•Allsafetyinformationmustbefollowed

See Installation instructions for more safety precautions.

•RefertotheappropriatePartsCatalogforpartnumber information.

•Models listed on page 3.

PBC/PBE/PBH

Through-The-Wall R-410A

Air Conditioners & Heat Pumps

RT4271001

May2010

TECHNICAL MANUTECHNICAL MANU

TECHNICAL MANUALAL

ALAL

This manual is to be used by qualified, professionally trained HVAC technicians only. Goodman does

not assume any responsibility for property damage or personal injury due to improper service

procedures or services performed by an unqualified person.

isaregisteredtrademark ofMaytagCorporationor itsrelatedcompanies and isusedunder license toGoodmanCompany, L.P., Houston,TX. Allrights reserved.

PRODUCT IDENTIFICATION

The model number is used for positive identification of component parts used in manufacturing. Please use this number

whenrequesting service orpartsinformation.

PBC 09 3 E 35 A X A A

BASIC MODEL TYPE MAJOR/MINOR DESIGN REV.

PBC = Standard Cooler TTW

PBE = Electric Heat TTW

PBH = Heat Pump TTW

COOLING CAPACITY

09 = 9000 BTUH

12 = 12000 BTUH

RATED VOLTAGE

2 = 115V 60Hz 1Ph

3 = 230/208V 60Hz 1Ph

DESIGN SERIES (Refrig)

A = R-22

E = R-410A FEATURE COD

MA = Standard Model R-22

HEATER SIZE AX = Standard Model R-410A

00 = no electric heat

35 = 3.5 kw (230/208V)

Use up to 4 as needed

In alphabetical order

WARNING

WARNING HIGH VOLTAGE!

Disconnect ALL power before servicing or installing this unit. Multiple power

sources may be present. Failure to do so may cause property damage, personal

injury or death.

Goodman will not be responsible

for any injury or property damage

arising from improper service or service procedures. If

you install or perform service on this unit, you assume

responsibility for any personal injury or property damage

which may result. Many jurisdictions require a license to

install or service heating and air conditioning equipment.

WARNING

WARNING ONLY individuals meeting (at a

minimum) the requirements of

an "Entry Level Technician" as specified by the Air-

Conditioning, Heating, and Refrigeration Institute (AHRI)

may use this information. Attempting to install or repair

this unit without such background may result in product

damage, personal injury, or death.

WARNING

PRODUCT IDENTIFICATION

The model number is used for positive identification of component parts used in manufacturing. Please use this number

whenrequesting service orpartsinformation.

PBC092E00AX

PBC122E00AX

PBC093E00AX

PBC123E00AX

PBE093E35AX

PBE123E35AX

PBH092E12AX

PBH093E35AX

PBH113E35AX

The United States Environmental Protection Agency (“EPA”) has issued various regulations re-

garding the introduction and disposal of refrigerants introduced into this unit. Failure to follow

these regulations may harm the environment and can lead to the imposition of substantial fines.

These regulations may vary by jurisdiction. Should questions arise, contact your local EPA office.

WARNING

Do not connect or use any device

that is not design certified by

Goodman for use with this unit.

Serious property damage, personal injury, reduced unit

performance and/or hazardous conditions may result

from the use of such non-approved devices.

WARNING

WARNING To prevent the risk of property

damage, personal injury, or death,

do not store combustible materials or use gasoline or

other flammable liquids or vapors in the vicinity of this

appliance.

WARNING

HIGH VOLTAGE!

DISCONNECT ALL POWER BEFORE SERVICING OR

INSTALLING THIS UNIT. MULTIPLE POWER

SOURCES MAY BE PRESENT. FAILURE TO DO SO

MAY CAUSE PROPERTY DAMAGE, PERSONAL

INJURY OR DEATH.

PRODUCT DESIGN

PBC, PBE and PBH through-the-wall room air conditioners

are designed for window installations in residential applica-

tionsand are available in9,000through18,000 BTUH sizes.

Theyaredesignedfor 208/230/115volt singlephaseapplica-

tions.

The provided filter must be installed and under no circum-

stancesshould theunitbeoperatedwithout thefilterin place.

LocationandClearances

Be sure electrical service is adequate for chosen model of

air conditioner or heat pump. Complete electrical rating for

unitis found on serial plate locatedbehindfront grille. Elec-

trical outlet must be close enough to unit for power cord to

reachwithout strain.

Air conditioner should be the only appliance on individual

circuit.

For personal safety and to avoid possible damage to appli-

ance or home, observe all safety instructions.

NOTES:

1. Mechanical experience is required to install the air

conditioneror heat pump.

2. Installation can take from 1 to 3 hours, depending on

installer’s knowledge and skill.

3. If you encounter problems during installation, call our

consumerinformationlinetoll-freeat1-877-376-0214(U.S.

andCanadaonly). If your problem cannot be resolved by

phone, contact an authorized Amana®brand servicer.

Contact and service will be at your expense.

SPECIFICATIONS

PBC***E00AX

MODEL PBC092E00AX PBC122E00AX PBC093E00AX PBC123E00AX

Cooling (BTU's) 9200 11800 9200

8900 11800

11400

@EER 9.8 9.4 9.8 9.8

Cooling Watts 940 1260 940 - 910 1200 - 1160

Cooling Amps 8.6 11.6 4.4 - 4.7 5.6 - 6.0

Voltage 115 115 230 -208 230 -208

Plug Type Parallel Parallel Tandem Tandem

PowerCord Rating 15 amp 15 amp 15amp 15 amp

Power Cord Type LCDI LCDI LCDI LCDI

PowerCord length 8 feet 8 feet 6 feet 6 feet

Dehumidification:pints / hour 41 oz./hr 55 oz./hr 41 oz./hr 55 oz./hr

Fan Speeds

CFM cooling : High-Low 275 275 275 275

Fan OnlySpeed 3 Speed 3 Speed 3 Speed 3 Speed

Controls

Thermostattemp. range 64° - 86° 64° - 86° 64° - 86° 64° - 86°

Outercase : insulation panels PBWS01A PBWS01A PBWS01A PBWS01A

Condensate Drain Spout Yes on Outercase Yes on Outercase Yes on Outercase Yes on Outercase

Thermostatic Drain Valve Yes Yes Yes Yes

Adjustable changeover thermostat --- --- --- ---

Chassis Size 26" TTW 26"TTW 26" TTW 26"TTW

Chassis Heighth 15.625" 15.625" 15.625" 15.625"

Chassis Width 26" 26" 26" 26"

Chassis Depth 16.875" 16.875" 16.875" 16.875"

SPECIFICATIONS PBE***E00AX

MODEL PBE093E35AX PBE123E35AX

Cooling (BTU's) 9200

8900 11800

11400

@ EER 9.8 9.8

Cooling Watts 940 - 910 1200 - 1160

Cooling Amps 4.4 - 4.7 5.6 - 6.0

Electric Heat 11000 - 9000 11000 - 9000

Electric Heat Watts 3500 - 2900 3500 - 2900

Electric HeatAmps 15 / 14 15 / 14

Heatpump --- ---

Heatpump Watts --- ---

Heatpump Amps --- ---

Fan Watts Indoor 64 Indoor 64 Indoor

Fan Watts Outdoor 123 Outdoor 123 Outdoor

Voltage 230 -208 230 -208

Plug Type Perpendicular Perpendicular

Power Cord Rating 20 amp 20 amp

Power Cord Type LCDI LCDI

Power Cord length 6 feet 6 feet

Dehumidification: pints / hr. 41 oz./hr 55 oz./hr

Fan Speeds

CFM cooling : High-Low 265/- 265/-

Fan OnlySpeed 3 Speed 3 Speed

Controls

Thermostat temp. range 64° - 86° 64° - 86°

Outercase : insulation panels PBWS01A PBWS01A

Condensate Drain Spout Yes on Outercase Yes on Outercase

ThermostaticDrain Valve Yes Yes

Adjustable changeover thermostat --- ---

Chassis Size 26" 26"

ChassisHeighth 15.625" 15.625"

Chassis Width 26" 26"

ChassisDepth 16.875" 16.875"

SPECIFICATIONS

PBH***E00AX

MODEL PBH092E12AX PBH093E35AX PBH113E35AX

Cooling (BTU's) 9000 9000

8700 11500

11100

@ EER 9.4 9.4 9.4

Cooling Watts 960 960 -930 1220 - 1180

Cooling Amps 8.8 4.5 - 4.8 5.7 - 6.2

Electric Heat 3900 11000 - 9000 11000 - 9000

Electric HeatWatts 1150 3500 -2900 3500 - 2900

Electric HeatAmps 11 15/ 14 15 / 14

Heatpump (BTU's) 8500 8500

8200 11000

10700

@ C.O.P. 2.9 2.9 2.7

Heatpump Watts 860 860 - 830 1195 - 1160

Heatpump Amps 7.7 4.0 -4.2 5.2 - 5.6

Fan Watts Indoor 64 Indoor 64 Indoor 64 Indoor

Fan Watts Outdoor 123 Outdoor 123 Outdoor 123 Outdoor

Voltage 115 230 -208 230 -208

Plug Type Parallel Perpendicular Perpendicular

Power Cord Rating 15 amp 20amp 20amp

Power Cord Type LCDI LCDI LCDI

Power Cord length 8 feet 6 feet 6 feet

Dehumidification: pints / hr. 41 oz./hr 41 oz./hr 55 oz./hr

Fan Speeds

CFM cooling : High-Low 265/- 265/- 265/-

Fan OnlySpeed 3 Speed 3 Speed 3 Speed

Controls

Thermostattemp. range 64° - 86° 64° - 86° 64° - 86°

Outercase :insulation panels PBWS01A PBWS01A PBWS01A

Condensate Drain Spout Yes on Outercase Yes on Outercase Yes on Outercase

Thermostatic Drain Valve Yes Yes Yes

Adjustable changeover thermostat Yes Yes Yes

Chassis Size 26" 26" 26"

Chassis Heighth 15.625" 15.625" 15.625"

Chassis Width 26" 26" 26"

Chassis Depth 16.875" 16.875" 16.875"

PBC***E00AX

SEN

BTUH SEN

BTUH

85 95 105 115

75 8675 6555 76 8230 6335 77 7745 6100 79 7235 5860 81

61 80 8630 7675 89 8195 7450 91 7720 7210 93 7330 7330 100

85 8775 8775 100 8420 8420 100 8050 8050 100 7630 7630 100

75 9815 5265 54 9375 5065 54 8760 4860 55 8185 4760 58

67 80 9720 6510 67 9200 6085 66 8650 5875 68 8080 5595 69

85 9560 7575 79 9120 7445 82 8505 7170 84 7970 6745 85

75 11030 3950 36 10450 3735 36 9860 3520 36 9235 3295 36

73 80 10905 5045 46 10335 4835 47 9725 4615 47 9095 4390 48

85 10765 6140 57 10190 5930 58 9575 5710 60 8940 5485 61

75 11175 11175 100 10535 8370 79 9810 8035 82 8770 7645 87

61 80 11130 10140 91 10495 9825 94 9750 9465 97 8875 9055 102

85 11410 11410 100 10880 10880 100 10230 10230 100 9540 9540 100

75 12660 6895 54 12100 6660 55 11230 6300 56 10365 5950 57

67 80 12520 8290 66 11800 7990 68 11025 7675 70 10130 7345 73

85 12315 9750 79 11705 9500 81 10820 9160 85 9915 8825 89

75 14290 5070 35 13515 4780 35 12725 4495 35 11825 4175 35

73 80 14120 6510 46 13335 6220 47 12530 5930 47 11535 5580 48

85 13930 7950 57 13165 7670 58 12265 7375 60 11260 7000 62

MODEL ID WB

ENT ID DB

ENT TOTAL

BTUH SHR TOTAL

BTUH SHR

PBC "E" MODEL 230V

TOTAL

BTUH SHR

OUTDOOR TEMP

PBC123 PBC09

PERFORMANCE DATA

PBC***E00AX

SEN

BTUH SEN

BTUH

85 95 105 115

75 8375 6255 75 7930 6035 76 7445 5800 78 6935 5560 80

61 80 8330 7375 89 7895 7150 91 7420 6910 93 7030 7030 100

85 8475 8475 100 8120 8120 100 7750 7750 100 7330 7330 100

75 9515 4965 52 9075 4765 53 8460 4560 54 7885 4460 57

67 80 9420 6210 66 8900 5785 65 8350 5575 67 7780 5295 68

85 9260 7275 79 8820 7145 81 8205 6870 84 7676 6445 84

75 10730 3650 34 10150 3435 34 9560 3220 34 8935 2995 34

73 80 10605 4745 45 10035 4535 45 9425 4315 46 8795 4090 47

85 10465 5840 56 9890 5630 57 9275 5410 58 8640 5185 60

75 10775 10775 100 10135 7970 79 9410 7635 81 8370 7245 87

61 80 10730 9740 91 10095 9425 93 9350 9065 97 8475 8655 102

85 11010 11010 100 10480 10480 100 9830 9830 100 9140 9140 100

75 12260 6495 53 11700 6260 53 10830 5900 54 9965 5550 56

67 80 12120 7890 65 11400 7590 67 10625 7275 68 9730 6945 71

85 11915 9350 78 11305 9095 80 10420 8760 84 9515 8420 89

75 13890 4670 34 13115 4380 33 12325 4095 33 11425 3775 33

73 80 13720 6110 45 12935 5820 45 12130 5530 46 11135 5180 47

85 13530 7550 56 12765 7270 57 11865 6975 59 10860 6600 61

ID WB

ENT ID DB

ENT TOTAL

BTUH SHRMODEL TOTAL

BTUH TOTAL

BTUH

SHR SHR

PBE "E" MODEL 208V

SHR

PBC123 PBC09

PERFORMANCE DATA

PBE***E00AX

SEN

BTUH SEN

BTUH

85 95 105 115

75 8675 6555 76 8230 6335 77 7745 6100 79 7235 5860 81

61 80 8630 7675 89 8195 7450 91 7720 7210 93 7330 7330 100

85 8775 8775 100 8420 8420 100 8050 8050 100 7630 7630 100

75 9815 5265 54 9375 5065 54 8760 4860 55 8185 4760 58

67 80 9720 6510 67 9200 6085 66 8650 5875 68 8080 5595 69

85 9560 7575 79 9120 7445 82 8505 7170 84 7970 6745 85

75 11030 3950 36 10450 3735 36 9860 3520 36 9235 3295 36

73 80 10905 5045 46 10335 4835 47 9725 4615 47 9095 4390 48

85 10765 6140 57 10190 5930 58 9575 5710 60 8940 5485 61

75 11175 11175 100 10535 8370 79 9810 8035 82 8770 7645 87

61 80 11130 10140 91 10495 9825 94 9750 9465 97 8875 9055 102

85 11410 11410 100 10880 10880 100 10230 10230 100 9540 9540 100

75 12660 6895 54 12100 6660 55 11230 6300 56 10365 5950 57

67 80 12520 8290 66 11800 7990 68 11025 7675 70 10130 7345 73

85 12315 9750 79 11705 9500 81 10820 9160 85 9915 8825 89

75 14290 5070 35 13515 4780 35 12725 4495 35 11825 4175 35

73 80 14120 6510 46 13335 6220 47 12530 5930 47 11535 5580 48

85 13930 7950 57 13165 7670 58 12265 7375 60 11260 7000 62

MODEL ID WB

ENT ID DB

ENT TOTAL

BTUH SHR TOTAL

BTUH SHR

PBE "E" MODEL 230V

TOTAL

BTUH SHR

OUTDOOR TEMP

PBE09

PBE123

PERFORMANCE DATA

Andere Handbücher für R-410A

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Amana Klimaanlage Handbücher

Amana

Amana PBC123B00MB Kurzanleitung

Amana

Amana Air Conditioners Kurzanleitung

Amana

Amana PTC073E Series Betriebsanleitung

Amana

Amana AAC051SRA Bedienungsanleitung

Amana

Amana ESA3067 - annexe 1 Bedienungsanleitung

Amana

Amana PACKAGE TERMINAL Service-Handbuch

Amana

Amana AMAP222BW Bedienungsanleitung

Amana

Amana SS-PTAC50 Montageanleitung

Amana

Amana AAC051STA Bedienungsanleitung

Amana

Amana AP095R Bedienungsanleitung

Amana

Amana PTC073D00ARDA Betriebsanleitung

Amana

Amana Room Air Conditioner & Heat Pump Bedienungsanleitung

Amana

Amana ACB06KE Bedienungsanleitung

Amana

Amana PTH123G25AXXX Service-Handbuch

Amana

Amana DigiSmart PTC073G***XXX Montageanleitung

Amana

Amana Thru-wall Bedienungsanleitung

Amana

Amana VCA Betriebsanleitung

Amana

Amana AMAP121A Bedienungsanleitung

Amana

Amana AP076E Bedienungsanleitung

Amana

Amana AP099R Bedienungsanleitung

Amana

Amana 10M52TB-P1230808R Bedienungsanleitung

Amana

Amana APG16 M Series Bedienungsanleitung

Amana

Amana PTAC 24" Service-Handbuch

Amana

Amana First Edition Bedienungsanleitung

Beliebte Klimaanlage Handbücher anderer Marken

Spheros

Spheros CC 355 Bedienungsanleitung

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Bedienungsanleitung

Panasonic

Panasonic CS-E12HKEW Bedienungsanleitung

nedis

nedis ACMB1WT7 Bedienungsanleitung

Samsung

Samsung AR KV Series Leitfaden

Daikin

Daikin FCFV50A Bedienungsanleitung

Fujitsu

Fujitsu Inverter ASBA30JFC Bedienungsanleitung

Toshiba

Toshiba RAS-M10SMUV-E Bedienungsanleitung

Daikin

Daikin FXLQ20MAVE Bedienungsanleitung

Hitachi

Hitachi RAS-E24CAK Bedienungsanleitung

CIAT

CIAT Magister 2 Series Leitfaden

Bestron

Bestron AAC6000 Bedienungsanleitung

Hisense

Hisense 7K Technisches Handbuch

Frigidaire

Frigidaire FFRE0533S1E0 Bedienungsanleitung

Samsung

Samsung AS09HM3N Bedienungsanleitung

Frigidaire

Frigidaire CRA073PU11 Betriebsanleitung

Soleus Air

Soleus Air GB-PAC-08E4 Bedienungsanleitung

McQuay

McQuay MCK020A Bedienungsanleitung
