Alto-Shaam FryTech ASF-60E Bedienungsanleitung

FryFry

TechTech

D U E T O O N G O I N G P R O D U C T I P R O V E E N T,S P E C I F I C AT I O N S A R E S U B JE C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A. #353 - 01/08

W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.

PHONE: 262.251.3800 800.558.8744 U.S.A./ CANADA FAX: 262.251.7067 800.329.8744 U.S.A.ONLY

www.alto-shaam.com

The Alto-Shaam ASF-60E open electric fryer cabinet is constructed of stainless steel and includes front- and rear-

mounted, heavy duty leveling casters. The fryer is provided with low-watt density, ribbon-style heating elements. The

14 gauge stainless steel fry tank holds 62 pounds (28 kg) of frying compound. Also included are two fry baskets and a

cleaning brush set. Fryer has a temperature range of 200°F to 390°F (93°C to 199°C). Solid state control provides a

temperature accuracy within 4° of set point.

■■ASF-60E Open Electric Fryer with Basic Control

• Unprecedented high level of efficiency.

• Quick oil temperature recovery.

• Stainless steel front, sides and tank.

• Dual, solid-state controls.

• elt cycle for solid or liquid shortening.

• 7-year limited fry tank warranty.

FACTORY INSTALLED OPTIONS

■■Automatic Basket Lifts

■■Deluxe Control

➥Programmable memory for up to six (6) product menu keys per lift.

■■Fryer/Dump Station Battery

➥Create a battery of ASF-60E fryers and ASF-60W dump stations in

any combination of up to five (5).

➥Includes oil filtration system. Specify right- or left-side placement

when ordering.

ITEM NO. _______________________

Show n w ith optional

automatic basket lifts

ASF-60E

ELECTRIC OPEN FRYER

23-1/4"

(590mm)

47-1/2"(1206mm)

150°

15-3/4"

(400mm)

33-5/8"(854mm)

45-1/4"(1148mm)

51-1/4"(1302mm)liftup

32-3/8"(822mm)

Electrical Connection

2-7/16"

(62mm)

D U E T O O N G O I N G P R O D U C T I P R O V E E N T, S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.

DIMENSIONS EXTERIOR H x W x D:

45-1/8" x 15-3/4" x 33-5/8"

(1146mm x 400mm x 854mm)

BASKET DI ENSIONS (HXWXD)

5-7/8" x 5-3/16" x 13-13/16"

(149mm x 131mm x 351mm)

#353 - 01/08

ASF-60E

ELECTRIC OPEN FRYER

W164 N9221 Water Street • P.O. Box 450 • enomonee Falls, Wisconsin 53052-0450 • U.S.A.

PHONE: 262.251.3800 800.558.8744 U.S.A./ CANADA FAX: 262.251.7067 800.329.8744 U.S.A. ONLY

www.alto-shaam.com

FryFry

TechTech

STANDARD ACCESSORIES

■■Basket, Half-Size (2 INCLUDED AS STANDARD)BS-27963

Brush Set (ONE 3-BRUSH SET INCLUDED AS STANDARD)

■■ ANGLE BRUSH BH-27382

■■ SCRUB BRUSH CE-27122

■■ STRAIGHT BRUSH BH-27121

OPTIONS

■■Fry Pot Cover 5007596

■■ Strainer/Skimmer CE-27400

C A PA C I T Y

SHORTENING/OIL: 62 lb (28 kg) AXI U

CLEARANCE REQUIREMENTS

BACK: 6" (152mm) FRONT: 25" (635mm)

6" (152mm) REQUIRED ON ALL SIDES WHEN

ADJACENT TO CO BUSTIBLE SURFACES.

INSTALLATION REQUIREMENTS

Hood installation is required.

Fryer must be installed level.

A flexible connector must be installed and

secured to the building structure.

NOT FACTORY SUPPLIED

WEIGHT EST NET WEIGHT SHIP WEIGHT

248 lb (113 kg) 330 lb (150 kg)

CARTON DI ENSIONS: 39" x 22" x 55"

(991mm x 559mm x 1397mm)

ELECTRICAL

VOLTAGE PHASE CYCLE/HZ AMPS kW

208-220 (ETL)3 60 47 17.93

at 208 3 60 45 16.2

at 220 3 60 47.6 18.2

240 (ETL)360 43.1 17.93

380-415

at 380 3 50 20.4 15.4

at 415 3 50 25.4 18.3

440-480 (ETL)

at 440 3 60 40.8 31

at 480 3 60 44.4 37

No cord and plug
