Datasheet | Switches

AT-GS900/5E

Unmanaged Gigabit Ethernet Switch

T-GS900/5E

5port 10/100/1000T unmanaged switch,

external P/S

High Performance

Designed for medium enterprises and

educational networks, the Allied Telesis

GS900 series of unmanaged Gigabit

switches delivers the high-speed and

high-performance demanded by today’s

high-bandwidth applications such as video,

graphics, and industrial design.

Flexibility

Available in 5 and 8 port models, Allied Telesis

lets you decide which size is best for your

network. Reduces your cost by allowing you to

only pay for the ports you need.

Simplified Installation

The GS900 series switches require minimal

configuration and can be installed in minutes

via wall-mount and desktops.The 10/100/1000T

copper ports on the GS900 series are fully

auto-negotiating, allowing the switches to

connect to all other 10Mbps Ethernet,

100Mbps Fast Ethernet, or 1000Mbps Gigabit

Ethernet devices. Equipped with MDI/MDI-X

ports for easy connection to other hubs and

switches, the GS900 series offers a natural

migration path from legacy networks and a

cost-effectiveintroduction to Gigabit Ethernet.

Finally, easy to read front panel LEDs show

ongoing switch status and simplify

troubleshooting.

Quality and Reliability

Allied Telesis is a worldwide leader in

unmanaged Ethernet switches. Shipping more

than 250,000 unmanaged switches every year,

Allied Telesis offers proven reliability and

industryrecognized quality.

Applications

Connected to managed Gigabit switches such

as the AT-9424M or the AT-9748TS/XP or

unmanaged Fast Ethernet switches such as the

AT-FS724L or the AT-LE700, the GS900 series

remains the ideal fit for Gigabit migration in

Local Area Networks (LANs).The GS900 series

of unmanaged Gigabit switches can forward

both standard sized packets and VLAN-tagged

packets throughout LANs. For those

applications requiring Gigabit to the desktop, an

ideal design combines Allied Telesis' GS900

series switches with our Gigabit Network

Interface Card (NIC) (AT-2916T-001).

Key Features

•Wirespeed performance

•Non-blocking architecture

•Auto-negotiation Gigabit ports

•Auto MDI/MDI-X on TX ports

•Transparent to VLAN packets

•Full-duplex flowcontrol

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2007 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000235 Rev. B

AT-GS900/5E |Unmanaged Gigabit Ethernet Switch

Performance

14,880pps for 10Mbps Ethernet

148,800pps for 100Mbps Ethernet

1,488,000pps for 1000Mbps Ethernet

Switching capacity Up to 12Mpps

MAC addresses Up to 4K

Packet buffer 128KB

Half/full-duplex

Auto-negotiation

MDI/MDI-X

Interface Connections

10/100/1000T RJ-45

Power Characteristics

Voltage 100-240V AC

Frequency 50/60Hz

Current 1.0A

Power consumption max. 15W

Environmental Specifications

Operating temp. 0°C to 40°C (32°F to 104°F)

Non-operating temp. -25°C to 70°C (-13°F to 158°F)

Operating humidity 5% to 90% non-condensing

Storage humidity 5% to 95% non-condensing

Technical Specifications

Physical Characteristics

Dimensions 3.8cm x 19.5cm x 11.4cm

(H x W x D) (1.5in x 7.68in x 4.49in)

Weight .65kg (1.43lbs)

Wall-mount or Desktop

All units come with wall-mount hardware

Standards and Compliance

IEEE 802.3 10T Ethernet

IEEE 802.3u 100TX Fast Ethernet

IEEE 802.3ab 1000T Gigabit Ethernet

IEEE 802.3z Full-duplex

IEEE 802.3x Flow control

Electrical/Mechanical Approvals

UL 1950

FCC/EN55022 Class A

VCCI Class A

C-Tick

EN60950 (TUV)

EN55024

Ordering Information

AT-GS900/5E

5port 10/100/1000T unmanaged switch, external P/S

Where xx = 10 for U.S. power cord

20 for no power cord

30 for U.K. power cord

40 for Australian power cord

50 for European power cord
