SFP uplink port

•Auto detect and classification of PoE

•PoE capable on all 8 10/100TX ports

(4 @ 15.4W max)

•IEEE 802.3af standard

•Non-blocking architecture

•Auto-negotiation ports

•Auto MDI/MDI-X on all ports

•Plug and Play installation

•Rack-mount, wall-mount and desktop hardware

included

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2008 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000092 Rev. D

AT-FS708/POE |Unmanaged 8 Port Power Over Ethernet Switch

Performance

Ethernet 10Mbps (half-duplex)

20Mbps (full-duplex)

Fast Ethernet 100Mbps (half-duplex)

200Mbps (full-duplex)

MAC addresses 8K

Packet buffer 768K

Half/full-duplex

Auto-negotiation

Auto MDI/MDI-X on all ports

Interface Connections

10/100TX RJ-45

1xSFP

Power Characteristics

Frequency 50 to 60Hz

Power requirements 90-240V AC

Power consumption 90W max

PoE power 48vDC, 65W

Switch and fan power 12vDC, 20W

Environmental Specifications

Operating temp 0 to 40ºC (32 to 104ºF)

Non-operating temp -25 to 70ºC (-13 to 158ºF)

Operating humidity 10-90% non-condensing

Non-operating humidity 5-95% non-condensing

Vibration IEC 68-2-36

Shock IEC 68-2-29

Drop IEC 68-2-32

Physical Characteristics

Dimensions 4.3cm x 33cm x 22cm

(1.7” x 13” x 8.7”)

Weight 1.90kgs (4.20 lbs)

Standards and Compliance

IEEE 802.3i 10T Ethernet

IEEE 802.3u 100TX Fast Ethernet

IEEE 802.3x Flow control

IEEE 802.3af Power over Ethernet, mode A

Certification

UL1950 TUV UL

C-Tick CE Mark

FCC Part 15

CISPR 22

EN55022

Ordering Information

AT-FS708/POE-xx

8port 10/100TX unmanaged PoE switch with 1 SFP

Where xx = 10 for US power cord

30 for UK power cord

40 for Australian power cord

50 for European power cord

SFP Modules

AT-SPTX

10/100/1000T 100m copper

Order number: 990-000262-00

AT-SPSX

GbE multi-mode 850nm fiber

Order number: 990-00028-00

AT-SPLX10

GbE single-mode 1310nm fiber up to 10km

Order number: 990-00029-00

AT-SPLX40

GbE single-mode 1310nm fiber up to 40km

Order number: 990-00161-00

AT-SPLX40/1550

GbE single-mode 1550nm fiber up to 40km

Order number: 990-00160-00

AT-SPZX80

GbE single-mode 1550nm fiber up to 80km

Order number:990-00031-00

AT-SPZX80/wwww

GbE single-mode CWDM fiber up to 80km

Order number: 990-000xx-00

WhereWhere CWDM

wwww = xx = Wavelength

1610 32 1610nm

1590 33 1590nm

1570 34 1570nm

1550 35 1550nm

1530 36 1530nm

1510 37 1510nm

1490 38 1490nm

1470 39 1470nm
