RAPIER SWITCH

QUICK INSTALL GUIDE

Rapier Switch Quick Install Guide

Document Number C613-04017-01 REV D.

19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA.

permission from Allied Telesyn.

Allied Telesyn International, Corp. reserves the right to make changes in specifications

and other information contained in this document without prior written notice. The

information provided herein is subject to change without notice. In no event shall Allied

Telesyn be liable for any incidental, special, indirect, or consequential damages

whatsoever, including but not limited to lost profits, arising out of or related to this

manual or the information contained herein, even if Allied Telesyn has been advised of,

known, or should have known, the possibility of such damages.

All trademarks are the property of their respective owners.

Quick Install Guide 3

Software Release 2.3.1

C613-04017-01 REV D

Models Covered By This Guide

This Quick Install Guide includes information on the following models:

■Rapier G6

■Rapier G6F-LX/SC

■Rapier G6F-SX/SC

■Rapier G6F-SX/MT-RJ

■Rapier 8/8MT

■Rapier 8/8SC

■Rapier 16F-FX/MT

■Rapier 16F-FX/SC

■Rapier 24

■Rapier 24i

■Rapier 48

■Rapier 48i

Quick Install Guide updates can be downloaded from

www.alliedtelesyn.co.nz/support/rapier/.

Rapier Switch

Safety and Statutory Information

Quick Install Guide

Hardware Reference

Software Reference

Network Service Modules

NSM Quick Install Guide

NSM Hardware Reference

Port Interface Cards

PIC Quick Install Guide

PIC Hardware Reference

General Customer Support

Visit www.alliedtelesyn.co.nz for

the latest documentation, FAQ,

and support information

Uplink Module

Uplink Module Quick Install Guide

Uplink Module Hardware Reference

Printed Acrobat PDF Website

Documentation Roadmap

User Guide

4Rapier Switch

Software Release 2.3.1

C613-04017-01 REV D

Package Contents

The following items are included with each Rapier Switch. Contact your sales

representative if any items are damaged or missing.

■One Rapier Switch.

■One AC power cord (AC models only).

■One serial cable for connecting the switch to a terminal or PC.

■One 19 inch rack-mount kit.

■One Rapier Switch Quick Install Guide.

■One Safety and Statutory Information booklet.

■One Rapier Switch Documentation and Tools CD-ROM (which includes

the complete Rapier Document Set and utilities).

■One warranty card.

Selecting a Site

The switch can be installed in a standard 19-inch rack or on a level surface such

as a desktop or bench. When installing the switch, choose a site that:

■Allows adequate airflow around the switch and its vents.

■Is free of dust and moisture.

■Will allow the switch to operate within a temperature range of 0 to 40º C

(32 to 104º F) and a humidity range of 5 to 95% non-condensing.

■Has a reliable and earthed (grounded), preferably dedicated and filtered,

power supply circuit.

■Does not expose cabling to sources of electrical noise, such as radios,

transmitters, broadband amplifiers, power lines, electric motors, and

fluorescent fixtures.

■Allows easy access to the switch’s power and cable connections.

■Will allow all related network devices to be connected to the switch

without exceeding maximum cable length limitations. See the Rapier Switch

Hardware Reference for cable length specifications.

Quick Install Guide 5

Software Release 2.3.1

C613-04017-01 REV D

Installing the Switch

All AC and DC versions of this equipment must be earthed.

Follow these steps to install the switch:

1. Before installing the switch, read the safety information

For safety information, see the Safety and Statutory Information booklet. A

copy of this booklet is supplied with each switch, and can also be found on

the Documentation and Tools CD-ROM or at www.alliedtelesyn.co.nz/

support/rapier/.

2. Gather the tools and equipment you will need

If installing a DC version of the switch, you will need a DC power source,

DC supply cable, and wire strippers (see step 8).

If the switch is to be connected to a redundant power supply, you will need

a redundant power supply unit and cable (see step 10).

3. Choose a suitable site for the switch

Either a flat surface or 19 inch rack.

4. Unpack the switch

Verify the package contents. If any items are damaged or missing, contact

your sales representative.

5. Install expansion options

If you purchased optional Uplink Modules, a Network Service Module

(NSM), or Port Interface Cards (PICs), install them now by following their

individual installation guides. These guides can be found on the

Documentation and Tools CD-ROM.

Installation instructions for PACs can be found in the Rapier Switch

Hardware Reference.

6. Place the switch in its operating locations

If installing the switch in a rack:

• Remove the rubber feet.

• Attach the rack-mounting brackets.

• Mount the switch in the rack.

7. Apply AC power to the switch (for AC models)

Plug the power cord into the AC power connector on the switch’s rear

panel. The Fault LED should flash for approximately 10 seconds as the

switch runs internal tests. If the LED continues to flash or remains lit, refer

to the Rapier Switch Hardware Reference for troubleshooting information.

6Rapier Switch

Software Release 2.3.1

C613-04017-01 REV D

Figure 1: Rapier front panel and rear panel with AC power inlet.

8. Apply DC power to the switch (for DC models)

Read the Safety and Statutory Information booklet before connecting a DC

power supply. A copy of this booklet is included with each switch. It is also

included on the Documentation and Tools CD-ROM, or can be

downloaded from www.alliedtelesyn.co.nz/support/rapier/.

Only trained and qualified personnel should connect a DC power supply. Due

to exposed terminals, DC powered switches should only be installed in

Restricted Access Areas.

DC supply cable specifications:

• Number of wires (cores): 3

• Minimum size: 2.1mm2(14 AWG)

• Minimum cable rating: 600V, 90 degrees Celsius

DC power supply specifications:

• 48 V DC (39-60 V DC is acceptable)

• Either positive grounded or negative grounded

Circuit protection:

• Use a 10 Amp circuit breaker

To connect the DC supply:

a) Ensure that the supply cable is not live

b) Strip the supply cable wires to expose 8mm (0.31 in.) of bare conductor

c) At the switch, connect the ground wire to the ground terminal (The

terminals can be identified by the diagram on the switch’s rear panel,

see Figure 2). Tighten the terminal to between 0.6 and 0.8 Nm (0.041 to

0.055 pound-force per foot)

STATUS

RESET

FAULT

PWR

RPS

10BASE-T/ 100BASE-TX

1X3X5X7X

2X4X6X8X

9X11X13X15X

10X12X14X16X

17X19X21X23X

18X20X22X24X

RS-232

TERMINAL PORT

100M LINK / ACTIVITY 10M LINK / ACTIVITY

HALF DUP/

COL

FULL DUP

PORT ACTIVITY

L/A

D/C

L/A

D/C

ASYN0

Layer 3 Fast Ethernet Switch

NSM 0

Hot Swap

In Use

Swap

Front panel

Uplink Module Bays 10/100 BASE Expansion Bays Port LEDs System

LEDs

RS-232 Terminal Port

Rear panel

100-240 VAC

Power Inlet RPS Inlet for

AT-PWR8000 NSM BAY NSM Hot Swap

Button and LEDs

Quick Install Guide 7

Software Release 2.3.1

C613-04017-01 REV D

d) At the switch, connect the positive feed to the + (positive) terminal and

the negative feed to the - (negative) terminal. Tighten the terminals to

between 0.6 and 0.8 Nm (0.041 to 0.055 pound-force per foot)

e) Ensure that there are no exposed conductor strands

f) Secure the supply cable (to the rack framework or similar object) so that

the connections are isolated from any forces applied to the cable

g) Ensure that the circuit breaker is in the Off position

h) Connect the supply-cable wires to the circuit breaker

i) Energise the circuit breaker

Figure 2: DC Power inlet terminals on a Rapier 24.

The Fault LED should flash for approximately 10 seconds as the switch

runs internal tests. If the LED continues to flash or remains lit, refer to the

Rapier Switch Hardware Reference for troubleshooting information.

9. Check that the Power LED on the switch’s front panel lights green

If the LED fails to light, refer to the Rapier Switch Hardware Reference for

troubleshooting information.

10. Connect the Redundant Power Supply (Optional)

AC models of Rapier Switches have a Redundant Power Supply (RPS)

connector on their rear panel.

The Switch is designed to operate with the AT-PWR8000 RPS, which can be

purchased separately. Contact your authorised Allied Telesyn distributer

or reseller for more information.

11. Connect the data cables

Make sure that each cable connection is secure. The switch will now

perform basic Layer 2 switching functions.

Configuring the switch

Some configuration is necessary if you wish to enable the switch’s advanced

switching capabilities. The switch can be configured via the Command Line

Interface (CLI) or Graphical User Interface (GUI).

Using the CLI to configure a switch

1. Connect a terminal or PC to the Terminal Port (ASYN0)

Using the supplied RS-232 DB9 straight-through cable, connect your

terminal or PC to the RS-232 Terminal Port on the switch’s front panel.

NSM 0

Hot Swap

In Use

Swap

38-75VDC , 2A

FOR CENTRALIZED DC

POWER CONNECTION,

INSTALL ONLY IN A

RESTRICTED AREA

DC Power inlet

DC INPUT

8Rapier Switch

Software Release 2.3.1

C613-04017-01 REV D

2. Set the communication parameters

Set the communication parameters on your terminal or terminal emulation

program to:

• Baud rate: 9600

• Data bits: 8

•Parity:None

•Stopbits:1

• Flow control: Hardware

3. Log in

After the switch has booted, the log in prompt appears. If the log in prompt

doesn’t appear, press [Enter] two or three times.

When the switch boots for the first time it automatically creates an account

with manager privileges. The account has the log in name “manager” and

the password is “friend”.

At the log in prompt, enter the log in name and password.

Password: friend

The switch’s command prompt appears and you can now configure the

switch using the command line interface.

Change the password as soon as possible. Leaving the manager account with

the default password is a serious security risk. Make sure that you remember

the new password as there is no way to retrieve it if it is lost.

Use the following command to change the account password:

set password

4. Load help files

To access help, enter:

set help=help-filename

where help-filename is the name of a help file stored in flash.

To see a list of files stored in flash, enter:

show file

Help files have an HLP extension.

To display a list of help topics, enter:

help

To display help on a specific topic, enter:

help topic

Alternatively, type a question mark (?) at the end of a partially completed

command to see a list of valid options.

See the Rapier Switch Software Reference for more information on

configuring the switch.

Quick Install Guide 9

Software Release 2.3.1

C613-04017-01 REV D

Using the GUI to configure a switch

The GUI can be accessed through the switch’s default VLAN (VLAN1). To

set-up the GUI the first time it is used, you must first access the CLI.

1. Access the CLI

Follow the instructions in the previous section: “Using the CLI to configure

a switch”.

2. Enable IP

At the CLI, enter the command:

ENABLE IP

3. Assign an IP address to VLAN1

Assign the VLAN1 interface an IP address in the required subnet, using the

command:

SET IP INTERFACE=vlan1 IP=ipaddress MASK=mask

4. Define a route (if required)

If the PC from which you will access the GUI is on a different subnet to the

switch, add a route from the PC to the switch. Enter:

ADD IP ROUTE=PC-ipaddress INTERFACE=vlan1

NEXTHOP=switch-ipaddress

5. Connect the PC to a switch port

The PC can be connected directly, or through a LAN.

The PC should be running Internet Explorer 5.xor Netscape 6.2, with

JavaScript enabled. A copy of Internet Explorer can be found on the

Documentation and Tools CD-ROM that is bundled with your switch.

If you access the Internet through a proxy server, set your browser to

bypass the proxy for the IP address you just assigned to the VLAN1

interface.

Point your web browser at the IP address of the VLAN interface.

6. Log in

At the log in prompt, enter the log in name and password.

User Name: manager

Password: friend

The system status page appears and you can now use the GUI to configure

the switch.

To ensure that configuration settings are saved correctly, use the GUI pages’ menus and

buttons to navigate, not your browser’s buttons.

As a security precaution, change the password as soon as possible.

To change the password, select Management > Users from the sidebar

menu. Select the Manager account and click Modify.

7. To access context-sensitive help

Click on the GUI Assistant Button [?] on each page.

10 Rapier Switch

Software Release 2.3.1

C613-04017-01 REV D

System LEDs and What They Mean

System LEDs on its front panel indicate the switch’s operational status.

1. DC models of the Rapier Switch do not have an RPS connector and the RPS LED will not function.

2. Not included on the Rapier 48, G6, G6F-SX/SC, G6F-LX/SC, or G6F-SX/MT-RJ.

3. Hot swapping is supported by Software Release 2.3.1 or later. AT-AR021 (S) BRI-S/T, AT-AR021 (U)

BRI-U, AT-AR022 ETH, AT-AR023 SYN, and AT-AR026 4ETH PICs can be hot swapped.

The Rapier Switch Hardware Reference has further troubleshooting information,

including information on Switch Port and Uplink Module LEDs.

System LEDs

LED State Function

Power Green The switch is receiving power and the voltage

is within the acceptable range

Fault Red The switch or management software is

malfunctioning

1 flash A switch fan has failed. (The LEDs will not

indicate an RPS fan failure.)

3 flashes If an RPS is connected, the switch’s PSU (Power

Supply Unit) has failed

4 flashes If RPS monitoring is enabled, the RPS PSU has

failed

5 flashes If RPS monitoring is enabled, an RPS is not

connected or is not operational

RPS1(Redundant

Power Supply)

Green An RPS is connected to the switch

In use2(Rear panel) Green An NSM is installed, is receiving power, and is

operational. The NSM and its PICs are not

ready to be hot swapped

Off No NSM is installed, or the NSM is not installed

correctly (the switch unit has not recognised

the NSM)

Swap2 (Rear panel) Green The NSM and its PICs are ready to be hot

swapped

Off The Hot Swap button must be pressed before

the NSM or PICs can be hot swapped, or the

software release does not support hot

swapping3

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Allied Telesis Schalten Handbücher

Allied Telesis

Allied Telesis AT-9800 Series Bedienungsanleitung

Allied Telesis

Allied Telesis GS950 PS Series Bedienungsanleitung

Allied Telesis

Allied Telesis FS750 SERIES Bedienungsanleitung

Allied Telesis

Allied Telesis CentreCOM GS980M Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-x210 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS201 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-SBx908 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9724TS Bedienungsanleitung

Allied Telesis

Allied Telesis TurboStack AT-S6 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS950/8POE Bedienungsanleitung

Allied Telesis

Allied Telesis CentreCOM AT-3726XL Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS900/16 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8900 SERIES Bedienungsanleitung

Allied Telesis

Allied Telesis AT-9006T Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS232 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS900M Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-8800 Series Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FH708SW Bedienungsanleitung

Allied Telesis

Allied Telesis AT-FS708 Bedienungsanleitung

Allied Telesis

Allied Telesis Patch 1 AT-S63 Bedienungsanleitung

Allied Telesis

Allied Telesis AT 9924SP AT-9924SP-30 AT-9924SP-30 Kurzanleitung

Allied Telesis

Allied Telesis AT-GS950/48 Bedienungsanleitung

Allied Telesis

Allied Telesis AT-GS900/8PS Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
