CPA562 HDMI IN-Line Controller
CPA562
HDMI IN-LINE
Controller
All Rights Reserved
Version: CPAV.1.0.2
User Manual
CPA562 HDMI IN-Line Controller
Important Safety Instructions
1. Do not expose this apparatus to
rain, moisture, dripping or
splashing and that no objects filled
with liquids, such as vases, shall be
placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit in
a bookcase, built-in cabinet or in
another confined space. Ensure the
unit is well ventilated.
3.
To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct the
unit’s ventilation openings with
newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other apparatus
(including amplifiers) that produce
heat.
5. Do not place sources of naked
flames, such as lighted candles, on
the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
1
Warnings of FCC
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
2
Table of Contents
Important Safety Instructions................................................................................................. 2
Introduction........................................................................................................................... 3
Overview...................................................................................................................... 3
Key Features................................................................................................................ 4
Key Benefits................................................................................................................. 4
Package Contents........................................................................................................ 5
Specifications ............................................................................................................... 6
Panel Layout................................................................................................................ 8
EDID Presets........................................................................................................................ 9
RS232 Control Tool............................................................................................................. 10
Initial Installation..................................................................................................................11
Warranty Terms and Conditions .......................................................................................... 13
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
3
Introduction
Overview
Altimium CPA562 is a HDMI In-line Controller, with resolutions up to 4K@60Hz (chroma
sub-sampling 4:4:4 8-bit only) and HDCP 2.2.
Its digital or analog audio output allows audio to be de-embedded from HDMI input and sent to
audio distribution system, such as AVR or Zone Amplifier. Its rotary EDID switch has 15 EDID
presets and can help negotiate the HDMI handshake in certain situations, such as an old HDMI
display with DDC channel invalid, or DVI display with audio amplified requirement.
By auto-detecting input signal status, it could automatically trigger CEC command to turn on or
off TV with CEC support, pre-loaded RS232 commands to power on or standby projector, and
relay control to turn on or off projection screen.
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
4
Key Features
Support video source up to HDMI 2.0(4K@60Hz 4:4:4 8-bit) and HDCP 2.2
HDMI audio de-embedded out with Digital Coaxial andAnalog Stereo
Rotary switch for EDID Management with 15 EDID presets
Built in CEC controller from HDMI out
Built in RS232 controller, to pre-load and store RS232 command of sink device
Key Benefits
Automatic CEC/RS232 command to Power ON/Standby display device, by detecting
input signal status
Built in RELAY control to automatically turn Projector Screen ON/OFF, by detecting input
signal status
Automatic input cable equalization and signal regeneration compensation
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
5
Package Contents
1 x CPA562
1x Power Supply (DC 12V 0.5A)
3 x Phoenix Male Connector (3.5 mm, 3 pins)
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
6
Specifications
Technical
Input 1 x HDMI IN
Input Signal Type HDMI 2.0 with HDCP 2.2
Input Resolution Support
VESA:
800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz,
1280x800@60Hz, 1280x960@60Hz,
1280x1024@60Hz, 1360x768@60Hz,
1366x768@60Hz, 1440x900@60Hz,
1600x900@60Hz, 1600x1200@60Hz,
1680x1050@60Hz, 1920x1200@60Hz;
SMPTE:
4096x2160@24/25/30/50/60Hz,
3840x2160@24/25/30/50/60Hz,
1080P@24/25/30/50/60Hz, 1080I@50/60Hz,
720P@50/60Hz, 576P@50Hz, 480P@60Hz
Input Video Level 0.5-1.2 V p-p
Input DDC Signal 5V p-p
Maximum Pixel Clock 297MHz
Output 1 x HDMI OUT
Output Signal Type HDMI 2.0 up to 4K@60Hz(4:2:0 10-bit) and HDCP 2.2.
Output Resolution Support
VESA:
800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz,
1280x800@60Hz, 1280x960@60Hz,
1280x1024@60Hz, 1360x768@60Hz,
1366x768@60Hz, 1440x900@60Hz,
1600x900@60Hz, 1600x1200@60Hz,
1680x1050@60Hz, 1920x1200@60Hz;
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
7
SMPTE:
4096x2160@24/25/30/50/60Hz,
3840x2160@24/25/30/50/60Hz,
1080P@24/25/30/50/60Hz, 1080I@50/60Hz,
720P@50/60Hz, 576P@50Hz, 480P@60Hz
Video Impedance 100 Ω
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)
Humidity 10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV(Air-gap discharge)/
±4kV(Contact discharge)
Surge Protection
Voltage: ±1 kV
(Ten times respectively for the positive and negative
voltage)
Electrical Fast Transient/Burst Data communication cord: 1 kV
Power cord : 2 kV
Power Supply DC 12V 0.5A
Power Consumption
(Maximum) ≤2 W
Device Dimension
(W x H x D)
120mm x 20mm x 80mm /
4.72’’ x 0.79’’ x 3.15’’
Product Weight 0.23kg
Certification CE, FCC
CPA562 HDMI IN-Line Controller
Altimium www.altimium.com
8
Panel Layout
Front Panel
No.
Name
Description
1 DC 12V 12V DC power input, threaded port for standard or locking
connection
2 POWER LED ON: The transmitter is powered on.
OFF: The transmitter is powered off.
3 HDMI IN Connects to an HDMI source
4 EDID Switch for EDID Management with 15 EDID presets
5 S/PDIF OUT HDMI audio de-embedded out with Digital Coaxial, connects to
the amplifier
6 AUDIO OUT HDMI audio de-embedded out with Analog Stereo, connects to
the amplifier
